Yale A7T0 GP50UX6, GP60UX6, GP70UX6 Parts Manual 550253259

$50.00

Series: A7T0
Type Of Manual: Parts Manual
Manual ID: 550253259
Format: PDF

Category: Yale Parts Manual PDF

Model List:
- GP50UX6, GP60UX6, GP70UX6

1. DISPLAY MOUNT, FLOORPLATES, AND COVERS
2. DASHBOARD COVERS
3. COUNTERBALANCE WEIGHT
4. HOOD MOUNT
5. OVERHEAD GUARD
6. SEAT MOUNTING
7. LABELS PAGE 1 OF 4
8. LABELS PAGE 2 OF 4
9. LABELS PAGE 3 OF 4
10. LABELS PAGE 4 OF 4
11. ENGINE SYSTEM – MITSUBISHI S6S-T
11.1. OIL CYLINDER ASSEMBLY
11.2. HIGH EXHAUST SYSTEM
11.3. COOLING SYSTEM
11.4. ENGINE MOUNTING
11.5. AIR INLET CONNECTION
11.6. ALTERNATOR ASSEMBLY
11.7. ALTERNATOR MOUNTING
11.8. BEARINGS
11.9. BREATHER
11.10. CAMSHAFT AND TAPPET
11.11. CONNECTING ROD
11.12. CRANKCASE ASSEMBLY
11.13. CRANKSHAFT
11.14. CRANKSHAFT PULLEY
11.15. CYLINDER HEAD
11.16. ENGINE COOLING SYSTEM
11.17. ENGINE FUEL SYSTEM
11.18. EXHAUST MANIFOLD
11.19. FAN SPACER
11.20. FLYWHEEL
11.21. FUEL FILTER
11.22. INJECTION PUMP S6S-VE – PAGE 1 OF 1
11.23. INJECTION PUMP S6S-VE – PAGE 1 OF 2
11.24. INJECTION PUMP S6S-VE – PAGE 2 OF 3
11.25. INJECTION PUMP MOUNTING
11.26. GLOW PLUG
11.27. INTAKE MANIFOLD
11.28. LIFTING EYE
11.29. ROCKER COVER
11.30. REAR PLATE
11.31. TIMING GEAR CASE
11.32. OIL COOLER
11.33. OIL FILTER
11.34. OIL LEVEL GAUGE
11.35. OIL PRESSURE AND TEMPERATURE SWITCHES
11.36. OIL PUMP
11.37. OIL STRAINER
11.38. OIL SYSTEM RELIEF AND SAFETY VALVES
11.39. STARTER
11.40. TIMING GEAR
11.41. TORSIONAL DAMPER
11.42. TURBOCHARGER PAGE 1 OF 3
11.43. TURBOCHARGER PAGE 2 OF 3
11.44. TURBOCHARGER PAGE 3 OF 3
11.45. WATER PUMP
11.46. WATER PUMP PULLEY
11.47. VALVE MECHANISM
11.48. OVERHAUL GASKET KIT
12. ENGINE SYSTEM – KUBOTA
12.1. ENGINE MOUNTING KUBOTA V3800
12.2. ENGINE MOUNTING KUBOTA WG3800
12.3. HIGH EXHAUST SYSTEM KUBOTA WG3800 – W(J2)3
12.4. HIGH EXHAUST SYSTEM KUBOTA V3800
12.5. COOLING SYSTEM KUBOTA V3800 – W(13)3
12.6. COOLING SYSTEM KUBOTA V3800 – W(15A)3, W(21)3
12.7. COOLING SYSTEM KUBOTA WG3800
12.8. LPG CONVERSION SYSTEM KUBOTA WG3800
12.9. HIGH EXHAUST SYSTEM KUBOTA WG3800 – W(K2)3
12.10. OIL COOLER KUBOTA WG3800 – W(J2)3, W(K2)3
12.11. WIRE HARNESS KUBOTA WG3800 – W(J2)3
12.12. WIRE HARNESS KUBOTA WG3800 – W(K2)3
12.13. ECU – PAGE 1 OF 2 KUBOTA WG3800 – W(J2)3
12.14. ECU – PAGE 1 OF 2 KUBOTA WG3800 – W(K2)3
12.15. ECU – PAGE 2 OF 2 KUBOTA WG3800 – W(J2)3
12.16. ECU – PAGE 2 OF 2 KUBOTA WG3800 – W(K2)3
12.17. UPPER GASKET KIT – OPTION KUBOTA WG3800 – W(J2)3, W(K2)3
