Yale B839 ERC35HG, ERC40HG, ERC45HG, ERC55HG Parts Manual 524238564

$50.00

Series: B839
Type Of Manual: Parts Manual
Manual ID: 524238564
Format: PDF

Category: Yale Parts Manual PDF

Model List:
- ERC35HG, ERC40HG, ERC45HG, ERC55HG

1. GENERAL TRUCK
1.1. COUNTERWEIGHT
1.2. OVERHEAD GUARD WITH CURVED LEG
1.3. FLOOR PLATES AND COVERS
1.4. NON SUSPENSION SEAT
1.5. FULL SUSPENSION SEAT SHEET 1 OF 2
1.6. FULL SUSPENSION SEAT SHEET 2 OF 2
1.7. BATTERY SPACER
2. ELECTRICAL SYSTEM
2.1. ELECTRICAL SYSTEM
2.2. CONTROL PANEL 36/48 VOLT
2.3. CONTROL PANEL 72/80 VOLT
2.4. CONTACTOR PANEL
2.5. CONTACTOR POWER STEERING ON-DEMAND
2.6. LINE CONTACTOR
2.7. WIRE HARNESS MAIN CONTROL – SHEET 1 OF 2 ( 8/2005)
2.8. WIRE HARNESS MAIN CONTROL – SHEET 2 OF 2 ( 8/2005)
2.9. WIRE HARNESS MAIN CONTROL – SHEET 1 0F 2 (8/2005 )
2.10. WIRE HARNESS MAIN CONTROL – SHEET 2 OF 2 (8/2005 )
2.11. WIRE HARNESS (MAIN CONTROL) 80 VOLT – SHEET 1 OF 2
2.12. WIRE HARNESS (MAIN CONTROL) 80 VOLT – SHEET 2 OF 2
2.13. WIRE HARNESS LIGHTS
2.14. WIRE HARNESS DASH PANEL
2.15. WIRE HARNESS BRAKE SWITCH
3. DRIVE UNIT
3.1. DRIVE AXLE
3.2. TRANSMISSION
3.3. TRACTION MOTOR
3.4. DRIVE TIRE AND WHEEL
4. STEERING SYSTEM
4.1. STEER AXLE
4.2. STEERING CYLINDER
4.3. STEER MOTOR AND PUMP
4.4. GEAR PUMP
4.5. STEER COLUMN
4.6. STEER PUMP
4.7. SHIFT LEVER
4.8. STEER TIRE AND WHEEL
5. BRAKE SYSTEM
5.1. PARK BRAKE LEVER ACTUATED
5.2. BRAKE LINKAGE
5.3. BRAKE ASSEMBLY
5.4. MASTER CYLINDER
5.5. ACCELERATOR
5.6. FOOT DIRECTIONAL CONTROL
6. HYDRAULIC SYSTEM
6.1. HYDRAULIC SINGLE PUMP AND MOTOR
6.2. SUPPLY AND RETURN
6.3. HYDRAULIC MOTOR
6.4. HYDRAULIC PUMP 29 CC
6.5. HYDRAULIC FILTER
6.6. HYDRAULIC PLUMBING CONTROL VALVE
6.7. HYDRAULIC CONTROL HAND LEVERS
6.8. CONTROL VALVE THREE FUNCTION
6.9. CONTROL VALVE FOUR FUNCTION
6.10. MAST INSTALLATION
6.11. TILT CYLINDER
7. Mast-Two Stage Limited Free-Lift
7.1. OUTER MAST TWO STAGE LIMITED FREE-LIFT
7.2. INNER MAST TWO STAGE LIMITED FREE-LIFT
7.3. MAIN LIFT TWO STAGE LIMITED FREE-LIFT
7.4. MAIN LIFT CYLINDER TWO STAGE LIMITED FREE-LIFT – ERC 35-40HG
7.5. MAIN LIFT CYLINDER TWO STAGE LIMITED FREE-LIFT – ERC 45-55 HG
7.6. CARRIAGE ASSEMBLY TWO STAGE LIMITED FREE-LIFT
8. Mast-Three Stage Full Free-Lift
8.1. OUTER MAST THREE STAGE FULL FREE-LIFT
8.2. INTERMEDIATE MAST THREE STAGE FULL FREE-LIFT
8.3. INNER MAST THREE STAGE FULL FREE-LIFT
