Komatsu HD785-7 Dump Truck Field Assembly Instruction GEN00223-04

Type Of Manual: Field Assembly Instruction
Manual ID: GEN00223-04
Format: PDF
Size: 9.2MB
Number of Pages: 55

Name: Komatsu HD785-7 Dump Truck Field Assembly Instruction GEN00223-04
Price: 20.00 USD
Availability: InStock

$20.00

1. COVER
2. FOREWORD
3. CONTENTS
4. OUTLINE OF THE WORK PART
5. REMOVAL
5.1. Removal of cab rear cover
5.2. Removal of trainer seat bracket
5.3. Removal of covers and ducts
6. INSTALLATION AND REPLACEMENT
6.1. Replacement of KOMTRAX Plus controller and retarder controller
6.2. Replacement of retarder controller (European specifications)
6.3. Installation and wiring of translator controller
6.4. Installation of drowsiness alarm buzzer
6.5. Replacement of machine monitor and bracket
6.6. Wiring inside of front dash cover
6.7. Assembly of drowsiness detection camera
6.8. Wiring of drowsiness detection camera harness and drowsiness detection system harness
6.9. Wiring inside of rear cover
6.10. Installation of side cover and trainer seat bracket
6.11. Installation of driver status monitor
6.12. Installation of duct and dash cover
6.13. Installation of drowsiness detection camera
6.14. Installation of cab rear cover
7. SETTINGS
7.1. Set optional selection of machine monitor
7.2. Set driver status monitor
