Hyster H360XD36, H360XD48 (C238) Parts Manual

Hyster H360XD36, H360XD48 (C238) Parts Manual - Image 2

Hyster H360XD36, H360XD48 (C238) Parts Manual - Image 3

Hyster H360XD36, H360XD48 (C238) Parts Manual - Image 4

Hyster H360XD36, H360XD48 (C238) Parts Manual - Image 5

hyster h360xd36 h360xd48 c238 parts manual 2

hyster h360xd36 h360xd48 c238 parts manual 3

Hyster H360XD36, H360XD48 (C238) Parts Manual

$30.00

Type Of Manual: Parts Manual
Number of Pages: 784
Size: 44.8MB
Format: PDF

Category: Hyster Parts Manual PDF

Model List:
- H360XD36, H360XD48 (C238)

1. FLOORPLATES AND STEPS
2. HOODS AND COVERS
3. COUNTERWEIGHT ATTACHING PARTS
4. CAB MOUNTING AND TILT
5. CAB TILT CYLINDER
6. CAB TILT PUMP ASSEMBLY
7. CAB TILT PUMP ELECTRIC
8. HAND PUMP
9. CAB GROUP OPEN CAB
10. CAB ASSEMBLY OPEN CAB
11. CAB SUB-ASSEMBLY OPEN CAB – PAGE 1 OF 2
12. CAB SUB-ASSEMBLY OPEN CAB – PAGE 2 OF 2
13. CAB GROUP CLOSED CAB
14. CAB ASSEMBLY CLOSED CAB
15. CAB SUB-ASSEMBLY CLOSED CAB – PAGE 1 OF 2
16. CAB SUB-ASSEMBLY CLOSED CAB – PAGE 2 OF 2
17. CAB REAR WIPER ASSEMBLY CLOSED CAB
18. CAB HEATED WINDOW CONNECTORS COVER
19. CAB DOOR LH – CLOSED CAB
20. CAB DOOR LH – CLOSED CAB, ALTERNATE ASSEMBLY
21. CAB DOOR RH – CLOSED CAB
22. CAB DOOR RH – CLOSED CAB, ALTERNATE ASSEMBLY
23. CAB WINDOW WIPER ASSEMBLY CLOSED CAB
24. CAB WINDOW WIPER ASSEMBLY CLOSED CAB – ALTERNATE ASSEMBLY
25. CAB SINGLE WIPER GROUP
26. CAB H-WIPER GROUP
27. CAB EXTERIOR MIRRORS
28. CAB ROOF PANEL GROUP
29. CAB ROOF MESH
30. CAB SUNSHADES
31. CAB RH REAR COVER W/O CONDENSER
32. CAB INTERIOR OPEN CAB
33. CAB INTERIOR CLOSED CAB
34. CAB DOCUMENT CLIP
35. CAB PASSENGER SEAT MOUNTING
36. CAB PASSENGER SEAT ASSEMBLY
37. CAB NOISE PANELS AND SOUND LINERS OPEN CAB – PAGE 1 OF 2
38. CAB NOISE PANELS AND SOUND LINERS OPEN CAB – PAGE 2 OF 2
39. CAB NOISE PANELS AND SOUND LINERS CLOSED CAB
40. SEAT SLIDING RAIL
41. SEAT BASE
42. SEAT AND HEADREST
43. SEAT AND HEADREST
44. SEAT ARMREST LH ( PENDING PER ECN 68901-28)
45. SEAT ASSEMBLY, AIR SUSPENSION 2-POINT BELT, DELUXE – PAGE 1 OF 2
46. SEAT ASSEMBLY, AIR SUSPENSION 2-POINT BELT, DELUXE – PAGE 2 OF 2
47. SEAT ASSEMBLY, AIR SUSPENSION 2 AND 3-POINT BELT, DELUXE, TEMPERATURE CONTROL – PAGE 1 OF 2
48. SEAT ASSEMBLY, AIR SUSPENSION 2 AND 3-POINT BELT, DELUXE, TEMPERATURE CONTROL – PAGE 2 OF 2
49. SEAT ASSEMBLY, AIR SUSPENSION 2 AND 3-POINT BELT, DELUXE – PAGE 1 OF 2
50. SEAT ASSEMBLY, AIR SUSPENSION 2 AND 3-POINT BELT, DELUXE – PAGE 2 OF 2
51. SEAT ASSEMBLY, AIR AND MECHANICAL SUSPENSION 2-POINT BELT, LOW BACK – PAGE 1 OF 2
