Yale C877 GDP130-140-160EB Parts Manual 524206424

Yale C877 GDP130-140-160EB Parts Manual 524206424 - Image 2

Yale C877 GDP130-140-160EB Parts Manual 524206424 - Image 3

Yale C877 GDP130-140-160EB Parts Manual 524206424 - Image 4

Yale C877 GDP130-140-160EB Parts Manual 524206424 - Image 5

yale c877 gdp130 140 160eb parts manual 524206424 2

yale c877 gdp130 140 160eb parts manual 524206424 3

Yale C877 GDP130-140-160EB Parts Manual 524206424

$50.00

Series: C877
Type Of Manual: Parts Manual
Manual ID: 524206424
Format: PDF

Category: Yale Parts Manual PDF

Model List:
- GDP130-140-160EB

1. GENERAL TRUCK
1.1. GENERAL TRUCK
1.2. COUNTERWEIGHT
1.3. FLOOR PLATES AND COVERS
1.4. CAB AND ATTACHING PARTS
1.5. AIR FILTER ASSEMBLY
1.6. CAB FLOORMATS
1.7. STEEL DOOR RIGHT HAND
1.8. STEEL DOOR LEFT HAND
1.9. MAIN WINDOW ASSEMBLY
1.10. CAB AND TILT CYLINDER MOUNTING
1.11. TILT CYLINDER CAB
1.12. HAND PUMP CAB TILT
1.13. ELECTRICAL PUMP CAB TILT
1.14. HEATER HOSE ARRANGEMENT PERKINS
1.15. HEATER HOSE ARRANGEMENT CUMMINS
1.16. AIR CONDITIONING SYSTEM CUMMINS
1.17. AIR CONDITIONING PERKINS
1.18. HEATER AND AIR CONDITIONER ATTACHMENT
1.19. HEATER ASSEMBLY CLOSED CAB, WITHOUT AIRCO
1.20. HEATER AND AIR CONDITIONER ASSEMBLY CLOSED CAB, WITH AIRCO
1.21. CONDENSER
1.22. CONDENSER
1.23. SEAT ASSEMBLY AIR SUSPENSION ( S/N C877E01596C)
1.24. SEAT ASSEMBLY MECHANICAL SUSPENSION ( S/N C877E01596C)
1.25. SEAT ASSEMBLY SUSPENSION (S/N C877E01597C )
1.26. SEAT SUSPENSION MOUNTING (S/N C877E01597C )
1.27. SEAT AIR SUSPENSION ASSEMBLY (S/N C877E01597C )
1.28. SEAT MECHANICAL SUSPENSION ASSEMBLY (S/N C877E01597C )
1.29. SEAT ARMREST ASSEMBLY – WITH WINDOW WASHER OPTIONS
1.30. SEAT ARMREST PIVOT ARM ASSEMBLY
1.31. SEAT TRAINING
1.32. CAB HARDWARE AND CONTROL COVER
1.33. CAB HARDWARE AND CONTROL COVER OPEN CAB
1.34. INCHING PEDAL AND ACCESSORIES CAB
1.35. AIR DUCT AND ACCESSORIES CAB
1.36. DASH DISPLAY CAB
1.37. CAB SOUND REDUCTION
2. ENGINES
2.1. ENGINE ASSEMBLY PERKINS
2.2. COOLING PERKINS
2.3. EXHAUST PERKINS
2.4. ENGINE MOUNT PERKINS
2.5. ENGINE BLOCK HEATER PERKINS
2.6. AIR COMPRESSOR AND ATTACHING PARTS PERKINS
2.7. AIR COMPRESSOR SHEET 1 OF 2 – PERKINS
2.8. AIR COMPRESSOR SHEET 2 OF 2 – PERKINS
2.9. CYLINDER BLOCK PERKINS
2.10. CYLINDER HEAD PERKINS
2.11. CYLINDER HEAD COVER PERKINS
2.12. CRANKSHAFT AND MAIN BEARINGS PERKINS
2.13. PISTON AND CONNECTING ROD PERKINS
2.14. CAMSHAFT AND ROCKER ASSEMBLY PERKINS
2.15. TIMING CASE PERKINS
2.16. TIMING COVER PERKINS
2.17. TIMING GEAR PERKINS
2.18. OIL SUMP PERKINS
2.19. MANIFOLDS PERKINS
