Komatsu WA600-3 Wheel Loader Field Assembly Manual SEAW006000

$20.00

Type Of Manual: Field Assembly Manual
Manual ID: SEAW006000
Format: PDF
Size: 0.6MB
Number of Pages: 21

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- WA600-3 Wheel Loader

1. MAIN MENU
2. COVER
3. CONTENTS
4. DRAWINGS OF UNITS DIVIDED FOR DELIVERY
5. WEIGHT AND DIMENSIONS TABLE OF UNITS DIVIDED FOR DELIVERY
6. ASSEMBLY WORK SCHEDULE
7. NECESSARY DEVICES AND TOOLS
8. ASSEMBLY PROCEDURE
8.1. INSTALLATION OF TIRE AND WHEEL ASSEMBLY
8.1.1. POSITIONING FO VEHICLE
8.1.2. REMOVAL OF AXLE STAND
8.1.3. SLINGING OF TIRE AND WHEEL ASSEMBLY
8.1.4. INSTALLATION OF TIRE AND WHEEL ASSEMBLY
8.2. INSTALLATION OF MUFFLER STACK
8.3. INSTALLATION OF CAB ASSEMBLY
8.3.1. REMOVAL OF FLOOR FRAME UNDERCOVERS
8.3.2. REMOVAL OF COVER IN CAB ASSEMBLY
8.3.3. SLINGING OF CAB ASSEMBLY
8.3.4. LOOSENING OF STEERING POST LOWER BOLT
8.3.5. OPERATION OF STEERING TILT LEVER
8.3.6. INSTALLATION OF SEAL
8.3.7. LOWERING OF CAB ASSEMBLY
8.3.8. TEMPORARY TIGHTENING OF STEERRING POST FIXING BOLTS
8.3.9. TEMPORARY TIGHTENING OF CAB ASSEMBLY MOUNTING BOLTS
8.3.10. PERMANENT TIGHTENING OF STEERING POST LOWER BOLT
8.3.11. PERMANENT TIGHTENING OF STEERING POST FIXING BOLT
8.3.12. CONNECTION OF WIRING CONNECTORS AND WASHER VINYL TUBES
8.3.13. INSTALLATION OF TROUBLESHOOTING SWITCH
8.3.14. INSTALLATION OF COVER IN CAB ASSEMBLY
8.3.15. INSTALLATION OF STEERING POST LOWER BELLOWS
8.3.16. INSTALLATION OF CAB ASSEMBLY RIGHTHAND COVER
8.3.17. INSTALLATION OF FLOOR FRAME LOWER COVER
8.3.18. INTALLATION OF MIRRORS AND MIRROR STAYS
8.4. INSTALLATION OF ROPS CANOPY
8.4.1. REMOVAL OF ANTENNA
8.4.2. REMOVAL OF REAR FRAME ROPS SUPPORT BOLTS TIGHTENED TEMPORARILY
8.4.3. SLINGING OF ROPS CANOPY
8.4.4. INSTALLATION OF ROPS CANOPY
8.4.5. INSTALLATION OF ANTENNA TO ROPS CANOPY
8.4.6. INSTALLATION OF ANTENAL WIRE HOLE GROMMET
8.5. INSTALLATION OF BUCKET
8.5.1. INSTALLATION OF CORD RING
8.5.2. ALIGHNIG OF BUCKET ASSEMBLY AND HINGE PIN HOLES
8.5.3. SELECTION OF SHIM FOR BUCKET HINGE PIN
8.5.4. INSERTION OF BUCKET HINGE PIN
8.5.5. INSTALLATION OF BUCKET HINGE PIN STOPPER
8.5.6. INSTALLATION OF BUCKET HINGE PIN AND RETAINER
8.5.7. LOWERING OF CORD RING TO GROOVE
8.5.8. INSTALLATION OF BUCKET LINK PIN
8.5.9. INSTALLATION OF GREASE NIPPLE AND PLUG
8.5.10. MEASUREMENT OF STEERING WHEEL OPERATING EFFORT
