Yale G807 ERP15VT, 16VT, 18VT, 20VT Parts Manual 524308696

Yale G807 ERP15VT, 16VT, 18VT, 20VT Parts Manual 524308696 - Image 2

Yale G807 ERP15VT, 16VT, 18VT, 20VT Parts Manual 524308696 - Image 3

Yale G807 ERP15VT, 16VT, 18VT, 20VT Parts Manual 524308696 - Image 4

Yale G807 ERP15VT, 16VT, 18VT, 20VT Parts Manual 524308696 - Image 5

yale g807 erp15vt 16vt 18vt 20vt parts manual 524308696 2

yale g807 erp15vt 16vt 18vt 20vt parts manual 524308696 3

Yale G807 ERP15VT, 16VT, 18VT, 20VT Parts Manual 524308696

$50.00

Series: G807
Type Of Manual: Parts Manual
Manual ID: 524308696
Format: PDF

Category: Yale Parts Manual PDF

Model List:
- ERP15VT, ERP16VT, ERP18VT, ERP20VT

1. GENERAL TRUCK
1.1. COUNTERWEIGHT
1.2. COUNTERWEIGHT
1.3. OVERHEAD GUARD
1.4. OVERHEAD GUARD
1.5. CAB ASSEMBLY WITH PVC DOORS
1.6. REAR WIPER SWITCH MOUNTING CAB WITH PVC DOORS
1.7. CAB PVC DOORS
1.8. CAB ASSEMBLY FULL STEEL CAB
1.9. CAB REAR PANEL AND WIPER ATTACHMENT
1.10. CAB REAR PANEL ASSEMBLY
1.11. CAB TOP PANEL ASSEMBLY
1.12. CAB ROOF FLAP
1.13. CAB HEADLINER ASSEMBLY
1.14. CAB STEEL DOORS
1.15. CAB STEEL DOOR ASSEMBLY – RIGHT HAND
1.16. CAB STEEL DOOR ASSEMBLY – LEFT HAND
1.17. CAB WINDOW – STEEL DOOR, RIGHT HAND
1.18. CAB WINDOW – STEEL DOOR, LEFT HAND
1.19. CAB FRONT PANEL ASSEMBLY
1.20. CAB FRONT WIPER ASSEMBLY
1.21. CAB HEATER
1.22. CAB HEATER ASSEMBLY ( 9/2011)
1.23. CAB HEATER ASSEMBLY (9/2011 )
1.24. SEAT FULL SUSPENSION – PAGE 1 OF 2
1.25. SEAT FULL SUSPENSION – PAGE 2 OF 2
1.26. SEAT FULL SUSPENSION, HIGH BACK – PAGE 1 OF 2
1.27. SEAT FULL SUSPENSION, HIGH BACK – PAGE 2 OF 2
1.28. SEAT SCISSORS HEAVY DUTY – SWIVEL AND NON-SWIVEL SEATS
1.29. ARMREST SLIDER ASSEMBLY
1.30. ARMREST SLIDER ASSEMBLY
1.31. HOOD AND COVERS EARLY PRODUCTION
1.32. HOOD AND COUNTERWEIGHT COVER LATE PRODUCTION ( S/N G807B07271N)
1.33. HOOD AND COUNTERWEIGHT COVER
1.34. HOOD AND COUNTERWEIGHT COVER WITH RAPID CHARGE OPTION ( S/N G807B07271N)
1.35. SIDE PANELS WITH HIGH HOOD
1.36. SIDE PANELS WITH LOW HOOD
1.37. BATTERY TRAY OPTIONS DROP-IN ( S/N G807B07271N)
1.38. BATTERY TRAY OPTIONS DROP-IN (S/N G807B07271N )
1.39. BATTERY TRAY OPTIONS SIDE-REMOVAL ( S/N G807B02919J)
1.40. BATTERY TRAY OPTIONS SIDE REMOVAL (S/N G807B02920J S/N G807B07271N)
1.41. BATTERY TRAY OPTIONS SIDE REMOVAL (S/N G807B07271N )
1.42. BATTERY COMPARTMENT DOOR SIDE REMOVAL (S/N G807B07271N )
1.43. BATTERY TRAY OPTIONS SIDE REMOVAL – WITH REMOVABLE BATTERY TRAY (S/N G807B07271N )
1.44. BATTERY TRAY OPTIONS SIDE REMOVAL – WITH REMOVABLE BATTERY TRAY (S/N G807B07667P )
1.45. BATTERY STAND FOR POWERED BATTERY EXTRACTION STACKER
1.46. HORIZONTAL BATTERY TRAY
1.47. FRAME HINGE
1.48. DOOR HINGE
1.49. BATTERY RETENTION
1.50. BATTERY RETENTION
