Hyster H300-360HD, H360HD-EC (E019) Challenger Parts Manual

Hyster H300-360HD, H360HD-EC (E019) Challenger Parts Manual - Image 2

Hyster H300-360HD, H360HD-EC (E019) Challenger Parts Manual - Image 3

Hyster H300-360HD, H360HD-EC (E019) Challenger Parts Manual - Image 4

Hyster H300-360HD, H360HD-EC (E019) Challenger Parts Manual - Image 5

hyster h300 360hd h360hd ec e019 challenger parts manual 2

hyster h300 360hd h360hd ec e019 challenger parts manual 3

Hyster H300-360HD, H360HD-EC (E019) Challenger Parts Manual

$30.00

Type Of Manual: Parts Manual
Number of Pages: 704
Size: 15.6MB
Format: PDF

Category: Hyster Parts Manual PDF

Model List:
- H300-360HD, H360HD-EC (E019) Challenger

1. GENERAL TRUCK
2. COUNTERWEIGHT
3. FLOOR PLATES AND COVERS
4. FLOOR PLATES AND COVERS
5. CAB AND ATTACHING PARTS
6. CAB FLOORMATS
7. DOOR STEEL ( S/N E019E02044A)
8. STEEL DOOR RIGHT HAND (S/N E019E02045A )
9. STEEL DOOR LEFT HAND (S/N E019E02045A )
10. CAB AND TILT CYLINDER MOUNTING
11. TILT CYLINDER CAB
12. HAND PUMP CAB TILT
13. ELECTRIC PUMP
14. AIR CONDITIONER PERKINS
15. AIR CONDITIONING CUMMINS
16. HEATER ARRANGEMENT PERKINS
17. HEATER ARRANGEMENT CUMMINS
18. HEATER AND AIR CONDITIONER
19. HEATER AND AIR CONDITIONER ATTACHMENT
20. HEATER ASSEMBLY
21. HEATER AND AIR CONDITIONER ASSEMBLY
22. CONDENSER
23. SEAT ASSEMBLY AIR
24. SEAT ASSEMBLY MECHANICAL
25. TRAINING SEAT
26. CAB HARDWARE AND CONTROL COVER
27. CAB HARDWARE AND CONTROL COVER OPEN CAB
28. INCHING PEDAL AND ACCESSORIES CAB
29. AIR DUCT AND ACCESSORIES CAB
30. DASH DISPLAY
31. INDICATOR DISPLAY ASSEMBLY
32. HYDRAULIC CONTROL AND TWISTLOCK EMPTY CONTAINER HANDLER
33. WINDOW WASHER AND ARMREST ASSEMBLY
34. ARMREST PIVOT-UP
35. CAB SOUND REDUCTION
36. ENGINE ASSEMBLY
36.1. ENGINE ASSEMBLY
36.2. EXHAUST PERKINS – TIER I ENGINE
36.3. EXHAUST PERKINS – TIER II ENGINE
36.4. EXHAUST CUMMINS – TIER I ENGINE ( S/N E019E02101A)
36.5. EXHAUST CUMMINS – TIER I ENGINE (S/N E019E02102A )
36.6. COOLING PERKINS – TIER I ENGINE
36.7. COOLING PERKINS – TIER II ENGINE
36.8. COOLING CUMMINS – TIER I ENGINE ( S/N E019E02101A)
36.9. COOLING CUMMINS – TIER I ENGINE (S/N E019E02102A )
36.10. FAN DRIVE AND MOUNTING CUMMINS – DRY BRAKE
36.11. ENGINE MOUNT PERKINS
36.12. ENGINE MOUNT CUMMINS
36.13. ENGINE BLOCK HEATER
36.14. ENGINE BLOCK HEATER
36.15. AIR DRYER AND ATTACHING PARTS
36.16. AIR DRYER ASSEMBLY
36.17. FLYWHEEL PERKINS
36.18. CYLINDER BLOCK PERKINS – TIER I ENGINE ( S/N E019E01964A)
36.19. CRANKSHAFT AND PISTON PERKINS – TIER I ENGINE ( S/N E019E01964A)
36.20. CYLINDER HEAD PERKINS – TIER I ENGINE ( S/N E019E01964A)
36.21. TIMING GEAR PERKIINS – TIER I ENGINE ( S/N E019E01964A)
36.22. AUXILIARY DRIVE GEAR PERKINS – TIER I ENGINE ( S/N E019E01964A)
36.23. OIL SUMP PERKINS – TIER I ENGINE ( S/N E019E01964A)
36.24. VALVE COVER PERKINS – TIER I ENGINE ( S/N E019E01964A)
36.25. OIL FILTER PERKINS – TIER I ENGINE ( S/N E019E01964A)