52. SEAT ASSEMBLY, AIR SUSPENSION 2-POINT BELT, LOW BACK – PAGE 2 OF 2
53. CAB FLOORMATS OPEN CAB
54. CAB FLOORMATS CLOSED CAB
55. CAB DOOR STEP OPEN CAB
56. CAB DOOR STEP CLOSED CAB
57. CAB DOOR STOPPERS
58. CAB DOOR STOPPERS ALTERNATE ASSEMBLY
59. AIR CONDITIONER HOSES, COMPRESSOR, AND ATTACHING PARTS
60. CONDENSER AND ATTACHING PARTS
61. CONDENSER UNIT ASSEMBLY
62. HEATER HOSES
63. CAB HEATER AND AIR CONDITIONER MOUNTING
64. CAB HEATER AND AIR CONDITIONER MOUNTING
65. CAB HEATER AND AIR CONDITIONER ASSEMBLIES
66. CAB HEATER AND AIR CONDITIONER ASSEMBLIES
67. LABELS PAGE 1 OF 3
68. LABELS PAGE 2 OF 3
69. LABELS PAGE 3 OF 3
70. CAB GRAB BAR HANDLE
71. ENGINE ASSEMBLY
71.1. COOLING SYSTEM
71.2. RADIATOR ASSEMBLY
71.3. EXHAUST SYSTEM HIGH MOUNT END PIPE
71.4. EXHAUST SYSTEM LOW MOUNT END PIPE
71.5. MUFFLER/CATALYTIC CONVERTER ASSEMBLY DOC
71.6. MUFFLER/CATALYTIC CONVERTER ASSEMBLY SCR
71.7. EXHAUST PIPE DRT
71.8. ENGINE MOUNTING
71.9. AUXILIARY PUMP MOUNTING
71.10. CAMSHAFT
71.11. COOLANT PLUMBING
71.12. CRANKCASE BREATHER
71.13. CRANKCASE BREATHER PLUMBING
71.14. CYLINDER BLOCK
71.15. CYLINDER HEAD
71.16. DIPSTICK AND TUBE
71.17. DRIVE BELT TENSIONER
71.18. ENGINE COOLANT VENT
71.19. EXHAUST MANIFOLD
71.20. EXHAUST OUTLET
71.21. EXHAUST RECIRCULATION
71.22. EXHAUST RECIRCULATION AIR PLUMBING
71.23. EXHAUST RECIRCULATION WATER PLUMBING
71.24. FAN DRIVE AND MOUNTING
71.25. FLAT MULTI-RIBBED (V) BELT
71.26. FLYWHEEL AND MOUNTING
71.27. FLYWHEEL HOUSING
71.28. FRONT GEAR COVER
71.29. HEAT SHIELD
71.30. LIFTING BRACKETS
71.31. OIL COOLER
71.32. OIL FILTER, FULL FLOW
71.33. OIL PAN
71.34. PLUG, AUXILIARY COOLING PLUMBING
71.35. PLUG, COOLANT HEATER STARTING AID
71.36. PLUGS, CAB HEATER PLUMBING
71.37. REAR GEAR TRAIN ACCESSORY MOUNTING
71.38. REAR GEAR HOUSING
71.39. ROCKER LEVERS
71.40. STARTER MOTOR
71.41. THERMOSTAT
71.42. TURBOCHARGER
71.43. TURBOCHARGER PLUMBING
71.44. VALVE COVER
71.45. VIBRATION DAMPER
71.46. WATER INLET CONNECTION
71.47. WATER OUTLET CONNECTION
71.48. WATER PUMP
72. FUEL SYSTEM
72.1. DEF SYSTEM PAGE 1 OF 4
72.2. DEF SYSTEM PAGE 2 OF 4
72.3. DEF SYSTEM PAGE 3 OF 4
72.4. DEF SYSTEM PAGE 4 OF 4
72.5. DEF TANK ASSEMBLY
72.6. DEF TANK ASSEMBLY ALTERNATE PART
72.7. DEF SUPPLY MODULE
72.8. AIR INTAKE AND FILTER LOW MOUNT AIR CLEANER
72.9. AIR INTAKE AND FILTER HIGH MOUNT AIR CLEANER WITH AIRCO
72.10. AIR INTAKE AND FILTER HIGH MOUNT AIR CLEANER WITHOUT AIRCO
72.11. FUEL TANK
72.12. FUEL HOSES AND FILTER
72.13. ACCELERATOR PEDAL MONOTROL
72.14. ACCELERATOR PEDAL FORWARD/REVERSE LEVER