2.20. IDLER GEAR PERKINS
2.21. FRONT DRIVE PULLEY PERKINS
2.22. FAN DRIVE AND PULLEY PERKINS
2.23. AUXILIARY DRIVE GEAR PERKINS
2.24. BLANKING PLUG, OIL FEED AND HOSES PERKINS
2.25. BLANKING PLATE AND PLUGS PERKINS
2.26. OIL PUMP AND DELIVERY HOUSING PERKINS
2.27. OIL FILTER AND ATTACHING PARTS PERKINS
2.28. OIL COOLER AND CONNECTIONS PERKINS
2.29. THERMOSTAT AND WATER OUTLET HOUSING PERKINS
2.30. WATER PUMP PERKINS
2.31. TURBOCHARGER AND ATTACHING PARTS PERKINS
2.32. TURBO DRAIN PIPE AND BLANKING PLATE PERKINS
2.33. ENGINE LIFTING EYES PERKINS
2.34. ELECTRONIC CONTROL MODULE AND MOUNTING PERKINS
2.35. WIRING LOOMS PERKINS
2.36. PICK-UP SENSORS PERKINS
2.37. FLYWHEEL HOUSING PERKINS
2.38. FLYWHEEL AND STARTER RING PERKINS
2.39. ENGINE ASSEMBLY CUMMINS
2.40. COOLING CUMMINS
2.41. EXHAUST CUMMINS
2.42. ENGINE MOUNTS CUMMINS
2.43. ENGINE BLOCK HEATER CUMMINS DIESEL ( S/N C877E01654D)
2.44. ENGINE BLOCK HEATER CUMMINS DIESEL (S/N C877E01655D )
2.45. BELT TENSIONER CUMMINS
2.46. VIBRATION DAMPER CUMMINS
2.47. FAN DRIVE CUMMINS
2.48. WATER INLET CONNECTION CUMMINS
2.49. WATER PUMP CUMMINS
2.50. THERMOSTAT HOUSING CUMMINS
2.51. THERMOSTAT CUMMINS
2.52. AIR COMPRESSOR DRY BRAKE – CUMMINS
2.53. AIR CROSSOVER CONNECTION CUMMINS
2.54. AIR COMPRESSOR COOLANT PLUMBING CUMMINS
2.55. CYLINDER BLOCK CUMMINS
2.56. CYLINDER HEAD CUMMINS
2.57. VALVE COVER CUMMINS
2.58. CRANKSHAFT AND MAIN BEARINGS CUMMINS
2.59. CRANKCASE BREATHER CUMMINS
2.60. PISTON AND CONNECTING ROD CUMMINS
2.61. VALVE TAPPET CUMMINS
2.62. CAMSHAFT CUMMINS
2.63. ROCKER LEVERS CUMMINS
2.64. CAM FOLLOWER COVER CUMMINS
2.65. OIL PAN CUMMINS
2.66. OIL LEVEL GAUGE CUMMINS
2.67. OIL FILTER CUMMINS
2.68. OIL PUMP CUMMINS
2.69. ENGINE OIL COOLER CUMMINS
2.70. EXHAUST MANIFOLD CUMMINS
2.71. FRONT GEAR COVER CUMMINS
2.72. FRONT GEAR HOUSING CUMMINS
2.73. FRONT GEAR TRAIN CUMMINS
2.74. FLYWHEEL HOUSING CUMMINS
2.75. FLYWHEEL CUMMINS
2.76. TURBOCHARGER CUMMINS
2.77. TURBOCHARGER OIL PLUMBING CUMMINS
2.78. AUXILIARY PUMP COVER CUMMINS
2.79. AIR HEATER STARTING AID CUMMINS
2.80. CAB HEATER PLUMBING CUMMINS
2.81. HAND HOLE COVER DRY BRAKE – CUMMINS
2.82. HAND HOLE COVER WET BRAKE – CUMMINS
2.83. LIFTING BRACKET CUMMINS
3. FUEL SYSTEM
3.1. FUEL SYSTEM PERKINS
3.2. FUEL INJECTION PUMP AND GEAR PERKINS
3.3. HIGH PRESSURE FUEL PIPES PERKINS
3.4. FUEL INJECTION SUPPLY AND RETURN LINES PERKINS
3.5. LIFT PUMP AND FUEL FILTER LINES PERKINS
3.6. LIFT PUMP ASSEMBLY PERKINS
3.7. FUEL FILTER ASSEMBLY PERKINS
3.8. WATER SEPARATOR PERKINS
3.9. FUEL SYSTEM CUMMINS DIESEL ( S/N C877E01552C)
