Komatsu PC30MR-3 Hydraulic Excavator Parts Manual FENC0024-03

$30.00

Type Of Manual: Parts Manual
Manual ID: FENC0024-03
Format: PDF
Size: 46.8MB
Number of Pages: 416

Category: Komatsu Parts Manual PDF

Model List:
- PC30MR-3 Hydraulic Excavator

1. COVER
2. FOREWORD
3. CONTENTS
4. ENGINE UNIT
4.1. A0000001001 Engine (Cylinder Block)
4.2. A0000001002 Engine (Front Cover)
4.3. A0000001003 Engine (Flywheel Housing and Oil Pan)
4.4. A0000001004 Engine (Cylinder Head)
4.5. A0000001005 Engine (Air Intake Manifold and Piping)
4.6. A0000001006 Engine (Exhaust Manifold and Muffler)
4.7. A0000001007 Engine (Camshaft and Idle Gearshaft)
4.8. A0000001008 Engine (Crankshaft and Piston)
4.9. A0000001009 Engine (Lubricating Oil Pump and Oil Filter)
4.10. A0000001010 Engine (Water Pump and Fan)
4.11. A0000001011 Engine (Inner Parts, Injection Pump)
4.12. A0000001012 Engine (Inner Parts, Governor)
4.13. A0000001013 Engine (Fuel Nozzle and Spill Hose)
4.14. A0000001014 Engine (Fuel Filter and Piping)
4.15. A0000001015 Engine (Water Separator)
4.16. A0000001016 Engine (Inner Parts, Starting Motor)
4.17. A0000001017 Engine (Inner Parts, Alternator)
4.18. A0000001018 Engine (Gasket Kit and Tool)
4.19. A0000001019 Engine (Special Tool)
5. ENGINE RELATED PARTS
5.1. A0100 Engine (For ROPS Canopy) (Mounting)
5.2. A0100 Engine (With Air Conditioner, For ROPS Cab) (Mounting)
5.3. B0100 Engine Mounting
5.4. B0300 Air Cleaner (Double Element)
6. COOLING SYSTEM
6.1. C0100 Cooling System (Without Air Conditioner) (Radiator and Oil Cooler)
6.2. C0100 Cooling System (With Air Conditioner) (Radiator and Oil Cooler)
7. FUEL SYSTEM
7.1. D0100 Fuel Tank (Fuel Tank Related Parts)
8. ELECTRICAL SYSTEM
8.1. E0100 Battery
8.2. E0200 Electric Wiring Harness (For ROPS Cab)
8.3. E0201 KOMTRAX Controller and Wiring Harness (For KOMTRAX, GPRS)
8.4. E0300 Headlamp (For ROPS Cab) (1/2)
8.5. E0300 Front Working Lamp (For ROPS Canopy)
8.6. E0340 Beacon Lamp (For ROPS Canopy)
8.7. E0340 Beacon Lamp (For ROPS Cab)
8.8. E0340 Beacon Lamp (For ROPS Canopy)
8.9. E0340 Beacon Lamp (For ROPS Cab)
8.10. E0420 Travel Alarm
9. HYDRAULIC SYSTEM
9.1. H0110 Hydraulic Tank
9.2. H0120 Control Valve (1Additional Actuator Piping, For ROPS Cab) (9Valve, 1/12)
9.3. H0120 Control Valve (1Additional Actuator Piping, For ROPS Canopy) (9Valve, 1/12)
9.4. H0311 Suction Piping, C60001C60228
9.5. H0312 Delivery Piping
9.6. H0330 Return Piping
9.7. H0340 Drain Piping
9.8. H1100 Actuator Piping (1Additional Actuator Piping) (Travel and Blade)
9.9. H1835 Proportional Pressure Control (PPC) Piping Joint
10. FRAME AND ITS RELATED PARTS
10.1. J1110 Revolving Frame
10.2. J1210 Boom Swing Bracket
10.3. J1210 Boom Swing Bracket
