New Holland W130C, W170C Tier 4B Final Wheel Loader Service Manual 47865319
New Holland W130C, W170C Tier 4B Final Wheel Loader Service Manual 47865319 - Image 2
New Holland W130C, W170C Tier 4B Final Wheel Loader Service Manual 47865319 - Image 3
New Holland W130C, W170C Tier 4B Final Wheel Loader Service Manual 47865319 - Image 4
New Holland W130C, W170C Tier 4B Final Wheel Loader Service Manual 47865319 - Image 5
new holland w130c w170c tier 4b final wheel loader service manual 47865319 2
new holland w130c w170c tier 4b final wheel loader service manual 47865319 3
new holland w130c w170c tier 4b final wheel loader service manual 47865319 4
new holland w130c w170c tier 4b final wheel loader service manual 47865319 5

New Holland W130C, W170C Tier 4B Final Wheel Loader Service Manual 47865319

$30.00

  • Type Of Manual: Service Manual
  • Manual ID: 47865319
  • Format: PDF
  • Size: 27.8MB
  • Number of Pages: 469
  • Serial Number:
    47865319
Category:
  • Model List:

    • W130C Tier 4B Final Wheel Loader
    • W170C Tier 4B Final Wheel Loader
  • 1. Hydraulic systems 35
  • 1.1. Hydraulic systems 000
  • 1.2. Reservoir, cooler, and filters 300
  • 1.3. Variable displacement pump 106
  • 1.4. Pilot system 357
  • 1.5. Hydraulic fan drive cooling system 752
  • 1.6. Hydraulic hand control 355
  • 1.7. Front loader hydraulic system control 724
  • 1.8. Front loader arm hydraulic system 701
  • 1.9. Front loader bucket hydraulic system 723
  • 1.10. Tool quick coupler hydraulic system 734
  • 2. Frames and ballasting 39
  • 2.1. Frame 100
  • 3. Steering 41
  • 3.1. Steering control 101
  • 3.2. Hydraulic control components 200
  • 3.3. Cylinders 216
  • 3.4. Auxiliary steering 910
  • 4. Wheels 44
  • 4.1. Front wheels 511
  • 4.2. Rear wheels 520
  • 5. Cab climate control 50
  • 5.1. Air conditioning 200
