Komatsu PC130-8 Hydraulic Excavator Operation and Maintenance Manual UEAM007307

$20.00

Type Of Manual: Operation and Maintenance Manual
Manual ID: UEAM007307
Format: PDF
Size: 13.3MB
Number of Pages: 444

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- PC130-8 Hydraulic Excavator

1. FOREWORD
1.1. FOREWORD
1.2. SAFETY INFORMATION
1.2.1. NOISE
1.2.2. VIBRATION LEVELS
1.3. INTRODUCTION
1.3.1. DIRECTIONS OF MACHINE
1.3.2. OPERATOR PROTECTIVE STRUCTURE
1.3.3. VISIBILITY FOR OPERATOR
1.3.4. BREAKINGIN THE NEW MACHINE
1.4. PRODUCT INFORMATION
1.4.1. PRODUCT IDENTIFICATION NUMBER (PIN)/MACHINE SERIAL NO. PLATE
1.4.2. EPA REGULATIONS, ENGINE NUMBER PLATE
1.4.3. SERVICE METER LOCATION
1.4.4. MACHINE SERIAL NUMBER PLATE
1.4.5. DECLARATION OF CONFORMITY
1.4.6. ATTACHMENTS AND OPTIONS
1.4.7. LOCATION OF SAFETY LABELS
1.4.8. SAFETY LABELS
1.5. GENERAL PRECAUTIONS
1.5.1. PRECAUTIONS RELATED TO PROTECTIVE STRUCTURES
1.5.2. PRECAUTIONS RELATED TO ATTACHMENTS AND OPTIONS
1.6. SAFETY MACHINE OPERATION
1.6.1. STARTING ENGINE
1.6.2. OPERATION
1.6.3. TRANSPORTATION
1.6.4. TURN OFF THE BATTERY DISCONNECT SWITCH TO THE OFF POSITION
1.6.5. BATTERY
1.6.6. TOWING
1.6.7. LIFTING OBJECTS WITH BUCKET LINK LIFTING DEVICE (OPTIONAL EQUIPMENT)
1.6.8. LIFTING OBJECTS WITH BUCKET
1.7. SAFETY MAINTENANCE INFORMATION
1.7.1. STABILITY
1.7.2. GUARDS
1.7.3. END OF SERVICE LIFE
1.7.4. REMOVING BATTERY CABLES (for machines not fitted with battery disconnect switch only)
2. OPERATION
2.1. MACHINE VIEW ILLUSTRATIONS
2.1.1. OVERALL MACHINE VIEW
2.1.2. CONTROLS AND GAUGES
2.2. DETAILED CONTROLS AND GAUGES
2.2.1. MONITORING SYSTEM
2.2.2. SWITCHES
2.2.3. DIESEL PARTICULATE FILTER (DPF) MONITOR
2.2.4. CEILING WINDOW
2.2.5. WINDSHIELD
2.2.6. EMERGENCY ESCAPE HAMMER
2.2.7. AIR CONDITIONER CONTROLS
2.2.8. BATTERY DISCONNECT SWITCH
2.2.9. RADIO
2.2.10. AUXILIARY ELECTRIC POWER
2.2.11. FUSE
2.2.12. FUSIBLE LINK
2.2.13. CONTROLLER
2.2.14. TOOL BOX
2.2.15. GREASE PUMP HOLDER
2.2.16. FIRE EXTINGUISHER
2.2.17. REFUELLING PUMP
2.3. MACHINE OPERATIONS AND CONTROLS
2.3.1. BEFORE STARTING ENGINE
2.3.2. STARTING ENGINE
2.3.3. AFTER STARTING ENGINE
2.3.4. STOPPING THE ENGINE
2.3.5. MACHINE OPERATION
2.3.6. STEERING THE MACHINE
2.3.7. SWINGING
2.3.8. WORK EQUIPMENT CONTROLS AND OPERATIONS
2.3.9. WORKING MODE
2.3.10. PROHIBITED OPERATIONS
2.3.11. GENERAL OPERATION INFORMATION
2.3.12. TRAVELLING ON SLOPES
2.3.13. ESCAPE FROM MUD
2.3.14. RECOMMENDED APPLICATIONS
2.3.15. BUCKET REPLACEMENT AND INVERSION
2.3.16. PARKING MACHINE
2.3.17. MACHINE INSPECTION AFTER DAILY WORK
2.3.18. LOCKING
2.3.19. ROAD LINERS
2.4. TRANSPORTATION
2.4.1. TRANSPORTATION PROCEDURE
2.4.2. LOADING AND UNLOADING WITH TRAILER
2.4.3. LIFTING MACHINE
2.5. COLD WEATHER OPERATION
2.5.1. COLD WEATHER OPERATION INFORMATION
2.5.2. AFTER DAILY WORK COMPLETION
2.5.3. AFTER COLD WEATHER SEASON
2.6. LONG TERM STORAGE