10.4. J1220 Boom Swing Cylinder (Inner Parts, Boom Swing Cylinder)
10.5. J1410 Swing Circle Lubrication
11. OPERATORS COMPARTMENT AND CONTROL SYSTEM
11.1. K0110 Operators Seat (Operators Seat, Rigid Type, Reclining)
11.2. K0160 Seat Belt (For 50mm Seat Belt, 2Point Type, Rigid Type Operators Seat)
11.3. K0210 Cab (1Additional Actuator Piping, With Air Conditioner) (Cab Body and Window)
11.4. K0210 Cab With Beacon Lamp (Floor, Console, L.H., C60001C60213)
11.5. K0310 Floor Mat (With 1Additional Actuator Piping, For ROPS Cab)
11.6. K0310 Floor Mat (For 1Additional Actuator Piping, Plastic Top Canopy)
11.7. K0350 Window Washer
11.8. K0410 Canopy (For ROPS Canopy)
11.9. K0700 Air Conditioner Unit (With Air Conditioner, For ROPS Cab)
11.10. K0810 Radio (MP3)
11.11. K1110 Floor Frame (Floor, Base)
11.12. K1110 Floor Frame With Beacon Lamp (Floor, Console, L.H., C60001C60213)
11.13. K1120 Floor Mounting (For ROPS Cab) (Gas Springs Related Parts)
11.14. K1120 Floor Mounting (For ROPS Canopy) (Gas Springs Related Parts)
12. GUARDS AND COVERS
12.1. M1110 Hood
12.2. M1130 Left Side Cover (For ROPS Cab)
12.3. M1130 Left Side Cover (For ROPS Canopy)
12.4. M1140 Right Side Cover (With Air Conditioner, For ROPS Cab) (Cover, 1/2)
12.5. M1140 Right Side Cover (For ROPS Canopy) (Cover, 1/2)
12.6. M1230 Front Cover
12.7. M1510 Counterweight, 378 Kg.
12.8. M1810 Under Cover (With Air Conditioner)
13. SWING CIRCLE AND ITS RELATED PARTS
13.1. N1200 Swing Machinery and Motor (Swing Machinery)
14. UNDERCARRIAGE
14.1. R0500 Track Shoe Assembly (Holed Double Grouser Shoe, 300mm Width) (Idler Cushion)
14.2. R0500 Track Shoe Assembly (Holed Double Grouser Shoe, 300mm Width,For City Pad) (Idler Cushion)
14.3. R1100 Track Frame (For Travel Speed Control, 2 Speed Type) (Swing Circle)
15. WORK EQUIPMENT
15.1. T1110 Boom (2285mm Boom, 1Attachment) (Boom and Piping)
15.2. T1120 Boom Cylinder (For 2285mm Boom) (Inner Parts, Boom Cylinder)
15.3. T1200 Arm (1240mm, 1Attachment) (Arm and Bushing)
15.4. T1200 Arm, 1240mm, 1Attachment Cover (Arm and Bushing)
15.5. T1235 Bucket Pin
15.6. T1235 Bucket Pin
15.7. T1510 Bucket (Heap 0.09m3, 500mm Width, With Side Cutter, Hook), C60001C60206
15.8. T1710 Blade
15.9. T1720 Blade Cylinder (Inner Parts, Blade Lift Cylinder)
16. MARKS AND PLATES
16.1. U0100 Marks and Plates (For ROPS Canopy, English)
16.2. U0100 Marks and Plates (For ROPS Cab, English)
16.3. U0100 Marks and Plates (For ROPS Canopy, Thai)
16.4. U0100 Marks and Plates (For ROPS Cab, Thai)
16.5. U0300 Lever Shift Pattern, English
17. AUXILIARY PARTS AND TOOL
17.1. V0100 Spare Part
17.2. V0300 General Tool Set (For Tool Kit)
18. FIELD REPAIR SERVICE PARTS
18.1. KIT Service Kit Parts
19. NUMERICAL INDEX