3.10. FUEL SYSTEM CUMMINS DIESEL (S/N C877E01553C S/N C877E01615D)
3.11. FUEL SYSTEM CUMMINS DIESEL (S/N C877E01616D )
3.12. FUEL INJECTION PUMP CUMMINS
3.13. INJECTOR CUMMINS
3.14. FUEL INJECTOR PLUMBING CUMMINS
3.15. FUEL PLUMBING CUMMINS
3.16. FUEL STRAINER CUMMINS
3.17. FUEL PUMP MOUNTING CUMMINS
3.18. FUEL TRANSFER PUMP CUMMINS
3.19. FUEL FILTER CUMMINS
3.20. FUEL FILTER PLUMBING CUMMINS
3.21. FUEL SYSTEM CUMMINS LPG
3.22. THROTTLE PEDAL LINKAGE FORWARD AND REVERSE LEVER
3.23. THROTTLE PEDAL LINKAGE DIRECTIONAL CONTROL PEDAL
3.24. DIRECTIONAL CONTROL PEDAL
3.25. AIR FILTER SYSTEM WITHOUT ASPIRATED PRE-CLEANER – PERKINS
3.26. AIR FILTER SYSTEM WITHOUT ASPIRATED PRE-CLEANER – CUMMINS
4. ELECTRICAL SYSTEM
4.1. ELECTRICAL SYSTEM PERKINS
4.2. ELECTRICAL SYSTEM CUMMINS ( S/N C877E01605D)
4.3. ELECTRICAL SYSTEM CUMMINS (S/N C877E01606D )
4.4. ELECTRICAL SYSTEM CUMMINS LPG
4.5. CONTROL PANEL HEATER
4.6. CONTROL PANEL AIR CONDITIONER
4.7. DC-DC CONVERTER AND ATTACHING PARTS
4.8. STARTER MOTOR PERKINS
4.9. STARTER MOTOR CUMMINS
4.10. ALTERNATOR BRACKET AND ATTACHING PARTS PERKINS
4.11. ALTERNATOR AND PULLEY PERKINS
4.12. ALTERNATOR AND MOUNTING CUMMINS
4.13. ENGINE CONTROL SYSTEM CUMMINS
4.14. JOYSTICK ASSEMBLY
4.15. WIRE HARNESS ENGINE CONTROL SYSTEM – CUMMINS
4.16. WIRE HARNESS CHASSIS – PERKINS
4.17. WIRE HARNESS FUSE AND RELAY – PERKINS DIESEL
4.18. WIRE HARNESS CHASSIS, CUMMINS DIESEL – SHEET 1 OF 2 ( 10/2004)
4.19. WIRE HARNESS CHASSIS, CUMMINS DIESEL – SHEET 2 OF 2 ( 10/2004)
4.20. WIRE HARNESS CHASSIS, CUMMINS DIESEL – SHEET 1 0F 2 (10/2004 S/N C877E01673D EXC. 01597C AND 01600D)
4.21. WIRE HARNESS CHASSIS, CUMMINS DIESEL – SHEET 2 0F 2 (10/2004 S/N C877E01673D EXC. 01597C AND 01600D)
4.22. WIRE HARNESS CHASSIS, CUMMINS DIESEL – SHEET 1 OF 2 (S/N C877E01673D S/N C877E01674D INC. 01597C AND 01600D)
4.23. WIRE HARNESS CHASSIS, CUMMINS DIESEL – SHEET 2 OF 2 (S/N C877E01673D S/N C877E01674D INC. 01597C AND 01600D)
4.24. WIRE HARNESS CHASSIS, CUMMINS DIESEL – SHEET 1 OF 2 (S/N C877E01674D )
4.25. WIRE HARNESS CHASSIS, CUMMINS DIESEL – SHEET 2 OF 2 (S/N C877E01674D )
4.26. WIRE HARNESS STEERING COLUMN
4.27. WIRE HARNESS AIR DRYER (S/N C877E01619D )
4.28. WIRE HARNESS REAR WIPER
4.29. WIRE HARNESS OPEN CAB
4.30. WIRE HARNESS CLOSED CAB ( S/N C877E01587C)
4.31. WIRE HARNESS CLOSED CAB (S/N C877E01588C )
4.32. WIRE HARNESS ARMREST – WITH CLOSED CAB
4.33. WIRE HARNESS ARMREST – WITH OPEN CAB
4.34. WIRE HARNESS CAB TILT
4.35. WIRE HARNESS CAB SIDE CONSOLE – SHEET 1 OF 3
4.36. WIRE HARNESS CAB SIDE CONSOLE – SHEET 2 OF 3