72.15. AIR INTAKE CONNECTION
72.16. AIR INTAKE MANIFOLD
72.17. AIR TRANSFER CONNECTION
72.18. DRAIN PLUG, FUEL PUMP
72.19. FUEL DRAIN PLUMBING
72.20. FUEL FILTER
72.21. FUEL FILTER PLUMBING
72.22. FUEL FILTER WITH WATER SEPARATOR
72.23. FUEL INJECTORS
72.24. FUEL INLET FITTING
72.25. FUEL INJECTOR PLUMBING
72.26. FUEL PUMP AND ATTACHING PARTS
73. ELECTRICAL SYSTEM
73.1. ELECTRICAL SYSTEM PAGE 1 OF 2
73.2. ELECTRICAL SYSTEM PAGE 2 OF 2
73.3. CAB ELECTRICAL MOUNTING
73.4. CAB ELECTRICAL REAR WALL ( S/N C238E01608V INC. 01610)
73.5. CAB ELECTRICAL REAR WALL (S/N C238E01609V EXC. 01610)
73.6. CAB ELECTRICAL ROOF ( S/N C238E01608V INC. 01610)
73.7. CAB ELECTRICAL ROOF (S/N C238E01609V EXC. 01610)
73.8. POWER DISTRIBUTION
73.9. TRANSMISSION CONTROLLER
73.10. RH ARMREST AND CONTROLS
73.11. ARMREST CONTROL BOX ASSEMBLY
73.12. JOYSTICK ASSEMBLY WITH FORWARD-NEUTRAL-REVERSE
73.13. JOYSTICK ASSEMBLY WITHOUT FORWARD-NEUTRAL-REVERSE
73.14. BUZZER ASSEMBLY
73.15. BEACON AND REAR WORK LIGHT MOUNTING WITHOUT A/C CONDENSER
73.16. LED BEACON WITH A/C CONDENSER WITH BEACON-ONLY LIGHT HARNESS
73.17. LED BEACON WITH A/C CONDENSER WITH REAR AND BEACON LIGHT HARNESS
73.18. LED BEACON WITH A/C CONDENSER WITH DRIVE, REAR AND BEACON LIGHT HARNESS
73.19. LED BEACON W/O A/C CONDENSER WITH BEACON-ONLY LIGHT HARNESS
73.20. LED BEACON W/O A/C CONDENSER WITH REAR AND BEACON LIGHT HARNESS
73.21. LED BEACON W/O A/C CONDENSER WITH DRIVE, REAR, AND BEACON LIGHT HARNESS
73.22. LIGHTS DRIVE
73.23. LIGHTS DIRECTIONAL AND MARKER – LED
73.24. LIGHTS FRONT FENDER
73.25. LIGHTS MAST WORK
73.26. LIGHTS REAR, WITH A/C CONDENSER – WITH REAR AND BEACON LIGHT HARNESS
73.27. LIGHTS REAR, WITH A/C CONDENSER – WITH DRIVE, REAR, AND BEACON LIGHT HARNESS
73.28. LIGHTS REAR, WITHOUT A/C CONDENSER – WITH REAR AND BEACON LIGHT HARNESS
73.29. LIGHTS REAR, WITHOUT A/C CONDENSER – WITH DRIVE, REAR, AND BEACON LIGHT HARNESS
73.30. LIGHTS REAR BLUE SPOTLIGHT
73.31. LIGHTS TAIL
73.32. CAB INTERIOR LIGHT GROUP STANDARD
73.33. CAB INTERIOR LIGHT GROUP DELUXE
73.34. CAB READING LIGHT
73.35. CAB LIGHT/WIPER CONTROLLER GROUP
73.36. CAB DISPLAY
73.37. CAB DOOR SWITCH
73.38. CAB FAN
73.39. CAB FAN ALTERNATE CONFIGURATION
73.40. DC-DC CONVERTER
73.41. SECOND 12V SOCKET OPTION
73.42. CAB REAR VIEW CAMERA REAR MOUNTED
73.43. CAB REAR VIEW CAMERA FRONT MOUNTED
73.44. WIRE HARNESS BEACON LIGHT
73.45. WIRE HARNESS CAB DISPLAY
73.46. WIRE HARNESS CAB DISPLAY – ALTERNATE PART
73.47. WIRE HARNESS CAB LIGHTS
73.48. WIRE HARNESS CAB LIGHTS W/BEACON