2.6.1. BEFORE STORAGE
2.6.2. DURING STORAGE
2.6.3. AFTER STORAGE
2.6.4. STARTING MACHINE AFTER LONGTERM STORAGE
2.7. TROUBLES AND ACTIONS
2.7.1. RUNNING OUT OF FUEL
2.7.2. PHENOMENA THAT ARE NOT FAILURES
2.7.3. TOWING THE MACHINE
2.7.4. LIGHTWEIGHT TOWING HOLE
2.7.5. SEVERE JOB CONDITION
2.7.6. DISCHARGED BATTERY
2.7.7. OTHER TROUBLE
3. MAINTENANCE
3.1. MAINTENANCE INFORMATION
3.2. OUTLINE OF SERVICE
3.2.1. HANDLING OIL, FUEL, COOLANT, AND PERFORMING OIL CLINIC
3.2.2. ELECTRIC SYSTEM MAINTENANCE
3.3. WEAR PARTS
3.3.1. WEAR PARTS LIST
3.4. RECOMMENDED FUEL, COOLANT, AND LUBRICANT
3.4.1. RECOMMENDED BRANDS, RECOMMENDED QUALITY FOR PRODUCTS OTHER THAN KOMATSU GENUINE OIL
3.5. TIGHTENING TORQUE SPECIFICATIONS
3.5.1. TIGHTENING TORQUE LIST
3.6. SAFETY CRITICAL PARTS
3.6.1. SAFETY CRITICAL PARTS LIST
3.7. MAINTENANCE SCHEDULE
3.7.1. MAINTENANCE SCHEDULE CHART
3.7.2. MAINTENANCE INTERVAL FOR HYDRAULIC BREAKER
3.8. MAINTENANCE PROCEDURE
3.8.1. WHEN REQUIRED
3.8.2. CHECK BEFORE STARTING
3.8.3. EVERY 100 HOURS MAINTENANCE
3.8.4. EVERY 250 HOURS MAINTENANCE
3.8.5. EVERY 500 HOURS MAINTENANCE
3.8.6. EVERY 1000 HOURS MAINTENANCE
3.8.7. EVERY 2000 HOURS MAINTENANCE
3.8.8. EVERY 4000 HOURS MAINTENANCE
3.8.9. EVERY 5000 HOURS MAINTENANCE
3.8.10. EVERY 8000 HOURS MAINTENANCE
3.9. END OF SERVICE LIFE
4. SPECIFICATIONS
4.1. SPECIFICATIONS
4.1.1. PC1308 MONO BOOM WORKING RANGE
4.1.2. PC1308 WORKING RANGE (2PC BOOM)
4.1.3. EXPLANATION OF LIFTING CAPACITY CHART (PC1308 1PC BOOM)
4.1.4. EXPLANATION OF LIFTING CAPACITY CHART (PC1308 2PC BOOM)
5. ATTACHMENTS AND OPTIONS
5.1. ATTACHMENTS AND OPTIONS GENERAL INFORMATION
5.1.1. SAFETY FIRST
5.1.2. ATTACHMENT INSTALLATION
5.2. BUCKET WITH HOOK
5.2.1. HOOK CONDITION
5.2.2. PROHIBITED OPERATIONS
5.2.3. ARM/PIN INFORMATION PC1308
5.3. HYDRAULIC QUICK COUPLER PIPING
5.3.1. LOCATIONS
5.3.2. OPERATION
5.4. MACHINE READY FOR ATTACHMENT
5.4.1. LOCATIONS
5.4.2. HYDRAULIC CIRCUIT
5.4.3. ATTACHMENT REMOVAL AND INSTALLATION
5.4.4. ATTACHMENT OPERATIONS
5.4.5. LONG TERM STORAGE
5.4.6. SPECIFICATIONS
5.5. ATTACHMENT GUIDE
5.5.1. ATTACHMENT COMBINATIONS
5.5.2. TRACK SHOES SELECTION
5.5.3. HANDLING OF RUBBER PAD SHOE AND ROAD LINER
5.6. RECOMMENDED ATTACHMENT OPERATIONS
5.6.1. HYDRAULIC BREAKER
5.7. PC1308 2PC BOOM
5.7.1. FEATURES OF 2PIECE BOOM ARM
5.7.2. OPERATION
5.7.3. TRANSPORTATION
5.7.4. LUBRICATING
5.8. SUPER LONG FRONT BOOM AND ARM
5.8.1. OPERATION INSTRUCTION
5.8.2. WORKING MODES
5.8.3. CHECKS BEFORE STARTING
5.8.4. USING SUPER LONG FRONT
5.8.5. METHOD OF WORK
5.8.6. CONTROL LEVERS, PEDALS
5.8.7. MACHINE OPERATION
5.8.8. TRANSPORT STORAGE OF SUPER LONG FRONT MACHINE
5.8.9. TRANSPORTATION OF SUPER LONG FRONT MACHINE
5.8.10. WORKING RANGE OF SUPER LONG FRONT
5.8.11. LIFTING CAPACITY PC130 SUPER LONG FRONT
5.8.12. MAINTENANCE
5.8.13. LUBRICATING
5.9. HANDLING MACHINES EQUIPPED WITH KOMTRAX
5.9.1. BASIC PRECAUTIONS
