Linde 140-01 – T20 EX Operating Instructions

$20.00

Type Of Manual: Operating Instructions
Format: PDF
Size: 15.6MB
Number of Pages: 182

Category: Linde Operator Manual PDF

Model List:
- T20 EX

1. Betriebsanleitung
2. Pallet truckwith drivers seatT20R Ex
2.1. Table of content
2.2. Introduction
2.2.1. Your industrial truck
2.2.2. Intended use
2.2.3. Impermissible use
2.2.4. Basic information on explosion protection
2.2.5. Description of use and climatic conditions
2.2.6. Symbols used
2.2.7. Technical description
2.2.8. Drive
2.2.9. Steering system
2.2.10. Braking
2.2.11. Lifting accessory
2.2.12. Electrical system
2.2.13. Insulation monitoring
2.2.14. Insulation monitoring warning
2.2.15. Insulation monitoring fault
2.2.16. Temperature monitoring
2.2.17. Receiving the industrial truck
2.2.18. Legal requirements for placing on the market
2.3. Safety
2.3.1. Safety regulations
2.3.2. Residual risks
2.3.3. Stability
2.3.4. If the truck tips over
2.3.5. Handling consumables
2.3.6. Qualified person
2.3.7. Regulations
2.4. Overview
2.4.1. Nameplate.adhesive label
2.4.2. Nameplate
2.4.3. Operating devices
2.4.4. Display unit
2.4.5. Indicator lights
2.5. Operation
2.5.1. Service plan before initial commissioning
2.5.2. Instructions for runningin
2.5.3. Preshift checks
2.5.4. Standard equipment
2.5.4.1. Adjusting the seat
2.5.4.2. Seat safety contact
2.5.4.3. Switching the truck on and off
2.5.4.4. Traction (dualpedal operation)
2.5.4.5. Traction (singlepedal operation)
2.5.4.6. Steering system
2.5.4.7. Brake system
2.5.4.8. Checking the industrial truck for leaks
2.5.4.9. Checking the requirement for the tyre leak resistance
2.5.4.10. Horn
2.5.4.11. Emergency off switch
2.5.5. Working with a load
2.5.5.1. Before taking up load
2.5.5.2. Picking up a load
2.5.5.3. Driving with a load
2.5.5.4. Driving on gradients
2.5.5.5. Setting down loads
2.5.6. Exiting the truck
2.5.6.1. Before exiting the truck
2.5.7. Loading.transporting
2.5.7.1. Crane loading
2.5.7.2. Transport
2.6. Servicing
2.6.1. General information
2.6.2. Inspection and maintenance data
2.6.3. Recommendations for consumables
2.6.4. Inspection and maintenance overview
2.6.4.1. Service plan after 50 hours after 3 months at the latest
2.6.4.2. Service plan every 500 hours after 6 months at the latest
2.6.4.3. Service plan every 1000 hours after a year at the latest
2.6.4.4. Service plan every 2000 hours after 2 years at the latest
2.6.5. Chassis, bodywork and fittings
2.6.5.1. Removing dust deposits
2.6.5.2. Cleaning the industrial truck
2.6.5.3. Opening the bonnet
2.6.5.4. Removing the floor
2.6.5.5. Lubricating the lifting system joints
2.6.5.6. Other cleaning and greasing
2.6.6. Chassis frame
2.6.6.1. Checking the brake system
2.6.6.2. Wheel gear Changing the oil
2.6.6.3. Checking the tyres for damage and foreign objects
2.6.6.4. Checking the wheel fastenings
2.6.7. Electrics.electronics
2.6.7.1. Battery check
2.6.7.2. Checking the battery charge status
2.6.7.3. Connecting the battery to an external battery charger
2.6.7.4. Replacing the battery
2.6.7.5. Checking the main contactor
2.6.7.6. Checking the condition and secure attachment of electric lines, cable connectors, cable connections and explosionprotected screw joints
2.6.8. Hydraulics
2.6.8.1. Checking the hydraulic oil level
2.6.8.2. Changing the hydraulic oil
2.6.9. Load lift system
2.6.9.1. Checking the load fork
2.6.10. Troubleshooting
2.6.10.1. Fuses
2.6.10.2. Diagnostic connector
2.6.10.3. Shutting down
2.6.10.4. Disposal of old trucks
2.6.10.5. Malfunctions during operation
2.7. Technical data
2.7.1. Type sheet T20 R Ex
2.7.2. Vibration characteristics