73.49. WIRE HARNESS CAB REAR VIEW CAMERA
73.50. WIRE HARNESS CAB REAR VIEW CAMERA – ALTERNATE PART
73.51. WIRE HARNESS CAB REAR VIEW CAMERA EXTENSION
73.52. WIRE HARNESS CAB REAR VIEW CAMERA – FRONT MOUNTED
73.53. WIRE HARNESS CAB REAR WALL – PAGE 1 OF 2
73.54. WIRE HARNESS CAB REAR WALL – PAGE 2 OF 2
73.55. WIRE HARNESS CAB REAR WALL – PAGE 1 OF 2, ALTERNATE PART
73.56. WIRE HARNESS CAB REAR WALL – PAGE 2 OF 2, ALTERNATE PART
73.57. WIRE HARNESS CAB REAR WALL – PAGE 1 OF 2 (S/N C238E01609V EXC. 01610)
73.58. WIRE HARNESS CAB REAR WALL – PAGE 2 OF 2 (S/N C238E01609V EXC. 01610)
73.59. WIRE HARNESS CAB ROOF WITH CONTROLLER
73.60. WIRE HARNESS CAB ROOF WITH CONTROLLER – ALTERNATE PART
73.61. WIRE HARNESS CAB ROOF WITH CONTROLLER (S/N C238E01609V EXC. 01610)
73.62. WIRE HARNESS CAB TILT
73.63. WIRE HARNESS CARRIAGE
73.64. WIRE HARNESS CARRIAGE, DFSSFP – SPLITTER
73.65. WIRE HARNESS CARRIAGE, STD/SS
73.66. WIRE HARNESS CHASSIS – PAGE 1 OF 2
73.67. WIRE HARNESS CHASSIS – PAGE 2 OF 2
73.68. WIRE HARNESS CLOSED CAB FLOOR
73.69. WIRE HARNESS CLOSED CAB FLOOR – ALTERNATE CONFIGURATION
73.70. WIRE HARNESS DEF SYSTEM
73.71. WIRE HARNESS ECM/EAS
73.72. WIRE HARNESS FRONT LIGHTS
73.73. WIRE HARNESS HOOD SPINE
73.74. WIRE HARNESS MAST
73.75. WIRE HARNESS MAST LIGHT EXTENSION
73.76. WIRE HARNESS MAST WORK LIGHT
73.77. WIRE HARNESS POWERTRAIN
73.78. WIRE HARNESS PRESSURE SWITCH BASE
73.79. WIRE HARNESS PUMP BASE TRUCK
73.80. WIRE HARNESS REAR
73.81. WIRE HARNESS SMART ANTENNA
73.82. WIRE HARNESS STEER COLUMN
73.83. WIRE HARNESS VAM
73.84. WIRE HARNESS WASHER PUMP
73.85. WIRE HARNESS WITHOUT TELEMETRY HARNESS – AMBIENT TEMPERATURE
73.86. ALTERNATOR AND MOUNTING
73.87. ENGINE CONTROL MODULE
73.88. ENGINE GROUND
73.89. ETR CONTROL MODULE WIRE HARNESS
73.90. AMBIENT AIR TEMPERATURE SENSOR
73.91. CAB RADIO GROUP
73.92. CAB RADIO PREPARATION GROUP
73.93. CAB RADIO PREPARATION GROUP ALTERNATE CONFIGURATION
73.94. FUSE BOX PDM1 W/O CIRCUIT BREAKERS
73.95. FUSE BOX PDM2 W/O CIRCUIT BREAKERS
73.96. FUSE BOX PDM1 W/ CIRCUIT BREAKERS
73.97. FUSE BOX PDM2 W/ CIRCUIT BREAKERS
73.98. FUSE BOARD CABIN W/O CIRCUIT BREAKERS
73.99. FUSE BOARD CABIN W/ CIRCUIT BREAKERS
73.100. WIRE HARNESS SECOND SOCKET
74. TRANSMISSION
74.1. CONVERTER
74.2. DRIVE TRAIN
74.3. PRESSURE OIL PUMP
74.4. POWER TAKE-OFF
74.5. ENGINE CONNECTION
74.6. TRANSMISSION HOUSING PAGE 1 OF 2
74.7. TRANSMISSION HOUSING PAGE 2 OF 2
74.8. PRESSURE FILTER
74.9. TRANSMISSION SENSORS
74.10. OIL DIPSTICK COVERS
74.11. FIRST SPEED CLUTCH ASSEMBLY
74.12. SECOND SPEED CLUTCH ASSEMBLY