12.18. LOWER GASKET KIT – OPTION KUBOTA WG3800 – W(J2)3, W(K2)3
12.19. PISTON KIT – OPTION KUBOTA WG3800 – W(J2)3, W(K2)3
12.20. DIAGNOSTIC KIT – OPTION KUBOTA WG3800 – W(J2)3,W(K2)3
12.21. DIAGNOSTIC KIT – OPTION KUBOTA WG3800 – W(J2)3, W(K2)3
12.22. DIRECT SALES – OPTION KUBOTA WG3800 – W(J2)3
12.23. EXHAUST MANIFOLD KUBOTA WG3800 – W(J2)3, W(K2)3
12.24. INLET MANIFOLD KUBOTA WG3800 – W(J2)3
12.25. INLET MANIFOLD KUBOTA WG3800 – W(K2)3
12.26. FAN KUBOTA WG3800 – W(J2)3, W(K2)3
12.27. WATER PUMP KUBOTA WG3800 – W(J2)3, W(K2)3
12.28. WATER FLANGE AND THERMOSTAT KUBOTA WG3800 – W(J2)3, W(K2)3
12.29. OIL SWITCH AND THERMOMETER KUBOTA WG3800 – W(J2)3, W(K2)3
12.30. STARTER – COMPONENT PARTS KUBOTA WG3800 – W(J2)3, W(K2)3
12.31. STARTER KUBOTA WG3800 – W(J2)3, W(K2)3
12.32. ALTERNATOR – COMPONENT PARTS KUBOTA WG3800 – W(J2)3, W(K2)3
12.33. ALTERNATOR AND PULLEY KUBOTA WG3800 – W(J2)3, W(K2)3
12.34. COVER – SUPPLY PUMP KUBOTA WG3800 – W(J2)3, W(K2)3
12.35. IGNITION COIL KUBOTA WG3800 – W(J2)3, W(K2)3
12.36. COVER – IGNITION PUMP KUBOTA WG3800 – W(J2)3, W(K2)3
12.37. FLYWHEEL KUBOTA WG3800 – W(J2)3, W(K2)3
12.38. PISTON AND CRANKSHAFT KUBOTA WG3800 – W(J2)3, W(K2)3
12.39. CAMSHAFT AND IDLE GEAR SHAFT KUBOTA WG3800 – W(J2)3, W(K2)3
12.40. MAIN BEARING CASE KUBOTA WG3800 – W(J2)3, W(K2)3
12.41. DIPSTICK KUBOTA WG3800 – W(J1)3, W(J2)3 – W(J2)3, W(K2)3
12.42. HEAD COVER KUBOTA WG3800 – W(J2)3, W(K2)3
12.43. GEAR CASE KUBOTA WG3800 – W(J2)3, W(K2)3
12.44. CYLINDER HEAD KUBOTA WG3800 – W(J2)3, W(K2)3
12.45. OIL PAN KUBOTA WG3800 – W(J2)3, W(K2)3
12.46. CRANKCASE ASSEMBLY KUBOTA WG3800 – W(J2)3, W(K2)3
13. ENGINE ASSEMBLY – KUBOTA WG3800
13.1. OIL COOLER KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.2. WIRE HARNESS KUBOTA WG3800 – W(J1)3
13.3. WIRE HARNESS KUBOTA WG3800 – W(J2)3
13.4. WIRE HARNESS KUBOTA WG3800 – W(K2)3
13.5. ECU – PAGE 1 OF 3 KUBOTA WG3800 – W(J1)3, W(J2)3
13.6. ECU – PAGE 1 OF 3 KUBOTA WG3800 – W(K1)3, W(K2)3
13.7. ECU – PAGE 2 OF 3 KUBOTA WG3800 – W(J2)3
13.8. ECU – PAGE 2 OF 3 KUBOTA WG3800 – W(J1)3
13.9. ECU – PAGE 2 OF 3 KUBOTA WG3800 – W(K1)3
13.10. ECU – PAGE 2 OF 3 KUBOTA WG3800 – W(K2)3
13.11. ECU – PAGE 3 OF 3 KUBOTA WG3800 – W(J1)3, W(K1)3
13.12. UPPER GASKET KIT – OPTION KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.13. LOWER GASKET KIT – OPTION KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.14. PISTON KIT – OPTION KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.15. DIRECT SALES – OPTION KUBOTA WG3800 – W(J1)3, W(J2)3
