Komatsu D375A-6 Bull Dozer Field Assembly Instruction GEN00097-05

$20.00

Type Of Manual: Field Assembly Instruction
Manual ID: GEN00097-05
Format: PDF
Size: 11.6MB
Number of Pages: 228

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- D375A-6 Bull Dozer

1. Cover
2. Preface
3. CONTENTS
4. Specifications
5. Precautions for field assembly
6. Disposal of removed parts
7. Assembly procedure, necessary equipment, and schedule
8. Layout of kit
9. Style for transportation
10. Table of tools for field assembly
11. Tightening torque
12. Coating materials list
13. Selection of wire ropes used for assembly
14. Assembly
14.1. A1 Installation of chassis
14.2. A2 Installation of undercover
14.3. A3 Installation of pivot shaft
14.4. A4 Installation of undercarriage
14.5. A5 Adding oil to recoil chamber and pivot chamber
14.6. A6.1 Installation of engine air inlet hood
14.7. A6.2 Installation of engine air precleaner (if equipped)
14.8. A7 Installing direction of exhaust pipe
14.9. A8 Installation of blade lift cylinder
14.10. A9 Installation of ripper
14.11. A10 Installation of track
14.12. A11 Assembly of blade
14.13. A12 Installation of blade
14.14. A13 Installation of operators cab
14.15. A14 Installation of rear monitor camera (if equipped)
14.16. A15 Installation of additional cab lights (if equipped)
14.17. A16 Installation of ROPS
14.18. A17 Installation of VHMS, ORBCOMM antenna
14.19. A18 Installation of revolving warning lamp to top of ROPS (if equipped)
14.20. A19 Check track tension
14.21. A20 Check fuel, coolant and lubricants
14.22. A21 Bleeding air from hydraulic cylinders
14.23. A22 Lubricating
14.24. A23 Installation of fuel quick charge piping (if equipped)
15. Check and maintenance procedures after completion of assembly
15.1. M1 Check and adjustment of operators cab
15.2. M2 Inspection of machine monitor
15.3. M3 Checking operation of dual tilt mechanism (If equipped)
15.4. M4 Setting procedure for USER ADJUST MODE
15.5. M5 Setting procedure for maximum cooling fan speed
15.6. M6 Replacement of return filter (Replacement of standard filter > special flushing parts)
15.7. M7 Flushing of hydraulic circuit, and bleeding air from hydraulic cylinders (Part 1)
15.8. M8 Replacement of return filter (Replacement of special flushing parts > standard filter)
15.9. M9 Bleeding air from hydraulic cylinders (Part 2)
16. APPENDIX 1. Installation procedure for spill guard (Installation by welding)
17. APPENDIX 2. Precautions for initialization procedures for VHMS controller
18. Field assembly inspection report