1.51. AUXILIARY COUNTERWEIGHT SIDE BATTERY REMOVAL (S/N G807B07271N )
1.52. AUXILIARY COUNTERWEIGHT DROP-IN BATTERY REMOVAL (S/N G807B07271N )
1.53. AUXILIARY COUNTERWEIGHT OPTIONAL – J2.0XNT (1/2015 )
1.54. COWL MOUNT
1.55. COWL MOUNT
1.56. FLOOR PLATES
1.57. DASH AND STEERING COLUMN COVERS FIXED COLUMN
1.58. DASH AND STEERING COLUMN COVERS TELESCOPIC COLUMN
1.59. STATIC STRAP
1.60. FORKS STANDARD
1.61. FORKS OPTIONAL
1.62. LABELS EXTERIOR
1.63. LABELS INTERIOR
1.64. LABELS HYDRAULIC CONTROL FUNCTIONS
1.65. NOISE REDUCTION
1.66. LOAD BACKREST EXTENSION 977MM CARRIAGES
1.67. LOAD BACKREST EXTENSION 907MM CARRIAGES
2. ELECTRICAL SYSTEM
2.1. ELECTRICAL ARRANGEMENT
2.2. ELECTRICAL ARRANGEMENT
2.3. ELECTRICAL ARRANGEMENT WITHOUT E-STEERING
2.4. ELECTRICAL ARRANGEMENT WITH E-STEERING (S/N G807B07271N )
2.5. CONTROLLERS WITHOUT E-STEERING
2.6. CONTROLLERS WITH E-STEERING (S/N G807B07271N )
2.7. CONTROLLER HOIST AND FAN ASSEMBLY ( S/N G807B05963L)
2.8. CONTROLLER HOIST AND FAN ASSEMBLY – WITHOUT E-STEERING (S/N G807B05964L )
2.9. CONTROLLER 48/36 VDC HOIST 450A WITH E-STEERING (S/N G807B07271N )
2.10. CONTROLLER TRACTION AND FAN ASSEMBLY ( S/N G807B05963L)
2.11. CONTROLLER TRACTION AND FAN ASSEMBLY (S/N G807B05964L )
2.12. BATTERY CONNECTOR AND CABLE WITHOUT RAPID CHARGE OPTION – SIDE BATTERY EXTRACTION (S/N G807B05405L )
2.13. BATTERY CONNECTOR AND CABLE WITHOUT RAPID CHARGE OPTION – STANDARD AND SIDE BATTERY EXTRACTION ( S/N G807B05404L)
2.14. BATTERY CONNECTOR AND CABLE WITHOUT RAPID CHARGE OPTION – STANDARD BATTERY EXTRACTION (S/N G807B05405L )
2.15. BATTERY CONNECTOR AND CABLE WITH RAPID CHARGE OPTION ( S/N G807B07271N)
2.16. BATTERY CONNECTOR AND CABLE WITH E-STEERING (S/N G807B07271N )
2.17. FUSE PANEL ASSEMBLY WITHOUT E-STEERING
2.18. FUSE PANEL ASSEMBLY WITH E-STEERING (S/N G807B07271N )
2.19. CONTACTOR WITHOUT E-STEERING ( 10/2015)
2.20. CONTACTOR SEALED, WITHOUT E-STEERING (10/2015 )
2.21. CONTACTOR WITH E-STEERING (S/N G807B07271N )
2.22. DISPLAY
2.23. MINI-LEVER CONTROLS 3 FUNCTION ( 2/2020)
2.24. MINI-LEVER CONTROLS 3 FUNCTION – WITH RTST (2/2020 )
2.25. MINI-LEVER CONTROLS 3 FUNCTION – WITHOUT RTST (2/2020 )
2.26. MINI-LEVER CONTROLS 4 FUNCTION ( 2/2020)
2.27. MINI-LEVER CONTROLS 4 FUNCTION – WITHOUT RTST (2/2020 )
2.28. MINI-LEVER CONTROLS 4 FUNCTION – WITH RTST (2/2020 )
2.29. TILT SENSOR GROUP
2.30. LIGHTS WITH STANDARD OVERHEAD GUARD
2.31. WIRE HARNESS RH LIGHT WITH STANDARD DISPLAY ( S/N G807B05946L)
2.32. WIRE HARNESS RH LIGHT WITH STANDARD DISPLAY (S/N G807B05946L )
2.33. WIRE HARNESS RH LIGHT WITH FREEZER DISPLAY – WITH TURN SIGNAL ( S/N G807B05946L)
2.34. WIRE HARNESS RH LIGHT WITH FREEZER DISPLAY – WITH TURN SIGNAL (S/N G807B05946L )
2.35. WIRE HARNESS TURN SIGNAL
2.36. WIRE HARNESS MANUAL HYDRAULICS
