Komatsu FR18S-2A, FR23S-2A, FR15DR-2A Forklift Truck Service Manual

Komatsu FR18S-2A, FR23S-2A, FR15DR-2A Forklift Truck Service Manual - Image 2

Komatsu FR18S-2A, FR23S-2A, FR15DR-2A Forklift Truck Service Manual - Image 3

Komatsu FR18S-2A, FR23S-2A, FR15DR-2A Forklift Truck Service Manual - Image 4

Komatsu FR18S-2A, FR23S-2A, FR15DR-2A Forklift Truck Service Manual - Image 5

komatsu fr18s 2a fr23s 2a fr15dr 2a forklift truck service manual 2

komatsu fr18s 2a fr23s 2a fr15dr 2a forklift truck service manual 3

Komatsu FR18S-2A, FR23S-2A, FR15DR-2A Forklift Truck Service Manual

$30.00

Type Of Manual: Service Manual
Format: PDF
Size: 13.3MB
Number of Pages: 564

Category: Komatsu Service Manual PDF

Model List:
- FR18S-2A Forklift Truck
- FR23S-2A Forklift Truck
- FR15DR-2A Forklift Truck

1. BTINTRO
1.1. Introduction, Service Manual
1.2. Contents, Section M
1.3. General Product Information
1.4. Inch (SAE) and Metric Fasteners
2. BTBATTER
2.1. Battery
2.2. Light Assemblies
2.3. Horn
2.4. Start/Stop Switches
2.5. Battery Connector
2.6. Mast Switch (S31)
3. BTCYLIND
3.1. Staging Cylinder, Three Stage Mast
3.2. Freelift Cylinder, Three Stage Mast
3.3. Reach Cylinder Assembly
3.4. Tilt Cylinder Assembly, FR18S2A
3.5. Tilt Cylinder Assembly, FR23S2A/FR15DR2A
4. BTDECALS
4.1. Decals
5. BTDRIVER
5.1. Driver Controls
5.2. Brake Pedal, FR18S2A
5.3. Brake Pedal, FR23S2A/ FRD15DR2A
6. BTELECT
6.1. Electromagnetic Brake
6.2. Drive Wheel
6.3. NonBraking Caster Wheel, FR18S2A
6.4. NonBraking Caster Assembly, FR18S2A
6.5. Braking Caster Wheel, FR23S2A/ FR15DR2A
6.6. Braking Caster Assembly, FR23S2A/ FR15DR2A
6.7. Load Wheels, Sizes 4 X 3, 5 X 4, and 5 X 3
6.8. Load Wheels, Size 10.5 X 3.5
6.9. Steering Arm / Wheel / Lever
6.10. Steering Bearing
7. BTELESC1
7.1. Electrical Schematics (Serial Numbers 27163__000 28105__000)
8. BTELESC2
8.1. Electrical Schematics (Serial Numbers 28105__00128126__000)
9. BTELESC3
9.1. Electrical Schematics (Serial Numbers 28126__001 31285__000)
10. BTELESC4
10.1. Electrical Schematics (Serial numbers 31285__001Up)
11. BTELFUNC
11.1. Electrical Functions
11.2. Electrical Symbols
12. BTELSYS
12.1. Control Cable and Harness
12.2. Contactors
12.3. Transistor Panel (Drive)
12.4. Transistor Panel (Lift)
12.5. Micro Switches
12.6. Main Electronic Card
12.7. Switches and Sensors
13. BTGENSER
13.1. Contents, Section S
13.2. Troubleshooting Guidelines
13.3. Chassis
13.4. Battery Compartment
14. BTHYDRA
14.1. Hydraulic System
14.2. Hydraulic Fluid
14.3. Hydraulic Tank
14.4. Hydraulic Filter Assembly
14.5. Control Valve Assembly
15. BTMAINT
15.1. Steering Motor
15.2. Fan Motor
15.3. Motor Maintenance Schedule/Troubleshooting
15.4. Motor Repair
15.5. Pump Motor
15.6. Drive Motor
15.7. Transmission
16. BTMAST
16.1. Mast, 3 Stage
16.2. Lifting Gear (Crosshead)
16.3. Sideshifter, FR18S/23S2A, FR15DR2A
16.4. Sideshifter, FR18S/23S2A, FR15DR2A
16.5. Single Reach, FR18S2A
16.6. Single Reach, FR23S2A
16.7. Double Reach Mechanism, FR15DR2A
16.8. Forks
16.9. Load Indicator FR18S2A
16.10. Load Indicator FR23S2A/FR1 5DR2A
16.11. Height Indicator and Preset Selector
16.12. Warning Symbols
16.13. Prohibitory Symbols
17. BTTECH
17.1. Technical Service Data
17.2. Ordering Spare Parts
17.3. Contents, Section P
17.4. Introduction, Maintenance
17.5. Service Schedule
17.6. Lubrication Chart
17.7. Oil and Grease Specifications

Rate this product
