Linde 1284-01 – E30B Production site Xiamen Spare Parts Manual

$30.00

Type Of Manual: Spare Parts Manual
Format: PDF
Size: 32.1MB
Number of Pages: 289

Category: Linde Parts Manual PDF

Model List:
- E30B

1. E30B
1.1. POWER UNIT . MOTOR
1.1.1. DRIVE MOTOR
1.1.1.1. DRIVE MOTOR 60923500504
1.1.2. LIFT MOTOR
1.1.2.1. lift motor assy. 60923500701
1.2. DRIVE TRANSMISSION
1.2.1. REDUCER ASSY
1.2.1.1. gearbox assy. Zhongnan 60832601000
1.2.1.2. gearbox assy. Zhongchai 60922601000
1.2.2. DRIVE AXLE
1.2.2.1. Drive axle 60912600003
1.2.2.1.1. WHEEL BRAKE 60913300200,60913300201
1.3. CHASSIS, BODYWORK AND FITTINGS
1.3.1. CHASSIS, OVERHEAD GUARD AND COUNTERWEIGHT
1.3.2. front plate assy.
1.3.3. battery hood assy.
1.3.4. DRIVERS SEAT
1.4. STEERING AXLE AND STEERING COMPONENTS
1.4.1. STEERING AXLE
1.4.1.1. STEERING AXLE 60924500100
1.4.1.1.1. STEERING CYLINDER 60924523600
1.4.2. STEERING AXLE 25.02.2022 and up 01.01.1999 and up
1.4.2.1. STEERING AXLE 60924500103 25.02.2022 and up
1.4.2.1.1. STEERING CYLINDER 60924523601 25.02.2022 and up
1.4.3. HYDROSTATIC STEERING
1.4.4. WHEELS AND TYRES
1.5. CONTROLS
1.5.1. BRAKE ASSY
1.5.2. ACTUATOR OF PILOT VALVE
1.5.3. PEDAL
1.5.3.1. Pedal Assembly 60915205604 up to 23.02.2023
1.5.3.2. Pedal Assembly 12845205601 24.02.2023 and up
1.6. ELECTRIC EQUIPMENT
1.6.1. Wire Harness Assembly
1.6.1.1. MAIN HARNESS 12843810511
1.6.1.2. WIRING HARNESS 60903810300
1.6.2. ELECTRIC ARMATURES
1.6.2.1. electronic control unit assy. 12843601007
1.6.3. TRUCK LIGHTING LED
1.6.3.1. headlight LED 60104801000 left
1.6.3.2. headlight LED 60104801001 right
1.6.3.3. rear light LED 60064801105
1.6.4. WARNING LIGHT
1.6.5. battery 21.07.2021 and up
1.6.6. charger 21.07.2021 and up
1.6.7. KCCU 14.07.2023 and up
1.7. HYDRAULIC UNIT
1.7.1. CONTROL VALVE AND LINES
1.7.2. HYDRAULIC PUMP,OIL TANK, FILTER AND LINES
1.7.3. HYDROSTATIC STEERING WITH LINES
1.7.4. HYDRAULIC LINES
1.7.4.1. tilt cylinder 63144901506,63144901606 6.8
1.8. MAST ASSEMBLY AND AUXILIARY HYDRAULIC SE
1.8.1. STANDARD MAST standard mast
1.8.2. pipeline standard mast
1.8.3. CHAIN and LIFT CYLINDER standard mast
1.8.3.1. lift cylinder assy. standard mast 62624902142 HH3000 29.11.2019 and up
1.8.3.2. leaf chain assy. 62624704100 HH3000 29.11.2019 and up
1.8.4. single aux. pipe standard mast
1.8.5. double aux. pipe standard mast
1.8.6. duplex mast duplex mast
1.8.7. pipeline duplex mast
1.8.8. CHAIN and LIFT CYLINDER duplex mast
1.8.8.1. lift cylinder assy. duplex mast 63134401707 HH3000 right
1.8.8.2. leaf chain assy. 62624704111 HH3000
1.8.8.3. lift cylinder assy. duplex mast 62624401780 HH3000 left
1.8.8.4. lift cylinder assy. 63134401803 HH3000
1.8.9. single aux. pipe duplex mast
1.8.10. double aux. pipe duplex mast
1.8.11. triplex mast triplex mast
1.8.12. pipeline triplex mast
1.8.13. CHAIN and LIFT CYLINDER triplex mast
1.8.13.1. leaf chain assy. 62624704100,62624704112 HH4500
1.8.13.2. lift cylinder assy. triplex mast 62624401706,62624401788 HH4500
1.8.13.3. lift cylinder assy. triplex mast 62624401834 HH4500
1.8.14. single aux. pipe triplex mast up to 27.01.2022
1.8.15. single aux. pipe triplex mast 28.01.2022 and up
1.8.16. double aux. pipe triplex mast up to 27.01.2022
1.8.17. double aux. pipe triplex mast 28.01.2022 and up
1.8.18. fork carriage standard mast
1.8.19. fork carriage duplex mast
1.8.20. fork carriage triplex mast
1.8.21. LOAD BACKREST
1.8.22. FORK
1.8.23. pipeline
1.9. SPECIAL EQUIPMENT
1.9.1. mirror
1.9.2. mirror
1.10. Miscellaneous
1.10.1. PLATES
1.10.2. nameplate lift mast 27.08.2021 and up
1.10.3. transparent tarpaulin