4.37. WIRE HARNESS CAB CONSOLE RELAYS AND FUSES – SHEET 3 OF 3
4.38. WIRE HARNESS CAB UNDERFLOOR ( S/N C877E01673D)
4.39. WIRE HARNESS CAB UNDERFLOOR (S/N C877E01674D )
4.40. WIRE HARNESS MAST TWO STAGE LIMITED FREE-LIFT
4.41. WIRE HARNESS MAST LIGHT EXTENSION – LEFT HAND
4.42. WIRE HARNESS MAST LIGHT EXTENSION – RIGHT HAND
4.43. WIRE HARNESS REAR DRIVE LIGHT EXTENSION
4.44. WIRE HARNESS MAST WORKLIGHT EXTENSION
4.45. WIRE HARNESS FRONT LIGHTS
4.46. WIRE HARNESS FRONT LIGHTS – WITH FRONT FENDER AND MAST WORK LIGHTS
4.47. WIRE HARNESS CAB LIGHTS
4.48. WIRE HARNESS OIL COOLER
4.49. WIRE HARNESS AUXILIARY HYDRAULIC OIL COOLER
4.50. WIRE HARNESS BRAKE TEMPERATURE – NON-ECH AND EC3 ( S/N C877E01646D)
4.51. WIRE HARNESS BRAKE TEMPERATURE – EC4 ( S/N C877E01646D)
4.52. WIRE HARNESS BACK-UP ALARM
4.53. WIRE HARNESS BRAKE TEMPERATURE (S/N C877E01647D )
4.54. WIRE HARNESS FRONT END – FOUR FUNCTION ( 10/2006)
4.55. WIRE HARNESS FRONT END – FIVE FUNCTION ( 10/2006)
4.56. WIRE HARNESS FRONT END – SIX FUNCTION ( 10/2006)
4.57. WIRE HARNESS FRONT END – FOUR, FIVE, AND SIX FUNCTION (11/2006 )
5. STEERING SYSTEM
5.1. STEERING SYSTEM
5.2. STEERING COLUMN AND ATTACHING PARTS
5.3. STEERING COLUMN ASSEMBLY
5.4. STEERING AXLE
5.5. STEERING CYLINDER
5.6. STEERING CYLINDER
6. BRAKE SYSTEM
6.1. BRAKE SYSTEM WET
6.2. BRAKE SYSTEM DRY
6.3. HYDRAULIC PUMP WET BRAKE – PERKINS
6.4. ACCUMULATOR CHARGE VALVE
6.5. OIL COOLER WET BRAKE
6.6. ACCUMULATOR
6.7. BRAKE ASSEMBLY WET
6.8. BRAKE ASSEMBLY DRY
6.9. PARK BRAKE WET BRAKE
6.10. BRAKE VALVE WET BRAKE
6.11. BRAKE VALVE DRY BRAKE
6.12. AIR DRYER AND ATTACHING PARTS
6.13. AIR DRYER ASSEMBLY
6.14. AIR DRYER AND ATTACHING PARTS
6.15. AIR DRYER SHEET 1 OF 2 (S/N C877E01506B S/N C877E01618D)
6.16. AIR DRYER SHEET 2 OF 2 (S/N C877E01506B S/N C877E01618D)
6.17. AIR DRYER SYSTEM
6.18. AIR DRYER
7. TRANSMISSION
7.1. TRANSMISSION MOUNT AND ATTACHING PARTS PERKINS
7.2. TRANSMISSION MOUNT AND ATTACHING PARTS CUMMINS
7.3. TORQUE CONVERTER HOUSING AND ATTACHING PARTS
7.4. TRANSMISSION CASE
7.5. TRANSMISSION CASE
7.6. CONTROL VALVE ASSEMBLY
7.7. CHARGE PUMP AND FILTER ASSEMBLY
7.8. OUTPUT SHAFT
7.9. THIRD CLUTCH
7.10. LOW CLUTCH
7.11. REVERSE AND SECOND CLUTCH
7.12. IDLER SHAFT REVERSE
7.13. FORWARD CLUTCH
7.14. DRIVE GEAR
7.15. AUXILIARY PUMP DRIVE
7.16. AUXILIARY PUMP DRIVE
7.17. GEAR CLUTCH INSTALLATION
7.18. TORQUE CONVERTER ASSEMBLY PERKINS ( S/N C877E01510B)
7.19. TORQUE CONVERTER ASSEMBLY PERKINS (S/N C877E01511B )
7.20. TORQUE CONVERTER ASSEMBLY CUMMINS ( S/N C877E01510B)
7.21. TORQUE CONVERTER ASSEMBLY CUMMINS (S/N C877E01511B )