13.16. EXHAUST MANIFOLD KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.17. INLET MANIFOLD KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3
13.18. INLET MANIFOLD KUBOTA WG3800 – W(K2)3
13.19. FAN KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.20. WATER PUMP KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.21. WATER FLANGE AND THERMOSTAT KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.22. OIL SWITCH AND THERMOMETER KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.23. STARTER – COMPONENT PARTS KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.24. STARTER KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.25. ALTERNATOR – COMPONENT PARTS KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.26. ALTERNATOR AND PULLEY KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.27. COVER – SUPPLY PUMP KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.28. IGNITION COIL KUBOTA WG3800 – W(J1)3, W(K1)3
13.29. IGNITION COIL KUBOTA WG3800 – W(J2)3, W(K2)3
13.30. COVER – IGNITION PUMP KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.31. FLYWHEEL KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.32. PISTON AND CRANKSHAFT KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.33. CAMSHAFT AND IDLE GEAR SHAFT KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.34. MAIN BEARING CASE KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.35. DIPSTICK KUBOTA WG3800 – W(J1)3, W(J2)3 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.36. HEAD COVER KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.37. GEAR CASE KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.38. CYLINDER HEAD KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.39. OIL PAN KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
13.40. CRANKCASE ASSEMBLY KUBOTA WG3800 – W(J1)3, W(J2)3, W(K1)3, W(K2)3
14. ENGINE ASSEMBLY-KUBOTA V3800 (DOCDPF)
14.1. CRANKCASE
14.2. OIL PAN
14.3. DIPSTICK AND GUIDE
14.4. CYLINDER HEAD
14.5. INLET AND EXHAUST VALVES
14.6. ROCKER ARM SHAFT
14.7. HEAD COVER
14.8. GEAR CASE
14.9. PISTON AND CRANKSHAFT
14.10. CAMSHAFT AND IDLE GEAR SHAFT
14.11. BEARING CASE COVER
14.12. FLYWHEEL
14.13. SUPPLY PUMP
14.14. INJECTION PIPE
14.15. COMMON RAIL
14.16. ALTERNATOR AND PULLEY
14.17. ALTERNATOR – COMPONENT PARTS
14.18. STARTER
14.19. STARTER – COMPONENT PARTS
14.20. SWITCH AND SENSOR
14.21. INJECTOR HARNESS
14.22. WIRE HARNESS
14.23. WIRE HARNESS BRACKET
14.24. WATER FLANGE AND THERMOSTAT
14.25. WATER PUMP