74.13. THIRD SPEED CLUTCH ASSEMBLY
74.14. FORWARD CLUTCH ASSEMBLY
74.15. REVERSE CLUTCH ASSEMBLY
74.16. OUTPUT FLANGE
74.17. CONTROL VALVE PAGE 1 OF 4
74.18. CONTROL VALVE PAGE 2 OF 4
74.19. CONTROL VALVE PAGE 3 OF 4
74.20. CONTROL VALVE PAGE 4 OF 4
74.21. PRESSURE REGULATOR
74.22. UNIVERSAL SHAFT
74.23. TRANSMISSION HOSES AND ATTACHING PARTS
75. Drive Axle
75.1. DRIVE AXLE ATTACHING PARTS
75.2. DRIVE AXLE ASSEMBLY BRAKE
75.3. DRIVE AXLE ASSEMBLY PLANETARY GEAR DRIVE
75.4. DRIVE AXLE ASSEMBLY HUB
75.5. DRIVE AXLE ASSEMBLY PARK BRAKE RETAINER
75.6. DRIVE AXLE ASSEMBLY PARK BRAKE
75.7. DRIVE AXLE ASSEMBLY DIFFERENTIAL AND CARRIER
75.8. DRIVE TIRE AND WHEEL TUBELESS PNEUMATIC
75.9. DRIVE TIRE AND WHEEL TUBED PNEUMATIC
76. STEERING SYSTEM
76.1. STEER COLUMN AND VALVE
76.2. STEER COLUMN ASSEMBLY
76.3. TURN SIGNAL LEVER
76.4. GEAR SELECTION LEVER
76.5. STEER AXLE ASSEMBLY
76.6. STEER CYLINDER
76.7. STEER HOSES
76.8. STEER TIRE AND WHEEL TUBELESS PNEUMATIC
76.9. STEER TIRE AND WHEEL TUBED PNEUMATIC
77. BRAKE SYSTEM
77.1. BRAKE ACCUMULATOR AND ATTACHING PARTS
77.2. HIGH PRESSURE HYDRAULIC FILTER AND GEAR PUMP AND ATTACHING BRAKE HOSES
77.3. HYDRAULIC CONTROL VALVE AND ATTACHING BRAKE HOSES
77.4. BRAKE VALVE AND ATTACHING HOSES
77.5. BRAKE VALVE AND INCHING PEDAL AND BRAKE PEDAL
77.6. BRAKE VALVE AND INCHING PEDAL ASSEMBLY
77.7. BRAKE MANIFOLD AND ATTACHING HOSES
78. HYDRAULIC SYSTEM
78.1. AUTOMATIC GREASING SYSTEM STEER AXLE GREASING
78.2. AUTOMATIC GREASING SYSTEM STEER AXLE GREASING – ALTERNATE CONFIGURATION
78.3. AUTOMATIC GREASING SYSTEM MAIN LINES
78.4. AUTOMATIC GREASING SYSTEM FRONT SIDE AND MAST – PAGE 1 OF 2
78.5. AUTOMATIC GREASING SYSTEM FRONT SIDE AND MAST – PAGE 2 OF 2
78.6. BLOCK ASSEMBLY AND HOSES, TWIN 12-PORT WITH METERING UNIT NUMBER 1
78.7. BLOCK ASSEMBLY AND HOSES, TWIN 7-PORT WITH METERING UNITS NUMBER 3 AND 8
78.8. AUTOMATIC GREASING PUMP PAGE 1 OF 2
78.9. AUTOMATIC GREASING PUMP PAGE 2 OF 2
78.10. HYDRAULIC LEVERS TWO-LEVER CONTROL PANEL
78.11. HYDRAULIC LEVERS THREE-LEVER CONTROL PANEL
78.12. HYDRAULIC LEVERS FOUR-LEVER CONTROL PANEL
78.13. HYDRAULIC LEVERS LABELS
78.14. HYDRAULIC PUMPS AND HOSES
78.15. HYDRAULIC SUPPLY AND RETURN WITH LIFT ACCUMULATOR
78.16. HYDRAULIC SUPPLY AND RETURN WITHOUT LIFT ACCUMULATOR
78.17. HYDRAULIC SUPPLY AND RETURN THREE FUNCTION
78.18. HYDRAULIC SUPPLY AND RETURN FOUR, FIVE, AND SIX FUNCTION
78.19. HYDRAULIC TANK
78.20. MAIN HYDRAULIC CONTROL VALVE ASSEMBLY
78.21. MAIN HYDRAULIC CONTROL VALVE ASSEMBLY ALTERNATE ASSEMBLY

Rate this product