2.37. WIRE HARNESS HEATER
2.38. WIRE HARNESS HEATER – WITH E-STEERING
2.39. WIRE HARNESS MANUAL INTERLOCK
2.40. WIRE HARNESS STEER UNIT
2.41. WIRE HARNESS STEER COLUMN
2.42. WIRE HARNESS SYNCHRONOUS STEERING
2.43. WIRE HARNESS STEERING COLUMN WITH ELECTRIC STEERING (2/2015 )
2.44. WIRE HARNESS REAR WIPER
2.45. WIRE HARNESS CAB ACCESSORY
2.46. WIRE HARNESS CAB ACCESSORY – ALTERNATE PART
2.47. WIRE HARNESS HYDRAULIC FLUID LEVEL AND PRESSURE
2.48. WIRE HARNESS LIGHTS WITH OVERHEAD GUARD (S/N G807B05946L )
2.49. WIRE HARNESS LIGHTS WITH OVERHEAD GUARD ( S/N G807B05946L)
2.50. WIRE HARNESS DC CONVERTER – 12V Outlet ( 9/2013)
2.51. WIRE HARNESS DC CONVERTER – 12V Outlet (9/2013 )
2.52. WIRE HARNESS DC/DC CONVERTER – W/ E-STEERING
2.53. WIRE HARNESS AUXILIARY PLUG
2.54. WIRE HARNESS DC/DC CONVERTER
2.55. WIRE HARNESS MAIN WITH ELECTRO-HYDRAULIC – PAGE 1 OF 2 ( S/N G807B02113H)
2.56. WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS – PAGE 2 OF 2 ( S/N G807B02113H)
2.57. WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS – PAGE 1 OF 2 (S/N G807B02114H )
2.58. WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS – PAGE 2 OF 2 (S/N G807B02114H )
2.59. WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS, WITHOUT E-STEER – PAGE 1 OF 2 (S/N G807B07271N 2/2016)
2.60. WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS, WITHOUT E-STEER – PAGE 2 OF 2 (S/N G807B07271N 2/2016)
2.61. WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS, WITHOUT E-STEER – PAGE 1 OF 2 (2/2016 )
2.62. WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS, WITHOUT E-STEER – PAGE 2 OF 2 (2/2016 )
2.63. WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS AND E-STEERING – PAGE 1 OF 2 (S/N G807B07271N )
2.64. WIRE HARNESS MAIN WITH ELECTRO-HYDRAULICS AND E-STEERING – PAGE 2 OF 2 (S/N G807B07271N )
2.65. WIRE HARNESS MAIN WITH E-HYDRAULICS AND ELECTRIC STEERING – PAGE 1 OF 2 (S/N G807B08277P )
2.66. WIRE HARNESS MAIN WITH E-HYDRAULICS AND ELECTRIC STEERING – PAGE 2 OF 2 (S/N G807B08277P )
2.67. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – PAGE 1 OF 2 ( S/N G807B02104H)
2.68. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – PAGE 2 OF 2 ( S/N G807B02104H)
2.69. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – PAGE 1 OF 2 ( S/N G807B02104H)
2.70. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – PAGE 2 OF 2 ( S/N G807B02104H)
2.71. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – PAGE 1 OF 2 (S/N G807B02105H S/N G807B05946L)
2.72. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS – PAGE 2 OF 2 (S/N G807B02105H S/N G807B05946L)
2.73. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS, WITHOUT E-STEER – PAGE 1 OF 2 (S/N G807B05946L S/N G807B07270N)
