Bomag BW 120 AC-5 Combination Roller Operating and Maintenance Instructions 00820131

$20.00

Type Of Manual: Operating and Maintenance Instructions
Manual ID: 00820131
Format: PDF
Size: 6.8MB
Number of Pages: 234
Serial Number:
101880351046 and up

Category: Bomag Operator Manual PDF

Notice: Undefined index: active_product in /usr/local/lsws/automanual.net/html/wp-content/plugins/text-to-speech-mh/public/class-text-to-speech-mh-public.php on line 115

Model List:
- BW 120 AC-5 Combination Roller

1. Table of contents
2. Introduction
2.1. Foreword
2.2. Machine type plate and engine type plate
3. Technical data
3.1. Noise and vibration data
4. Concerning your safety
4.1. Basic prerequisites
4.2. Definition of responsible persons
4.3. Fundamentals for safe operation
4.4. Handling fuels and lubricants
4.5. Loading / transporting the machine
4.6. Startup procedure
4.7. Driving the machine working operation
4.8. Refuelling
4.9. Regeneration of exhaust gas aftertreatment system
4.10. Emergency procedures
4.11. Maintenance work
4.12. Repair
4.13. Signage
5. Indicators and control elements
5.1. Drivers stand
5.2. Outside of machine
5.3. Engine compartment
6. Checks prior to start up
6.1. Notes on safety
6.2. Visual inspections and function tests
6.3. Checking the engine oil level
6.4. Checking the fuel level, topping up fuel
6.5. Checking the hydraulic oil level
6.6. Checking the hydraulic oil filter
6.7. Checking the coolant level
6.8. Checking the air filter
6.9. Checking the water level, topping up
6.10. Checking the emulsion level, topping up
6.11. Checking, adjusting the scrapers
6.12. Checking wheels and tyres
7. Operation
7.1. Settingup the work place
7.2. Electronic immobilizer
7.3. Starting the engine
7.4. Travel operation
7.5. Working with vibration
7.6. Water spraying system
7.7. Regeneration of exhaust gas aftertreatment system
7.8. Crabwalk
7.9. Parking the machine in secured condition
7.10. Edge cutter
7.11. Chip spreader
7.12. Emergency procedures
8. Loading / transporting the machine
8.1. Prepare for transport
8.2. Loading the machine
8.3. Lashing the machine to the transport vehicle
8.4. Loading by crane
8.5. After transport
9. Maintenance
9.1. Preliminary remarks and safety notes
9.2. Fuels and lubricants
9.3. List of fuels and lubricants
9.4. Runningin instructions
9.5. Maintenance Table
9.6. Every 50 operating hours
9.7. Every 250 operating hours
9.8. Every 500 operating hours
9.9. Every 1000 operating hours
9.10. Every 2000 operating hours
9.11. Every 3000 operating hours
9.12. As required
10. Troubleshooting
10.1. Preliminary remarks
10.2. Starting the engine with jump leads
10.3. Fuse assignment
10.4. Fault code display
10.5. Engine faults
10.6. Trouble shooting ECONOMIZER
11. Disposal
11.1. Final shutdown of machine
