Komatsu PC750-7, PC750LC-7, PC750SE-7, PC800-7, PC800SE-7 Hydraulic Excavator Field Assembly Instruction GEN00014-04

$20.00

Type Of Manual: Field Assembly Instruction
Manual ID: GEN00014-04
Format: PDF
Size: 11.7MB
Number of Pages: 160

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- PC750-7 Hydraulic Excavator
- PC750LC-7 Hydraulic Excavator
- PC750SE-7 Hydraulic Excavator
- PC800-7 Hydraulic Excavator
- PC800SE-7 Hydraulic Excavator

1. Cover
2. Foreword
3. Contents
4. Specifications
5. Precautions for Field Assembly
6. Disposal of Removed Parts
7. Assembling Procedures, Applicable Equipment and Schedule
8. Transportation
9. Packing Style for Transportation
10. List of Tools for Field Assembling
11. Tightening Torque
12. Coating Materials List
13. Assembling of Chassis
13.1. A1 Installation of Left and Right Track Frames
13.2. A2 Installation of Travel Pipe
13.3. A3 Installation of Top Guard
13.4. A4 Installation of Radiator Cover
13.5. A5 Installation of Rearview Mirror
13.6. A6 Installation of Handrail
13.7. A7 Installation of Step
13.8. A8 Installation of Left Side Step
13.9. A9 Installation of Muffler Tail Tube
13.10. A10 Sticking of Sheet (to Counterweight)
13.11. A11 Installation of Counterweight
13.12. A12 Installation of ORBCOMM Antenna (if equipped)
13.13. A13 Installation of Step Light
13.14. A14 Installation of Travel Pipe Cover
13.15. A15 Extension of Track Frame Gauge (Only when 3split packages are tansported)
13.16. A16 Testing Track Shoe Tension
13.17. A17 Inspection of Oil Amount ans Water Amount
13.18. A18 Parts to be Touched up After Field Assembly
14. Assembling of Work Equipment of Backhoe
14.1. B1 Pulling Out of Boom Foot Pin, and Boom Cylinder Foot Pin
14.2. B2 Installation of Boom Assembly
14.3. B3 Relieving Remaining Pressure from Hydraulic Circuit
14.4. B4 Installation of Boom Cylinder Foot
14.5. B5 Installation of Boom Cylinder Hose
14.6. B6 Installation of Boom Cylinder
14.7. B7 Installation of Arm Cylinder
14.8. B8 Installation of Arm Cylinder Hose
14.9. B9 Installation of Arm Assembly
14.10. B10 Installation of of Hose between Boom and Bucket Cylinder
14.11. B11 Installation of Bucket Assembly
14.12. B12 Lubrication Piping to Work Equipment
14.13. B13 Connection of Wiring of Work Equipment
14.14. B14 Greasing after Assembling Work Equipment
14.15. B15 Air Bleeding from Hydraulic Cylinder
15. Assembling of Work Equipment of Loading Shovel
15.1. C1 Releasing residual pressure in hydraulic circuit
15.2. C2 Pulling out boom foot pin and boom cylinder foot pin
15.3. C3 Installation of boom and arm assembly
15.4. C4 Installation of flushing piping between chassis and boom
15.5. C5 Installation of flushing piping for boom cylinder and arm cylinder
15.6. C6 Installation of flushing piping for bucket cylinder
15.7. C7 Installation of flushing piping for bottom dump cylinder
15.8. C8 Installation of boom cylinder
15.9. C9 Installation of boom cylinder foot
15.10. C10 Installation of boom cylinder hoses
15.11. C11 Installation of boom cylinder rod pin
15.12. C12 Installation of arm cylinder hoses
15.13. C13 Installation of bucket cylinder
15.14. C14 Installation of bucket cylinder hose
15.15. C15 Installation of connecting hoses between chassis and boom top
15.16. C16 Installation of bottom dump cylinder hose
15.17. C17 Installation of bucket assembly
15.18. C18 Installation of working lamps
15.19. C19 Installation of work equipment drease piping
15.20. C20 Greasing after assembling of work equipment
15.21. C21 Bleeding air from work equipment circuit
16. Procedure for Inspection and Maintenance after Completion of Assembly
16.1. M1 Inspection of Oil level in Hydraulic Tank and Refill
16.2. M2 Replacement of Return Filter (Standard Filter to Flushing Filter)
16.3. M3 Flushing of Hydraulic Circuit
16.4. M4 Replacement of Return Filter (Flushing Filter to Standard Filter)
17. Field Assembly Inspection Report (Backhoe)
18. Field Assembly Inspection Report (Loading Shovel)
