Type Of Manual: Operation and Maintenance Manual
Manual ID: 48032414
Format: PDF
Size: 23.8MB
Number of Pages: 242
Serial Number:
48032414

Category: New Holland Operator Manual PDF

Notice: Undefined index: active_product in /usr/local/lsws/automanual.net/html/wp-content/plugins/text-to-speech-mh/public/class-text-to-speech-mh-public.php on line 115

Model List:
- 6810 Tier 3 Tractor

1. GENERAL INFORMATION
1.1. Note to the owner
1.2. Intended use
1.3. ElectroMagnetic Compatibility (EMC)
1.4. Product identification
1.5. Operators manual storage on the machine
1.6. Machine orientation
1.7. Machine components
2. SAFETY INFORMATION
2.1. Safety rules and signal word definitions
2.2. Safety rules
2.3. Ecology and the environment
2.4. Safety features
2.5. Safety signs
2.6. Informational decals
3. CONTROLS AND INSTRUMENTS
3.1. Access to operators platform
3.1.1. Proper entry and exit
3.2. Operators seat
3.2.1. Operator seat adjustments
3.2.2. Seat belt operation
3.3. Forward controls
3.3.1. Instrument panel
3.3.2. Front console
3.3.3. Foot pedals
3.3.4. Transmission controls
3.4. Lefthand side controls
3.4.1. Power TakeOff (PTO)
3.5. Righthand side controls
3.5.1. Parking brake
3.5.2. Differential lock pedal
3.5.3. Hydraulic controls
3.6. Rearward controls
3.6.1. Rear work light
3.7. Display
3.7.1. Analog/Digital Instrument Cluster (ADIC)
3.7.2. Warning and status indicators
4. OPERATING INSTRUCTIONS
4.1. Commissioning the unit
4.1.1. Run in period of a new machine
4.1.2. Multifunctional light switch
4.2. Starting the unit
4.2.1. Starting the engine
4.3. Stopping the unit
4.3.1. Stopping the tractor
4.4. Moving the unit
4.4.1. General transmission operation
4.4.2. Steering control
5. TRANSPORT OPERATIONS
5.1. Road transport
5.1.1. Basic instructions
5.1.2. High visibility position markers
5.2. Recovery transport
5.2.1. Towing the tractor
6. WORKING OPERATIONS
6.1. Tires and wheels
6.1.1. Tire load and inflation charts
6.1.2. Tractor ballasting
6.1.3. Liquid ballast
6.1.4. Front wheel tread settings
6.1.5. Rear wheel tread settings
6.2. Driveline
6.2.1. Creeper gears
6.2.2. FourWheel Drive (4WD)
6.2.3. Differential lock
6.2.4. Front axle oscillation
6.3. Hydraulic system
6.3.1. Open center remote valves
6.3.2. Closed center (Deluxe) remote valves
6.3.3. Hydraulic Power Lift (HPL)
6.3.4. Hydraulic remote control valves
6.3.5. Connecting remote cylinders
6.3.6. Bleeding remote cylinders
6.3.7. Operating singleacting hydraulic cylinders
6.3.8. Operating doubleacting hydraulic cylinders
6.3.9. Hydraulic remote control valves
6.3.10. Connecting remote cylinders
6.3.11. Bleeding remote cylinders
6.3.12. Operating singleacting hydraulic cylinders
6.3.13. Operating doubleacting hydraulic cylinders
6.3.14. Operating continuous flow hydraulic equipment
6.4. Implements
6.4.1. Adjusting the drawbar
6.4.2. Hitch operation
6.4.3. Power TakeOff (PTO) operation
7. MAINTENANCE
7.1. General information
7.1.1. Safety rules Machine service access
7.1.2. Warranty notice
7.1.3. Jacking points
7.1.4. Opening the hood
7.1.5. Fueling the machine
7.1.6. General specification Biodiesel fuels
