Clark C60 L, C70 L, C75 L Service Manual SM-1057

$30.00

Type Of Manual: Service Manual
Manual ID: SM-1057
Format: PDF
Size: 52.7MB
Number of Pages: 889
Serial Number:
PSI (T4, T0)

Category: Clark Service Manual PDF

Model List:
- C60 L
- C70 L
- C75 L

1. SM1057
2. CONTENTS
3. GROUP SA SAFE MAINTENANCE
3.1. Section 1 Safety
3.2. Section 2 Lifting, Jacking, and Blocking the Truck
3.3. Section 3 Towing
4. GROUP PS PERIODIC SERVICE
4.1. Section 1 Maintenance Schedules
4.2. Section 2 The Planned Maintenance Program
5. GROUP 00 (LPSI 4X) ENGINE (LPG PSI 4X 4.3L)
5.1. Section 1 Engine Mechanical
5.2. Section 2 Diagnostic Information and Procedures
5.3. Section 3 Inspection, Removal and Installation
5.4. Section 4 Description and Operation
5.5. Section 5 PSI Fuel System
5.6. Section 6 Special Tools and Equipment
6. GROUP 01 ENGINE COOLING SYSTEM
6.1. Section 1 Engine Cooling System Specifications and Description
6.2. Section 2 Engine Cooling System Troubleshooting
6.3. Section 3 Engine Cooling System Testing and Maintenance
6.4. Section 4 Radiator Removal and Replacemant
7. GROUP 03 INTAKE AND EXHAUST SYSTEM
7.1. Section 1 Intake and Exhaust Systems Specifications and Description
7.2. Section 2 Intake System Troubleshooting
7.3. Section 3 Intake System Service
7.4. Section 4 Exhaust Systems
8. GROUP 08 TRANSMISSION (T12313) (FOR LPG TRUCK)
8.1. Section 1 DISASSEMBLY
8.2. Section 2 DISASSEMBLY AND REASSEMBLY OF 1st AND 2nd CLUTCH
8.3. Section 3 DISASSEMBLY AND REASSEMBLY OF 3rd CLUTCH
8.4. Section 4 DISASSEMBLY AND REASSEMBLY OF FORWARD AND REVERSE CLUTCHES
8.5. Section 5 REGULATOR VALVE DISASSEMBLY AND REASSEMBLY
8.6. Section 6 CLEANING AND INSPECTION
8.7. Section 7 TROUBLESHOOTING PROCEDURES
8.8. Section 8 TRANSMISSION CONTROLLER
8.9. Section 9 TRANSMISSION REMOVAL AND INSTALLATION
9. GROUP 13 ELECTRICAL SYSTEM
9.1. Section 1 Cautions for working on the electrical system
9.2. Section 2 Electrical system Specifications and features
9.3. Section 3 Electrical Circuit Diagram Electrical Parts Arrangement
9.4. Section 4 Instrument Pod
9.5. Section 5 Air Conditioning System (Option)
10. GROUP 21 (L) DRIVE AXLE (for LPG truck)
10.1. Section 1 System Operation
10.2. Section 2 Differential Carrier Assy
10.3. Section 3 Drive Axle
10.4. Section 4 Problem and Cause
10.5. Section 5 Disassembly and Reassembly of Drive Axle
10.6. Section 6 Transmission Removal and Installation
11. GROUP 22 WHEELS AND TIRES
11.1. Section 1 Wheels and Tires Specifications and Description
11.2. Section 2 Pneumatic Wheels and Tires
12. GROUP 23 BRAKE SYSTEM
12.1. Section 1 Braking / Inching System Specifications and Description
12.2. Section 2 Service Brake Troubleshooting
12.3. Section 3 Brake / Inching Pedals and Linkages Adjustments
12.4. Section 4 Brake System Bleeding
12.5. Section 5 Brake Valve Service
12.6. Section 6 Parking Brake Service
13. GROUP 25 STEERING COLUMN AND GEAR
13.1. Section 1 Steering System Specifications and Description
13.2. Section 2 Steering System Troubleshooting
13.3. Section 3 Steering Column and Component Removal and Replacement
13.4. Section 4 Steering System Relief Pressure Check and Adjustment
13.5. Section 5 Steering Gear Overhaul
14. GROUP 26 STEER AXLE
14.1. Section 1 Steer Axle Specifications and Description
14.2. Section 2 Steer Axle Wheel Bearing Maintenance and Adjustment
14.3. Section 3 Steer Axle Removal and Replacement
14.4. Section 4 Steer Axle Overhaul
14.5. Section 5 Steer Cylinder Removal and Replacement
14.6. Section 6 Steer Cylinder Overhaul
15. GROUP 29 HYDRAULIC SUMP, FILTERS, AND PUMP
15.1. Section 1 Main Hydraulic Sump, Filters, and Pump Specifications and Description
15.2. Section 2 Main Hydraulic Pump Troubleshooting
15.3. Section 3 Main Hydraulic Removal and Installation
16. GROUP 31 HYDRAULIC CONTROL VALVE
16.1. Section 1 Operation of Hydraulic Control Valve
16.2. Section 2 Hydraulic Circuit
16.3. Section 3 Disassembling Hydraulic Valve
16.4. Section 4 Assembling Hydraulic Control Valve
16.5. Section 5 Hydraulic System Pressure Checks and Adjustments
16.6. Section 6 Hydraulic Control Valve Removal and Replacement
16.7. Section 7 Testing Hydraulic Valve
16.8. Section 8 EHL Valve Disassembly and Assembly
17. GROUP 32 TILT CYLINDERS
17.1. Section 1 Tilt Cylinder Specifications and Description
17.2. Section 2 Tilt Cylinder Checks and Adjustments
17.3. Section 3 Tilt Cylinder Removal and Replacement
17.4. Section 4 Tilt Cylinder Overhaul
18. GROUP 34 UPRIGHTS
18.1. Section 1 Upright Specifications and Description
18.2. Section 2 Troubleshooting
18.3. Section 3 Upright Inspection
18.4. Section 4 Carriage and Upright Roller Clearance Checks and Shim Adjustments
18.5. Section 5 Cylinder Removal, Shimming, Overhaul, and Replacement
18.6. Section 6 Upright Chain Inspection, Adjustment, and Replacement
18.7. Section 7 Fork and Carriage Removal and Replacement
18.8. Section 8 Upright Removal and Replacement
19. GROUP 38 COUNTERWEIGHT AND CHASSIS
19.1. Section 1 Counterweight Specifications and Description
19.2. Section 2 Counterweight Removal and Replacement
19.3. Section 3 Overhead Guard / Operators Cell Removal and Replacement
19.4. Section 4 Floorboard, Cowls, and Seat Deck Removal and Replacement
19.5. Section 5 Operators Seat Removal and Replacement
20. GROUP 40 SPECIFICATIONS
20.1. Section 1 Nameplates and Decals
20.2. Section 2 General Specifications
20.3. Section 3 Hydraulic Fitting Tightening Procedure