2.74. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS, WITHOUT E-STEER – PAGE 2 OF 2 (S/N G807B05946L S/N G807B07270N)
2.75. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS, WITHOUT E-STEER – PAGE 1 OF 2 (S/N G807B07271N 2/2016)
2.76. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS, WITHOUT E-STEER – PAGE 2 OF 2 (S/N G807B07271N 2/2016)
2.77. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS, WITHOUT E-STEER – PAGE 1 OF 2 (2/2016 )
2.78. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS, WITHOUT E-STEER – PAGE 2 OF 2 (2/2016 )
2.79. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS AND ELECTRIC STEERING – PAGE 1 OF 2 (S/N G807B07271N 2/2016)
2.80. WIRE HARNESS MAIN WITH MANUAL-HYDRAULICS AND ELECTRIC STEERING – PAGE 2 OF 2 (S/N G807B07271N 2/2016)
2.81. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS AND E-STEERING – E-BRAKE (PAGE 1 OF 2) (2/2016 )
2.82. WIRE HARNESS MAIN WITH MANUAL HYDRAULICS AND E-STEERING – E-BRAKE (PAGE 2 OF 2) (2/2016 )
3. DRIVE UNIT
3.1. DRIVE UNIT ASSEMBLY
3.2. DRIVE UNIT ASSEMBLY
3.3. MASTER DRIVE UNIT WITH E-BRAKE PAGE 1 OF 3 – HOUSING, MOTOR AND BRAKE (S/N G807B15165V )
3.4. MASTER DRIVE UNIT WITH E-BRAKE PAGE 2 OF 3 – TRANSMISSION INPUT (S/N G807B15165V )
3.5. MASTER DRIVE UNIT WITH E-BRAKE PAGE 3 OF 3 – TRANSMISSION OUTPUT (S/N G807B15165V )
3.6. TRANSMISSION INPUT ( S/N G807B15164V)
3.7. TRANSMISSION OUTPUT ( S/N G807B15164V)
3.8. TRANSMISSION HOUSING ( S/N G807B15164V)
3.9. TRANSMISSION COVER AND BRAKE DISCS ( S/N G807B15164V)
3.10. TRACTION MOTOR ASSEMBLY
3.11. DRIVE TIRE AND WHEEL ASSEMBLY
4. STEERING SYSTEM
4.1. STEER AXLE MOUNTING
4.2. STEER AXLE ASSEMBLY
4.3. STEERING AXLE ELECTRIC STEERING – PAGE 1 OF 4 (S/N G807B07272N S/N G807B11254S)
4.4. STEERING AXLE ELECTRIC STEERING – PAGE 2 OF 4 (S/N G807B07272N S/N G807B11254S)
4.5. STEERING AXLE ELECTRIC STEERING – PAGE 3 OF 4 (S/N G807B07272N S/N G807B11254S)
4.6. STEERING AXLE ELECTRIC STEERING – PAGE 4 OF 4 (S/N G807B07272N S/N G807B11254S)
4.7. STEERING AXLE ELECTRIC STEERING – PAGE 1 OF 4 (S/N G807B11255S )
4.8. STEERING AXLE ELECTRIC STEERING – PAGE 2 OF 4 (S/N G807B11255S )
4.9. STEERING AXLE ELECTRIC STEERING – PAGE 3 OF 4 (S/N G807B11255S )
4.10. STEERING AXLE ELECTRIC STEERING – PAGE 4 OF 4 (S/N G807B11255S )
4.11. STEER TIRE AND WHEEL ASSEMBLY
4.12. STEERING WHEEL AND COLUMN FIXED
4.13. STEERING WHEEL AND COLUMN TELESCOPIC
4.14. STEERING COLUMN ASSEMBLY FIXED ( S/N G807B05946L)
4.15. STEERING COLUMN ASSEMBLY FIXED (S/N G807B05946L )
4.16. STEERING COLUMN ASSEMBLY FIXED – ELECTRIC STEERING
4.17. STEERING COLUMN ASSEMBLY TELESCOPIC ( S/N G807B05946L)
4.18. STEERING COLUMN ASSEMBLY TELESCOPIC (S/N G807B05946L )
4.19. STEERING COLUMN ASSEMBLY TELESCOPIC WITH TILT MEMORY – ELECTRIC STEERING
