Komatsu 980E-5 Dump Truck Field Assembly Instruction CEAW013501

Komatsu 980E-5 Dump Truck Field Assembly Instruction CEAW013501 - Image 2

Komatsu 980E-5 Dump Truck Field Assembly Instruction CEAW013501 - Image 3

Komatsu 980E-5 Dump Truck Field Assembly Instruction CEAW013501 - Image 4

Komatsu 980E-5 Dump Truck Field Assembly Instruction CEAW013501 - Image 5

komatsu 980e 5 dump truck field assembly instruction ceaw013501 2

komatsu 980e 5 dump truck field assembly instruction ceaw013501 3

Komatsu 980E-5 Dump Truck Field Assembly Instruction CEAW013501

$20.00

Type Of Manual: Field Assembly Instruction
Manual ID: CEAW013501
Format: PDF
Size: 24.3MB
Number of Pages: 416

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- 980E-5 Dump Truck

1. COVER
2. FOREWORD
3. TABLE OF CONTENTS
4. SAFETY RULES, TOOLS EQUIPMENT
5. TRUCK COMPONENTS AND SPECIFICATIONS
6. MAJOR COMPONENT WEIGHTS
7. FIELD WELDING FOR ASSEMBLY OR REPAIR
8. RECEIVING ASSEMBLY PREPARATION
9. CHASSIS ASSEMBLY
10. DUMP BODY ASSEMBLY
11. FINAL ASSEMBLY
12. FINAL CHECKOUT
13. APPENDIX
13.1. STANDARD TORQUE CHARTS AND CONVERSION TABLES
13.2. SUSPENSION OILING AND CHARGING PROCEDURES
13.3. SUSPENSION OILING AND CHARGING BLOCK KIT INSTALLATION PROCEDURE
13.4. OILING AND CHARGING SPECIFICATION CHART
13.5. ENGINE EMISSIONS AFTERTREATMENT SYSTEMS (IF EQUIPPED)
13.6. TOEIN ADJUSTMENT PROCEDURE
13.7. PRESHIFT BRAKE TEST TEST PROCEDURE
13.8. PARKING BRAKE BLEEDING/FLUSHING PROCEDURE
13.9. ALTERNATOR LOCK CHECKOUT PROCEDURE
13.10. INTERFACE MODULE CHECKOUT PROCEDURE
13.11. ADDITIONAL ELECTRICAL CHECKOUT FOR TRUCKS WITH IM CONTROLS
13.12. AUTOMATIC LUBRICATION SYSTEM CHECKOUT PROCEDURE
13.13. AUTOMATIC LUBRICATION SYSTEM
13.14. AUTOMATIC LUBRICATION SYSTEM PRIMING
13.15. AIR CONDITIONING SYSTEM CHECKOUT PROCEDURE
13.16. TIRE MONITORING SYSTEM CHECKOUT PROCEDURE
13.17. HYDRAULIC SYSTEM CHECKOUT PROCEDURE
13.18. BRAKE SYSTEM CHECKOUT PROCEDURE
13.19. KOMTRAX PLUS 2 SHOP SETUP CHECKOUT PROCEDURE
13.20. KOMTRAX PLUS 2 SITE SETUP CHECKOUT PROCEDURE
13.21. PAYLOAD METER IV CHECKOUT PROCEDURE
13.22. ELECTRIC CHECKOUT PROCEDURE
13.23. KOMVISION CHECKOUT PROCEDURE
13.24. KOMATSU WIRELESS BRIDGE CHECKOUT PROCEDURE
13.25. RETRACTABLE LADDER SYSTEM CHECKOUT PROCEDURE
13.26. SEAT BELTS AND TETHERS CHECKOUT PROCEDURE
13.27. FIELD ASSEMBLY INSPECTION REPORT
13.28. HOUR POSTCOMMISSIONING CHECKSHEET
