Komatsu HD785-7 Dump Truck Field Assembly Instruction GEN00058-08

$20.00

  • Type Of Manual: Field Assembly Instruction
  • Manual ID: GEN00058-08
  • Format: PDF
  • Size: 29.9MB
  • Number of Pages: 221
Category:
  • Model List:

    • HD785-7 Dump Truck
  • 1. COVER
  • 2. CONTENTS
  • 3. Outline of division (Only main components)
  • 4. Dimensions of main components
  • 5. Layout of work space
  • 6. Rough schedule of assembly and welding
  • 7. List of jigs, tools, and consumables for field assembling
  • 8. Assembly process
  • 9. Adjustment procedure
  • 10. Welding procedure
  • 11. Appendix