7.22. TURBINE SHAFT AND STATOR SUPPORT
7.23. DRIVE PLATE
7.24. DIFFERENTIAL AND CARRIER WET BRAKE
7.25. DIFFERENTIAL AND CARRIER DRY BRAKE
7.26. HUB AND SHAFT ASSEMBLY WET BRAKE
7.27. HUB AND SHAFT ASSEMBLY DRY BRAKE
7.28. AXLE HOUSING AND ATTACHING PARTS
7.29. OUTPUT FLANGE
8. HYDRAULIC SYSTEM
8.1. AUXILIARY HYDRAULIC OIL COOLER
8.2. HYDRAULIC SUPPLY AND RETURN
8.3. LIFT ACCUMULATOR AND ATTACHING PARTS
8.4. ACCUMULATOR PISTON TYPE
8.5. HYDRAULIC TANK AND ATTACHING PARTS
8.6. HYDRAULIC CONTROL VALVE AND ATTACHING PARTS
8.7. HYDRAULIC CONTROL VALVE
8.8. END CAP PARTS LIFT SECTION
8.9. HYDRAULIC PUMP TURBO ( S/N C877E01622D)
8.10. HYDRAULIC PUMP
8.11. PILOT VALVE
8.12. JOYSTICK CONTROL
8.13. CONTROL LEVER
8.14. ELECTRONIC LEVER ASSEMBLY WITH CLAMP ATTACHMENT
8.15. ELECTRONIC LEVER ASSEMBLY THREE, FOUR, FIVE, AND SIX FUNCTION
8.16. TILT CYLINDER AND ATTACHING PARTS
8.17. TILT CYLINDER
9. Mast-Two Stage Limited Free-Lift
9.1. MAST INSTALLATION
9.2. OUTER MAST TWO STAGE LIMITED FREE-LIFT ( S/N C877E01520B)
9.3. OUTER MAST TWO STAGE LIMITED FREE-LIFT (S/N C877E01521B )
9.4. INNER MAST TWO STAGE LIMITED FREE-LIFT ( S/N C877E01520B)
9.5. INNER MAST TWO STAGE LIMITED FREE-LIFT (S/N C877E01521B )
9.6. LIFT TWO STAGE LIMITED FREE-LIFT ( S/N C877E01520B)
9.7. LIFT TWO STAGE LIMITED FREE-LIFT (S/N C877E01521B )
9.8. LIFT CYLINDER TWO STAGE LIMITED FREE-LIFT ( S/N C877E01520B)
9.9. LIFT CYLINDER TWO STAGE LIMITED FREE-LIFT (S/N C877E01521B )
9.10. CARRIAGE THREE FUNCTION
9.11. CARRIAGE FOUR, FIVE, AND SIX FUNCTION
9.12. CARRIAGE INDIVIDUAL FORK POSITIONER – FOUR FUNCTION
9.13. CARRIAGE SIMULTANEOUS FORK POSITIONER – THREE FUNCTION
10. Mast-Three Stage Full Free-Lift
10.1. MAST INSTALLATION
10.2. MAST ASSEMBLY THREE STAGE FULL FREE-LIFT – SHEET 1 OF 3
10.3. MAST ASSEMBLY THREE STAGE FULL FREE-LIFT – SHEET 2 OF 3
10.4. MAST ASSEMBLY THREE STAGE FULL FREE-LIFT – SHEET 3 OF 3
10.5. MAIN LIFT CYLINDER THREE STAGE FULL FREE-LIFT
10.6. FREE-LIFT CYLINDER THREE STAGE FULL FREE-LIFT
10.7. CARRIAGE THREE FUNCTION – THREE STAGE FULL FREE-LIFT
10.8. CARRIAGE FOUR, FIVE, AND SIX FUNCTION – THREE STAGE FULL FREE-LIFT
10.9. STANDARD PIN CARRIAGE (THREE STAGE) – (FOUR, FIVE, AND SIX FUNCTION
10.10. CARRIAGE INDIVIDUAL FORK POSITIONER (FOUR FUNCTION) – THREE STAGE FULL FREE-LIFT
10.11. CARRIAGE SIMULTANEOUS FORK POSITIONER (THREE FUNCTION) – THREE STAGE FULL FREE-LIFT
11. ATTACHMENTS AND HEADER HOSE GROUP
11.1. HEADER HOSE TWO STAGE LIMITED FREE-LIFT ( S/N C877E01520B)
11.2. HEADER HOSE TWO STAGE LIMITED FREE-LIFT (S/N C877E01521B )

Rate this product
