Komatsu PC400LC-7E0 Hydraulic Excavator Shop Manual CEBM016902

$40.00

Type Of Manual: Shop Manual
Manual ID: CEBM016902
Format: PDF
Size: 35.5MB
Number of Pages: 873

Category: Komatsu Shop Manual PDF

Model List:
- PC400LC-7E0 Hydraulic Excavator

1. GENERAL
1.1. SPECIFICATIONS
1.2. WEIGHT TABLE
1.3. FUEL COOLANT AND LUBRICANTS
2. STRUCTURE AND FUNCTION
2.1. ENGINE AND COOLING SYSTEM
2.2. POWER TRAIN
2.3. UNDERCARRIAGE AND FRAME
2.4. HYDRAULIC SYSTEM
2.5. WORK EQUIPMENT
2.6. AIR CONDITIONER PIPING
2.7. ELECTRICAL SYSTEM
2.8. ELECTRONIC CONTROL SYSTEM
2.9. MONITOR SYSTEM
3. TESTING, ADJUSTING AND TROUBLESHOOTING
3.1. STANDARD VALUE TABLES
3.2. TESTING AND ADJUSTING
3.3. TROUBLESHOOTING GENERAL
3.4. TROUBLESHOOTING ERROR CODES AND FAILURE CODES
3.5. TROUBLESHOOTING OF ELECTRICAL SYSTEM (EMODE)
3.6. TROUBLESHOOTING OF HYDRAULIC AND MECHANICAL SYSTEMS (HMODE)
4. DISASSEMBLY AND ASSEMBLY
4.1. HOW TO READ THIS MANUAL
4.2. PRECAUTIONS DURING OPERATION
4.3. SPECIAL TOOL LIST
4.4. CONNECTOR REPAIR PROCEDURES
4.5. ENGINE
4.6. RADIATOR ASSEMBLY
4.7. HYDRAULIC OIL COOLER ASSEMBLY
4.8. AFTERCOOLER ASSEMBLY
4.9. ENGINE AND HYDRAULIC OIL PUMP ASSEMBLY
4.10. FINAL DRIVE ASSEMBLY
4.11. FINAL DRIVE ASSEMBLY
4.12. SWING MOTOR AND SWING MACHINERY
4.13. SWING MOTOR AND SWING MACHINERY
4.14. SWING CIRCLE ASSEMBLY
4.15. UNDERCARRIAGE AND FRAME
4.16. TRACK ROLLER ASSEMBLY
4.17. IDLER ASSEMBLY
4.18. RECOIL SPRING ASSEMBLY
4.19. SPROCKET
4.20. TRACK SHOE ASSEMBLY
4.21. REVOLVING FRAME ASSEMBLY
4.22. COUNTERWEIGHT ASSEMBLY
4.23. CENTER SWIVEL JOINT ASSEMBLY
4.24. HYDRAULIC TANK ASSEMBLY
4.25. CONTROL VALVE ASSEMBLY
4.26. HYDRAULIC PUMP ASSEMBLY
4.27. HYDRAULIC PUMP INPUT SHAFT
4.28. WORK EQUIPMENT PPC VALVE ASSEMBLY
4.29. TRAVEL PPC VALVE ASSEMBLY
4.30. HYDRAULIC CYLINDER ASSEMBLY
4.31. WORK EQUIPMENT ASSEMBLY
4.33. CAB GLASS (STUCK GLASS)
4.34. WINDOW ASSEMBLY
4.35. AIR CONDITIONER UNIT ASSEMBLY
4.36. KOMTRAX TERMINAL ASSEMBLY
4.37. MONITOR ASSEMBLY
4.38. PUMP CONTROLLER
5. OTHERS
5.1. REMOVAL
5.2. HYDRAULIC
5.3. ELECTRICAL