4.20. STEERING HAND PUMP ASSEMBLY
4.21. STEERING HAND PUMP ASSEMBLY
4.22. STEERING ACCUMULATOR
4.23. STEER SENSOR E-STEER
5. BRAKE SYSTEM
5.1. BRAKE ASSEMBLY HYDRAULIC
5.2. BRAKE ASSEMBLY E-BRAKE
5.3. MASTER CYLINDER
5.4. PARKING BRAKE RELEASE
5.5. ACCELERATOR PEDAL STANDARD
5.6. ACCELERATOR PEDAL FOOT DIRECTIONAL CONTROL
6. HYDRAULIC SYSTEM
6.1. HYDRAULIC POWER UNIT INSTALLATION
6.2. HYDRAULIC POWER UNIT INSTALLATION ELECTRIC STEERING (S/N G807B07271N )
6.3. HYDRAULIC PUMP AND MOTOR ASSEMBLY
6.4. HYDRAULIC PUMP AND MOTOR ELECTRIC STEERING (S/N G807B07271N )
6.5. HYDRAULIC MOTOR
6.6. HYDRAULIC PUMP
6.7. HYDRAULIC TANK ASSEMBLY
6.8. HYDRAULIC TANK AND ATTACHING PARTS ELECTRIC STEERING (S/N G807B07271N )
6.9. HYDRAULIC FILTER HOUSING
6.10. HYDRAULIC SUPPLY AND RETURN
6.11. HYDRAULIC SUPPLY AND RETURN WITH ELECTRIC STEERING (S/N G807B07271N )
6.12. HYDRAULIC HOSES AND FITTINGS STEERING ( S/N G807B07270N)
6.13. HYDRAULIC HOSES AND FITTINGS STEERING – WITH SYNCRONOUS STEERING (S/N G807B07271N )
6.14. HYDRAULIC HOSES AND FITTINGS STEERING – WITHOUT SYNCRONOUS STEERING (S/N G807B07271N )
6.15. HYDRAULIC HOSES AND FITTINGS AUXILIARY HOSES
6.16. HYDRAULIC HOSE MAST
6.17. HYDRAULIC CONTROLS MANUAL
6.18. HYDRAULIC LEVERS – LINKAGE ASSEMBLY (MANUAL)
6.19. HYDRAULIC CONTROL VALVE MANUAL – 3 AND 4 FUNCTION ( S/N G807B03975K)
6.20. HYDRAULIC CONTROL VALVE MANUAL – 3 AND 4 FUNCTION (S/N G807B03976K S/N G807B07271N)
6.21. HYDRAULIC CONTROL VALVE MANUAL – 3 AND 4 FUNCTION (S/N G807B07271N )
6.22. INLET SECTION MANUAL HYDRAULIC CONTROL VALVE
6.23. LIFT/TILT/AUXILIARY SECTION MANUAL HYDRAULIC CONTROL VALVE
6.24. OUTLET SECTION MANUAL HYDRAULIC CONTROL VALVE
6.25. TIE RODS MANUAL HYDRAULIC CONTROL VALVE
6.26. POSITIONER SENSOR MANUAL HYDRAULIC CONTROL VALVE
6.27. HYDRAULIC CONTROLS ELECTRO-HYDRAULIC
6.28. CONTROL VALVE ELECTRO-HYDRAULIC – 3 AND 4 FUNCTION
6.29. INLET SECTION ELECTRO-HYDRAULIC CONTROL VALVE
6.30. LIFT/TILT SECTION ELECTRO-HYDRAULIC CONTROL VALVE
6.31. TIE RODS ELECTRO-HYDRAULIC CONTROL VALVE
6.32. TILT CYLINDER AND MAST INSTALLATION
6.33. TILT CYLINDER ASSEMBLY
7. Mast-Two Stage Limited Free-Lift
7.1. MAST ASSEMBLY TWO STAGE LIMITED FREE LIFT – A270 ( S/N A270B01595H)
7.2. MAST ASSEMBLY TWO STAGE LIMITED FREE LIFT – A270 (S/N A270B01596H )
7.3. LIFT CYLINDER ASSEMBLY TWO STAGE LIMITED FREE LIFT – A270
7.4. CARRIAGE ASSEMBLY TWO STAGE LIMITED FREE LIFT – A270 – STANDARD
7.5. HEADER HOSE ASSEMBLY TWO STAGE LIMITED FREE LIFT – A270 ( S/N A270B01595H)
7.6. HEADER HOSE ASSEMBLY TWO STAGE LIMITED FREE LIFT – A270 (S/N A270B01596H )
7.7. MAST ASSEMBLY TWO STAGE LIMITED FREE LIFT – C661 ( S/N C661B01677H)
7.8. MAST ASSEMBLY TWO STAGE LIMITED FREE LIFT – C661 (S/N C661B01678H )

Rate this product