14.26. FAN AND PULLEY
14.27. INLET MANIFOLD
14.28. AIR CLEANER FLANGE AND THROTTLE VALVE
14.29. INLET PIPE
14.30. EXHAUST MANIFOLD
14.31. EGR VALVE
14.32. EGR COOLER
14.33. TURBO CHARGER
14.34. DIESEL PARTICULATE FILTER MUFFLER
14.35. DIESEL PARTICULATE MUFFLER COMPONENTS
14.36. DIESEL PARTICULATE FILTER MUFFLER SENSOR
14.37. PRESSURE PIPE
14.38. BREATHER PIPE AND SEPARATOR PIPE
14.39. OIL SEPARATOR
14.40. OIL PIPE
14.41. OIL COOLER
14.42. OIL FILTER
14.43. ECU AND ACCESSORIES AND SERVICE PARTS
14.44. ECU AND ACCESSORIES AND SERVICE PARTS
14.45. ECU AND ACCESSORIES AND SERVICE PARTS
14.46. PISTON KIT – OPTION
15. ENGINE ASSEMBLY – KUBOTA V3800 (DOC)
15.1. CRANKCASE
15.2. OIL PAN
15.3. DIPSTICK AND GUIDE
15.4. CYLINDER HEAD
15.5. INLET AND EXHAUST VALVES
15.6. ROCKER ARM SHAFT
15.7. HEAD COVER
15.8. GEAR CASE
15.9. PISTON AND CONNECTING ROD
15.10. CAMSHAFT AND IDLE GEAR SHAFT
15.11. BEARING CASE COVER
15.12. FLYWHEEL
15.13. SUPPLY PUMP
15.14. FUEL PIPE
15.15. INJECTION PIPE
15.16. COMMON RAIL
15.17. ALTERNATOR AND PULLEY
15.18. ALTERNATOR – COMPONENT PARTS
15.19. STARTER
15.20. STARTER – COMPONENT PARTS
15.21. SWITCH AND SENSOR
15.22. INJECTOR HARNESS
15.23. WIRE HARNESS
15.24. WIRE HARNESS BRACKET
15.25. WATER FLANGE AND THERMOSTAT
15.26. WATER PUMP
15.27. FAN AND PULLEY
15.28. INLET MANIFOLD
15.29. AIR CLEANER FLANGE AND THROTTLE VALVE
15.30. EXHAUST MANIFOLD
15.31. EGR VALVE
15.32. EGR COOLER
15.33. TURBO CHARGER
15.34. DIESEL PARTICULATE FILTER MUFFLER
15.35. DIESEL PARTICULATE MUFFLER COMPONENTS
15.36. BREATHER PIPE AND SEPARATOR PIPE
15.37. OIL SEPARATOR
15.38. OIL PIPE
15.39. OIL COOLER
15.40. OIL FILTER
15.41. OIL SEPARATOR
15.42. HYDRAULIC PUMP COVER
15.43. ECU AND ACCESSORIES AND SERVICE PARTS
15.44. PISTON KIT – OPTION
15.45. INSULATION KIT OPTIONAL
16. FUEL SYSTEM
16.1. FUEL SYSTEM KUBOTA WG3800
16.2. FUEL SYSTEM MITSUBISHI S6S-T
16.3. FUEL SYSTEM KUBOTA V3800
16.4. AIR CLEANER KUBOTA V3800
16.5. AIR CLEANER MITSUBISHI S6S-T
16.6. ACCELERATOR PEDAL
16.7. ACCELERATOR PEDAL (ELECTRONIC)
16.8. AIR CLEANER KUBOTA WG3800
17. ELECTRICAL SYSTEM
17.1. ELECTRICAL SYSTEM PAGE 1 OF 4
17.2. ELECTRICAL SYSTEM PAGE 2 OF 4
17.3. ELECTRICAL SYSTEM PAGE 3 OF 4
17.4. ELECTRICAL SYSTEM PAGE 4 OF 4
17.5. BATTERY AND MOUNTING MITSUBISHI S6S-T
17.6. BATTERY AND MOUNTING KUBOTA WG3800, V3800
18. TRANSMISSION
18.1. TOR-CON OIL COOLING SYSTEM
18.2. TRANSMISSION SHAFT MOUNT
18.3. TRANSMISSION MITSUBISHI S6S-T – PAGE 1 OF 4
18.4. TRANSMISSION MITSUBISHI S6S-T – PAGE 2 OF 4
