Clark C 500 Overhaul Manual OH-339

$30.00

Type Of Manual: Overhaul Manual
Manual ID: OH-339
Format: PDF
Size: 86.0MB
Number of Pages: 641

Category: Clark Parts Manual PDF

Model List:
- C 500

1. TABLE OF CONTENTS
2. FOREWORD
3. SAFETY MESSAGES
4. GROUP 00 SECTION 3 (Gas)
4.1. TROUBLE SHOOTING
4.2. CYLINDER HEAD OVERHAUL
4.3. CYLINDER HEAD REASSEMBLY
4.4. LOWER ENGINE OVERHAUL
4.5. DISASSEMBLY (ENGINE FRONT)
4.6. Gear Installation
4.7. GEAR TIMING
4.8. BASIC ENGINE DATA
5. GROUP 00 SECTION 4 (Diesel)
5.1. CLARK (WAUKESHA) D155D OVERHAUL
5.2. FUEL INJECTION TEST MAINTENANCE
5.3. INSTALLATION OF NEW VALVE LIFTERS ALONG WITH NEW CAMSHAFT
5.4. ASSEMBLY OF WATER PUMP
5.5. REASSEMBLY OF WATER PUMP
5.6. Dl55D ENGINE REASSEMBLY
5.7. TIMING
5.8. INJECTION PUMP ENGINE TIMING
5.9. DIESEL BASIC ENGINE DATA
5.10. TIMING GEAR/S BACKLASH
6. GROUP 00 SECTION 12 (Perkins)
7. EXHAUST EMISSION SYSTEM
8. SECTION I MAINTENANCE AND FIELD INSTALLATION OF LOW EMISSION EQUIPMENT
9. SECTION II MODELS 2267 LW 10 AND LX 9 CARBURATORS
9.1. ZENITH CARBURETOR MODEL Z267LWlO AND Z267LX9
9.2. ZENITH 68 SERIES CARBURETORS
10. SECTION IIIZENITH 28 228SERIES CARBURETORS
10.1. ZENITH 28 AND 228 SERIES CARBURETORS
11. SECTION IV MODELS ZPC 2 J 10 AND ZPC 1 J 8 CARBURATORS
11.1. BENDIXZENITH CARBURETOR ASSEMBLY MODEL ZPCZJIO AND ZPClJ8
12. TYPE A962A VAPORlZER PRIMARY REGULATORS
13. GROUP 02 SECTION 5 IMPCO LPG LOCKOFF VALVE
14. GROUP 02 SECTION 6 IMPCO LPG VAPORIZERREGULATOR
15. GROUP 02 SECTION 8 IMPCO LPG CARBURETOR
16. SPEED FORWARD AND REVERSE HYDRATORK TRANSMISSION (MODELS H200 THROUGH H211)
16.1. CLEANING AND INSPECTION
16.2. SELECTOR PACK REASSEMBLY
16.3. MODEL H200 TRANSMISSION REASSEMBLY
16.4. FLUID SEAL/S, SPECIFICATIONS
17. SPEED FORWARD AND REVERSE HYDRATORK TRANSMISSION (MODELS H200 THROUGH H211)
17.1. REASSEMBLY
17.2. FLUID SEAL(S), SPECIFICATIONS
18. MODLE H200D MANUAL TRANSMISSION DISASSEMBLY AND REASSEMBLY
19. R 200 1 SPEED MANUAL TRANSMISSION
19.1. MODLE R200D MANUAL TRANSMISSION DISASSEMBLY AND REASSEMBLY
19.2. MODEL R200T MANUAL TRANSMISSION DISASSEMBLY ANDREASSEMBLY
19.3. PARKING BRAKE DISASSEMBLY AND REASSEMBLY
19.4. TRANSMISSION REASSEMBLY
20. SUN TESTER
21. GROUP 11 SECTION 4 DELCOREMY STARTING MOTOR OVERHAUL
22. DELCOREMY IGNITION DISTRIBUTORS
23. GROUP 12 SECTION 3 ALTERNATOR OVERHAUL
24. ALTERNATORS DELCOREMY DELCOTRON
25. DELCOTRON GENERATORS
26. DRIVE AXLE, DIFFERENTIAL AND AXLE ADAPTOR
26.1. AXLE END DISASSEMBLY AND ASSEMBLY
26.2. REASSEMBLY OF THE AXLE END ASSEMBLY
26.3. HYDRAULIC ACTUATION WHEEL CYLINDERS
26.4. OTHER WHEEL CYLINDER TYPES
26.5. TWO BLEEDING METHODS MANUAL AND PRESSURE
26.6. PARK I NG BRAKE
26.7. WHEEL BRAKE
26.7.1. AUTOMATIC BRAKE ADJUSTERS
26.7.2. CHECKING ADJUSTOR PIN TO SHOE SLOT CLEARANCE,
26.8. TO ELEVATE DRIVE WHEELS
27. NEUTRAL STARTING SWITCH
28. POWER STEER CYLINDER
29. GROUP 29 HYDRAULIC PUMP OVERHAUL SECTION 1
30. VANE TYPE HYDRAULIC PUMPS (SINGLE)
31. Parker Hannifin Hydraulic Unit
32. Section I Parker Hannifin D Series Gear Pumps
33. TESTING THE HYDRAULIC SYSTEM
34. DISASSEMBLY REASSEMBLY OF VICKERS CM11 SERIES 21 DESIGN VALVE
35. TILT LOCK VALVE TROUBLE SHOOTING
36. GROUP 32 GREER BLADDER ACCUMULATOR OVERHAUL
37. GROUP 32 SECTION 6 TILT CYLINDER OVERHAUL
38. GROUP 34 UPRIGHT LIFT CYLINDER OVERHAUL
39. GROUP 34 SECTION 2 UPRIGHT ROLLER CHECK AND ADJUSTMENT PROCEDURES
