Komatsu PC600-8R1, PC600LC-8R1, PC700LC-8R Hydraulic Excavator Field Assembly Instruction GEN00103-01

$20.00

Type Of Manual: Field Assembly Instruction
Manual ID: GEN00103-01
Format: PDF
Size: 15.6MB
Number of Pages: 191

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- PC600-8R1 Hydraulic Excavator
- PC600LC-8R1 Hydraulic Excavator
- PC700LC-8R Hydraulic Excavator

1. COVER
2. FOREWORD
3. CONTENTS
4. SPECIFICATIONS
5. PRECAUTIONS FOR FIELD ASSEMBLY
6. DISPOSAL OF REMOVED PARTS
7. ASSEMBLING PROCEDURES, APPLICABLE EQUIPMENT AND SCHEDULE
8. KIT LAYOUT DIAGRAM
9. TRANSPORTATION
10. LIST OF TOOLS FOR FIELD ASSEMBLING
11. TIGHTENING TORQUE
12. COATING MATERIALS
13. SELECTION OF WIRE ROPES USED FOR ASSEMBLY
14. ASSEMBLY OF CHASSIS
14.1. A 1. Installation of Left and Right Track Frames
14.2. A 2. Installation of Travel Pipe
14.3. A 3. Installation of Operator Cabs Left Handrail
14.4. A 4. Installation of Operator Cabs Door Stopper and Striker
14.5. A 5. Installation of Rearview Mirror
14.6. A 6. Installation of Handrail
14.7. A 71. Installation of Step
14.8. A 72. Installation of Step
14.9. A 8. Installation of Left Side Step
14.10. A 9. Sticking Sheet to Counterweight
14.11. A10. Installation of Rear View Camera
14.12. A11. Installation of Counterweight
14.13. A12. Installation of Step Light
14.14. A13. Bleeding of Air from Travel Motor
14.15. A141. Installation of Travel Piping Cover
14.16. A142. Installation of Travel Piping Cover
14.17. A15. Installation of Travel Motor Guard
14.18. A16. Installation of Precleaner
14.19. A17. Testing Track Shoe Tension
14.20. A18. Check Fuel, Coolant and Oil Levels
15. ASSEMBLING OF WORK EQUIPMENT
15.1. B 1. Assembly of Arm Cylinder
15.2. B 2. Connection of Arm Cylinder Hoses
15.3. B 3. Installation of Boom Cylinder
15.4. B 4. Installation of Boom Cylinder Hoses
15.5. B 5. Installation of Boom Foot Dust Seal
15.6. B 6. Assembly of Boom Assembly
15.7. B 7. Installation of Hoses from Chassis Along Top of Boom
15.8. B 8. Connection of Boom Cylinder Head
15.9. B 9. Installation of Arm Assembly
15.10. B10. Installation of Bucket Cylinder Hoses between Boom and Bucket Cylinder
15.11. B11. Installation of Bucket
15.12. B12. Connection of Work Equipment Grease Piping
15.13. B13. Connection of Work Equipment Wiring
15.14. B14. Greasing after Assembling Work Equipment
15.15. B15. Bleeding Air from Work Equipment Circuit
15.16. B16. Parts to be Touched up After Field Assembly
16. ASSEMBLING OF WORK EQUIPMENT OF LOADING SHOVEL
16.1. C 1. Releasing residual pressure in hydraulic circuit
16.2. C 2. Pulling out boom foot pin and boom cylinder foot pin
16.3. C 3. Installation of boom cylinder foot
16.4. C 4. Installation of boom and arm assembly
16.5. C 5. Installation of boom cylinder hoses
16.6. C 6. Installation of boom cylinder rod pin
16.7. C 7. Installation of boom cylinder
16.8. C 8. Installation of arm cylinder hoses
16.9. C 9. Installation of bucket cylinder
16.10. C10. Installation of bucket cylinder hoses
16.11. C11. Installation of connecting hoses between chassis and boom top
16.12. C12. Installation of bottom dump cylinder hoses
16.13. C13. Installation of bucket assembly
16.14. C14. Installation of working lamps
16.15. C15. Installation of work equipment grease piping
16.16. C16. Grease after assembling of work equipment
16.17. C17. Bleeding air from work equipment circuit
16.18. C18. Checking oil level in hydraulic tank and adding oil
17. PROCEDURE FOR INSPECTION AND MAINTENANCE AFTER COMPLETION OF ASSEMBLY
17.1. M 1. Inspection of Oil Level in Hydraulic Tank and Refill
17.2. M 2. Replacement of Return Filter (Standard Filter to Flushing Filter)
17.3. M 3. Flushing of Hydraulic Circuit
17.4. M 4. Replacement of Return Filter (Flushing Filter to Standard Filter)
17.5. M 5. Failure code
17.6. M 6. Operating Method of Monitoring
18. Field Assembly Inspection Report (Backhoe)
19. Field Assembly Inspection Report (Loading Shovel)