7.1.7. Torque Minimum tightening torques for normal assembly
7.1.8. Standard torque data for hydraulics
7.1.9. Organic Acid Technology (OAT) coolant
7.1.10. Fluid capacities and lubricants
7.1.11. Engine oil Recommended engine oil for operating temperature ranges
7.2. Maintenance planning
7.2.1. Maintenance chart
7.3. Warning light on
7.3.1. Engine air filter (outer element) Clean
7.3.2. Water separator Drain fluid
7.4. Every 10 hours or daily
7.4.1. Engine oil Level make up
7.4.2. Radiator, oil cooler, and air cooler Clean
7.4.3. Engine cooling system Level make up
7.4.4. Water separator Drain fluid
7.5. First 50 hours
7.5.1. Transmission and hydraulic oil filter Replace
7.5.2. Engine oil and oil filter Change
7.6. Every 50 hours
7.6.1. Tire pressure Check
7.6.2. Transmission, rear axle, and hydraulic system oil Level make up
7.6.3. FourWheel Drive (4WD) front axle differential oil Level make up
7.6.4. FourWheel Drive (4WD) front axle hub oil Level make up
7.6.5. Fuel filter water separator Drain fluid
7.6.6. Wheel hardware Check
7.6.7. Grease points Grease
7.6.8. Clutch pedal free play Adjust
7.7. Every 300 hours
7.7.1. Transmission, rear axle, and hydraulic system oil Change fluid
7.7.2. Transmission and hydraulic oil filter Replace
7.7.3. Engine oil and oil filter Change
7.7.4. Final drive housing oil Level make up
7.7.5. Clutch pedal free play Adjust
7.7.6. Parking brake Adjust
7.7.7. Brake pedal Adjust
7.7.8. Alternator drive belt Adjust
7.7.9. Fuel filter Replace
7.8. Every 600 hours
7.8.1. Transmission, rear axle, and hydraulic system oil Change fluid
7.8.2. Front axle hubs (2WD) Clean
7.8.3. Engine air filter (outer element) Replace
7.9. Every 1200 hours or annually
7.9.1. Engine air filter (inner element) Replace
7.9.2. FourWheel Drive (4WD) front axle differential oil Change fluid
7.9.3. FourWheel Drive (4WD) front axle hub oil Change fluid
7.9.4. Final drive housing oil Change fluid
7.9.5. Engine valves clearance Check and adjust
7.10. Every 2000 hours
7.10.1. Fuel injector spray Check
7.11. Every 4000 hours or four years
7.11.1. Engine coolant Change fluid
7.12. As required
7.12.1. Headlight bulb Replace
7.12.2. Work light bulb Replace
7.12.3. Front light bulb Replace
7.12.4. Rear light bulb Replace
7.12.5. Steering stops Adjust
7.12.6. Steering toein Adjust
7.12.7. Parking brake Adjust
7.13. Fuse and relay locations
7.13.1. Chassis fuse box
7.14. Storage
7.14.1. Preparing for storage
7.14.2. Removal from storage
8. TROUBLESHOOTING
8.1. Symptom(s)
8.1.1. Engine
8.1.2. Transmission
8.1.3. Electrical system
8.1.4. Hydraulic system
8.1.5. Hydraulic remote control valves
8.1.6. Threepoint hitch
9. SPECIFICATIONS
9.1. Length and height
9.2. Width
9.3. Ground clearance
9.4. Maximum side slope operation
9.5. Power TakeOff (PTO)
9.6. Hydraulic system
9.7. Threepoint linkage
9.8. Brake system
9.9. Steering system
9.10. Electrical system
9.11. Fluid capacities and lubricants
10. ACCESSORIES
10.1. Roll Over Protective Structure (ROPS)
10.2. Hitch
10.3. Fuel filter water separator
11. FORMS AND DECLARATIONS
11.1. Delivery report Owner copy
11.2. Delivery report Dealer copy