8.4. MAIN LIFT THREE STAGE FULL FREE-LIFT
8.5. FREE-LIFT THREE STAGE FULL FREE-LIFT
8.6. MAIN LIFT CYLINDER THREE STAGE FULL FREE-LIFT
8.7. FREE-LIFT CYLINDER THREE STAGE FULL FREE-LIFT
8.8. CARRIAGE THREE STAGE FULL FREE-LIFT
9. Mast-Two Stage Full Free-Lift
9.1. OUTER MAST AND MAIN LIFT TWO STAGE FULL FREE-LIFT
9.2. INNER MAST AND FREE-LIFT TWO STAGE FULL FREE-LIFT
9.3. MAIN LIFT CYLINDER TWO STAGE FULL FREE-LIFT
9.4. FREE-LIFT CYLINDER TWO STAGE FULL FREE-LIFT
9.5. CARRIAGE TWO STAGE FULL FREE-LIFT
10. HEADER HOSE GROUP
10.1. HEADER HOSES TWO STAGE LIMITED FREE-LIFT
10.2. HEADER HOSE TWO STAGE LIMITED FREE-LIFT – MAST HEIGHTS 2790MM AND 3050MM
10.3. HEADER HOSE THREE STAGE FULL FREE-LIFT – HEIGHTS LESS THAN 4940 AND 5200 MM
10.4. HEADER HOSE THREE STAGE FULL FREE-LIFT – HEIGHTS 4940 AND 5200 MM AND ABOVE
10.5. HEADER HOSE TWO STAGE FULL FREE-LIFT – MAST HEIGHT 3650 MM
10.6. HEADER HOSE TWO STAGE FULL FREE- LIFT – MAST HEIGHT 2790 AND 3050 MM
11. FORKS, LOAD BACKREST, AND MAST INSTALLATION
11.1. FORKS CLASS III
11.2. FORKS CLASS III – OPTIONAL
11.3. FORKS CLASS IV
11.4. LOAD BACKREST EXTENSION
12. OPTIONS
12.1. DC CONVERTER
12.2. ACCUMULATOR
12.3. DRIVE LIGHTS
12.4. STROBE LIGHT
12.5. LED BACK-UP AND BRAKE LIGHTS
12.6. INTEGRAL SIDE-SHIFT ASSEMBLY TWO STAGE LIMITED FREE-LIFT – 1219 MM (48 IN.) CLASS III
12.7. INTEGRAL SIDE-SHIFT CARRIAGE TWO STAGE LIMITED FREE-LIFT – 1219 MM (48 IN.) CLASS III
12.8. INTEGRAL SIDE-SHIFT ASSEMBLY TWO STAGE LIMITED FREE-LIFT – 1219 MM (48 IN.) CLASS IV
12.9. INTEGRAL SIDE-SHIFT CARRIAGE TWO STAGE LIMITED FREE-LIFT – 1219 MM (48 IN.) CLASS IV
12.10. INTEGRAL SIDE-SHIFT ASSEMBLY TWO STAGE FULL FREE-LIFT – 1219 MM (48 IN.) CLASS III
12.11. INTEGRAL SIDE-SHIFT CARRIAGE TWO STAGE FULL FREE-LIFT – 1219 MM (48 IN.) CLASS III
12.12. INTEGRAL SIDE-SHIFT ASSEMBLY TWO STAGE FULL FREE-LIFT – 1219 MM (48 IN.) CLASS IV
12.13. INTEGRAL SIDE-SHIFT CARRIAGE TWO STAGE FULL FREE-LIFT – 1219 MM (48 IN.) CLASS IV
12.14. INTEGRAL SIDE-SHIFT ASSEMBLY THREE STAGE FULL FREE-LIFT – 1219 MM (48 IN.) CLASS III
12.15. INTEGRAL SIDE-SHIFT CARRIAGE THREE STAGE FULL FREE-LIFT – 1219 MM (48 IN.) CLASS III
12.16. INTEGRAL SIDE-SHIFT ASSEMBLY THREE STAGE FULL FREE-LIFT – 1219 MM (48 IN.) CLASS IV
12.17. INTEGRAL SIDE-SHIFT CARRIAGE THREE STAGE FULL FREE-LIFT – 1219 MM (48 IN.) CLASS IV
13. NUMERICAL INDEX
14. USER SUPPORT INFORMATION
