Clark EC 90, 120 Service Manual SM-646 - Image 2

Clark EC 90, 120 Service Manual SM-646 - Image 3

Clark EC 90, 120 Service Manual SM-646 - Image 4

Clark EC 90, 120 Service Manual SM-646 - Image 5

Clark EC 90, 120 Service Manual SM-646

$30.00

Type Of Manual: Service Manual
Manual ID: SM-646
Format: PDF
Size: 6.9MB
Number of Pages: 324

Category: Clark Service Manual PDF

Model List:
- EC 90
- 120

1. SM 646 EC 90/120
2. Arrangement and Use of this Manual
3. Contents
4. Alphabetical Listing
5. GROUP SA SAFE MAINTENANCE
5.1. Section 1. Safety
5.2. Section 2. Lifting, Jacking, and Blocking
6. GROUP PS PERIODIC SERVICE
6.1. Section 1. Maintenance Schedule
6.2. Section 2. The Planned Maintenance Program
6.3. Section 3. The PM Inspection Form
7. GROUP 12 BATTERY
7.1. Section 1. Battery Service
8. GROUP 13 WIRING, SWITCHES, AND INSTRUMENTS
8.1. Section 1. Electrical Diagrams
8.2. Section 2. General Electrical Service Tips
8.3. Section 3. Switches and Sensors
8.4. Section 4. Instrument Panel
9. GROUP 16 ELECTRICAL MOTORS
9.1. Section 1. Motors Specifications and Description
9.2. Section 2. Motors Inspection and Troubleshooting
9.3. Section 3. Drive Motor Overhaul
9.4. Section 4. Lift Pump Motors
9.5. Section 5. Steer Pump Motor Overhaul
10. GROUP 19 MOTOR CONTROLS
10.1. Section 1. Specifications and Description
10.2. Section 2. Control System Maintenance and Checks
10.3. Section 3. Control Panel Removal and Replacement
10.4. Section 4. Contactors Overhaul
10.5. Section 5. EV200 LX Handset Operation Supplement
10.6. Section 6. EV200 LX Status Codes
11. GROUP 20 DRIVE AXLE
11.1. Section 1. Drive Axle Specifications and Description
11.2. Section 2. Drive Axle Troubleshooting
11.3. Section 3. Drive Axle Removal and Installation
11.4. Section 4. Drive Axle Overhaul General Practices
11.5. Section 5. Drive Axle Ends Overhaul
11.6. Section 6. Drive Axle Differential Adaptor Overhaul
11.7. Section 7. Drive Axle Differential Overhaul
12. GROUP 22 WHEELS AND TIRES
12.1. Section 1. Specifications and Description
12.2. Section 2. Cushion Wheels and Tires
13. GROUP 23 BRAKE SYSTEM
13.1. Section I. Brake System Specifications and Descriptions
13.2. Section 2. Service Brake Troubleshooting
13.3. Section 3. Pedal and Linkage Adjustments
13.4. Section 3. Service Brake Linkage Adjustment
13.5. Section 4. Brake System Bleeding
13.6. Section 5. Brake Master Cylinder Service
13.7. Section 6. Service Brake Overhaul
13.8. Section 7. Seat Brake Service
14. GROUP 25 STEERING SYSTEM
14.1. Section 1. Steering System Specifications and Description
14.2. Section 2. Steering System Troubleshooting
14.3. Section 3. Steering System Relief Pressure Check and Adjustment
14.4. Section 4. Steering Column Removal and Installation
14.5. Section 5. Steering Gear Overhaul
14.6. Section 6. Steering Pump Overhaul
14.7. Section 7. Steer Axle Maintenance and Overhaul
14.8. Section 8. Steer Cylinder Overhaul
15. GROUP 29/30 MAIN HYDRAULIC SYSTEM
15.1. Section 1. Main Hydraulic System Specifications and Description
15.2. Section 2. Fluids and Filters
15.3. Section 3. Hydraulic System Troubleshooting
15.4. Section 4. Hydraulic System Pressure Checks and Adjustments
15.5. Section 5. Main Hydraulic Pump Overhaul
15.6. Section 6. Hydraulic Control Valve Removal and Overhaul
16. GROUP 32 TILT CYLINDERS
16.1. Section 1. Tilt Cylinder Specifications and Description
16.2. Section 2. Tilt Cylinder Checks and Adjustments
16.3. Section 3. Tilt Cylinder Mounting and Overhaul
16.4. Section 4. Tilt Lock Valve Overhaul
17. GROUP 34 UPRIGHTS
17.1. Section 1. Upright Removal and Replacement
17.2. Section 2. Lift Chain Inspection and Service Guidelines
18. GROUP 38 COUNTERWEIGHT AND CHASSIS
18.1. Section 1. Counterweight Removal and Installation
18.2. Section 2. Overhead Guard Removal and Installation
18.3. Section 3. Seat and Sheet Metal Removal and Installation
19. GROUP 40 SPECIFICATIONS
19.1. Section 1. Nameplate and Decals
19.2. Section 2. General Specifications
19.3. Section 3. Hydraulic Fitting Tightening Procedure