18.5. TRANSMISSION MITSUBISHI S6S-T – PAGE 3 OF 4
18.6. TRANSMISSION MITSUBISHI S6S-T – PAGE 4 OF 4
18.7. TRANSMISSION KUBOTA WG3800
18.8. TRANSMISSION KUBOTA V3800
18.9. CLUTCH ASSEMBLY MITSUBISHI S6S-T
18.10. CLUTCH ASSEMBLY KUBOTA
19. Drive Axle
19.1. DRIVE AXLE MOUNTING
19.2. FRONT WHEEL AND TIRE
19.3. DRIVE AXLE ASSEMBLY
20. STEERING SYSTEM
20.1. STEER COLUMN
20.2. STEER AXLE MOUNTING
20.3. STEERING SYSTEM
20.4. STEER AXLE ASSEMBLY
20.5. REAR WHEEL AND TIRE
21. BRAKE SYSTEM
21.1. FOOT BRAKE
21.2. PARKING BRAKE
21.3. BRAKE ASSEMBLY
22. HYDRAULIC SYSTEM
22.1. HYDRAULIC OIL TANK
22.2. HYDRAULIC LEVERS TWO FUNCTION
22.3. HYDRAULIC LEVERS THREE FUNCTION
22.4. HYDRAULIC LEVERS FOUR FUNCTION
22.5. HYDRAULIC SUPPLY AND RETURN
22.6. CYLINDER
22.7. TILT SYSTEM
22.8. TILT CYLINDER
23. Mast-Two Stage Limited Free-Lift
23.1. MAST HYDRAULIC SYSTEM TWO FUNCTION
23.2. MAST HYDRAULIC SYSTEM THREE FUNCTION
23.3. MAST HYDRAULIC SYSTEM FOUR FUNCTION
23.4. MAST ASSEMBLY
23.5. LIFT CYLINDER
24. Mast-Two Stage Full Free-Lift
24.1. MAST HYDRAULIC SYSTEM TWO FUNCTION
24.2. MAST HYDRAULIC SYSTEM THREE FUNCTION
24.3. MAST HYDRAULIC OPTIONAL PARTS
24.4. MAST HYDRAULIC SYSTEM FOUR FUNCTION
24.5. MAST ASSEMBLY
24.6. REAR LIFT CYLINDER
24.7. FRONT LIFT CYLINDER
25. Mast-Three Stage Full Free-Lift
25.1. MAST HYDRAULIC SYSTEM TWO FUNCTION
25.2. MAST HYDRAULIC SYSTEM THREE FUNCTION
25.3. MAST HYDRAULIC OPTIONAL PARTS
25.4. MAST HYDRAULIC SYSTEM FOUR FUNCTION
25.5. MAST ASSEMBLY
25.6. REAR LIFT CYLINDER
25.7. FRONT LIFT CYLINDER
26. Attachments
26.1. LIFT BRACKET MAST-TWO STAGE LIMITED AND FULL FREE-LIFT
26.2. LIFT BRACKET MAST-THREE STAGE FULL FREE-LIFT
27. OPTIONAL EQUIPMENT
27.1. SIDESHIFT CASCADE 150D-SSS-14C
27.2. SIDESHIFT FORK POSITIONER LDSJ-TY70G-C1
27.3. SIDE-SHIFT CYLINDER ASSEMBLY CASCADE 150D-SSS-14C
27.4. SIDESHIFT LDSJ-GC70
27.5. INTEGRAL SIDE-SHIFT
27.6. INTEGRAL SIDESHIFT FORK POSITIONER HYDRAULIC SYSTEM
27.7. INTEGRAL SIDESHIFT FORK POSTIONER
27.8. INTEGRAL SIDESHIFT MAST-TWO STAGE LIMITED FREE LIFT
27.9. INTEGRAL SIDESHIFT MAST-TWO AND THREE STAGE FULL FREE LIFT
27.10. OPERATOR PRESENCE SYSTEM
27.11. SIDESHIFT FORK POSITIONER MAST-TWO AND THREE STAGE FULL FREE LIFT – LDSJ
27.12. SIDESHIFT FORK POSITIONER MAST-TWO LIMITED FREE LIFT – LDSJ
27.13. SIDESHIFT MAST-TWO AND THREE STAGE FULL FREE LIFT – CASCADE
27.14. SIDESHIFT MAST-TWO STAGE LIMITED FREE LIFT – CASCADE
27.15. SIDESHIFT MAST-THREE STAGE FULL FREE LIFT – LDSJ

Rate this product
