Bomag BW 154 AP – 4i, BW 174 AP – 4i Electrics Documentation

$20.00

Type Of Manual: Documentation
Format: PDF
Size: 1.6MB
Number of Pages: 105

Category: Bomag Operator Manual PDF

Model List:
- BW 154 AP – 4i Electrics
- BW 174 AP – 4i Electrics

1. Table of contents
2. Confirmation of changes
2.1. Document
2.2. Software
3. Displayed monitoring activities with fault reactions
4. Known faults
5. How to proceed when replacing components
5.1. How to proceed when replacing an ESX control (A34)
5.2. How to proceed when replacing a data collector module (A 80)
5.3. How to proceed when replacing a travel pump
5.4. How to proceed when replacing a steering valve
5.5. How to proceed when replacing a steering angle sensor
5.6. Which components can be replaced without a subsequent adjustment procedure
5.7. Software update
6. Functions of the ESX control
6.1. General display functions and operation
6.1.1. Calling up service mode
6.1.2. Entering input codes
6.2. Driving against the closed brake
6.3. Setting the machine type
6.4. Adjusting the crossslope sensor
6.5. Calibration of the angle transducers
6.6. Adjusting the angle transducers
6.7. Automatic detection of surge currents on steering valves
6.8. Automatic detection of surge currents in travel system
6.9. Fault log display and delete
6.9.1. Deleting all stored faults
6.10. Adjusting the chip spreader type
6.11. Activating edge cutting units
6.12. Initializing the LCDisplay
6.13. Inspection of DPFsystem on Kubota engines
7. Description of signals on the electronic modules
7.1. Description of the signals on the ESXcontrol
7.2. Description of signals on the data collector
7.3. Description of signals on the travel lever
7.4. Description of Signals on Display Module
7.5. Description of Signals on the BLM IO Module
8. Description of fault codes on the ESX control
8.1. Overview
8.2. Description of fault reactions
8.3. Note codes