36.26. MANIFOLDS PERKINS – TIER I ENGINE ( S/N E019E01964A)
36.27. WATER PUMP PERKINS – TIER I ENGINE ( S/N E019E01964A)
36.28. TURBOCHARGER PERKINS – TIER I ENGINE ( S/N E019E01964A)
36.29. AIR DUCT PERKINS – TIER I ENGINE ( S/N E019E01964A)
36.30. LUBRICATION SYSTEM PERKINS – TIER I ENGINE ( S/N E019E01964A)
36.31. AIR COMPRESSOR AND ATTACHING PARTS PERKINS
36.32. AIR COMPRESSOR PAGE 1 OF 2
36.33. AIR COMPRESSOR PAGE 2 OF 2
36.34. CYLINDER BLOCK PERKINS – TIER II ENGINE
36.35. CYLINDER HEAD PERKINS – TIER II ENGINE
36.36. CYLINDER HEAD COVER PERKINS – TIER II ENGINE
36.37. CRANKSHAFT AND MAIN BEARINGS PERKINS – TIER II ENGINE
36.38. PISTON AND CONNECTING ROD PERKINS – TIER II ENGINE
36.39. CAMSHAFT AND ROCKER ASSEMBLY PERKINS – TIER II ENGINE
36.40. TIMING CASE AND ALTERNATOR MOUNTING PERKINS – TIER II ENGINE
36.41. TIMING COVER PERKINS – TIER II ENGINE
36.42. TIMING GEAR PERKINS – TIER II ENGINE
36.43. OIL SUMP PERKINS – TIER II ENGINE
36.44. MANIFOLDS PERKINS – TIER II ENGINE
36.45. IDLER GEAR PERKINS – TIER II ENGINE
36.46. FRONT DRIVE PULLEY PERKINS – TIER II ENGINE
36.47. FAN DRIVE AND PULLEY PERKINS – TIER II ENGINE
36.48. AUXILIARY DRIVE GEAR PERKINS – TIER II ENGINE
36.49. BLANKING PLUG, OIL FEED AND HOSES PERKINS – TIER II ENGINE
36.50. BLANKING PLATE AND PLUGS PERKINS – TIER II ENGINE
36.51. OIL PUMP AND DELIVERY HOUSING PERKINS – TIER II ENGINE
36.52. OIL FILTER AND ATTACHING PARTS PERKINS – TIER II ENGINE
36.53. OIL COOLER AND CONNECTIONS PERKINS – TIER II ENGINE
36.54. THERMOSTAT AND WATER OUTLET HOUSING PERKINS – TIER II ENGINE
36.55. WATER PUMP PERKINS – TIER II ENGINE
36.56. TURBOCHARGER AND ATTACHING PARTS PERKINS – TIER II ENGINE
36.57. TURBO DRAIN PIPE AND BLANKING PLATE PERKINS – TIER II ENGINE
36.58. ENGINE LIFTING EYES PERKINS – TIER II ENGINE
36.59. ELECTRONIC CONTROL MODULE AND MOUNTING PERKINS – TIER II ENGINE
36.60. WIRING LOOMS PERKINS – TIER II ENGINE
36.61. PICK-UP SENSORS PERKINS – TIER II ENGINE
36.62. OIL FILTER FULL FLOW – CUMMINS
37. FUEL SYSTEM
37.1. FUEL SYSTEM PERKINS – TIER I ENGINE ( S/N E019E01964A)
37.2. FUEL SYSTEM CUMMINS
37.3. FUEL INJECTION PERKINS – TIER I ENGINE ( S/N E019E01964A)
37.4. LOW PRESSURE SYSTEM PERKINS – TIER I ENGINE ( S/N E019E01964A)
37.5. LIFT PUMP PERKINS – TIER I ENGINE ( S/N E019E01964A)
37.6. FUEL FILTER PERKINS – TIER I ENGINE ( S/N E019E01964A)
37.7. AIR FILTER WITHOUT ASPIRATED PRE-FILTER – TIER I ENGINE
37.8. AIR FILTER WITH ASPIRATED PRE-CLEANER – TIER I ENGINE
37.9. FUEL SYSTEM PERKINS – TIER II ENGINE (S/N E019E01965A )
37.10. FUEL INJECTION PUMP AND GEAR PERKINS – TIER II ENGINE
37.11. HIGH PRESSURE FUEL PIPES PERKINS – TIER II ENGINE
37.12. FUEL INJECTION SUPPLY AND RETURN LINES PERKINS – TIER II ENGINE
37.13. LIFT PUMP AND FUEL FILTER LINES TIER II ENGINE
37.14. LIFT PUMP ASSEMBLY PERKINS – TIER II ENGINE
37.15. FUEL FILTER ASSEMBLY PERKINS – TIER II ENGINE
37.16. AIR FILTER WITHOUT ASPIRATED PRE-CLEANER – TIER II ENGINE
37.17. AIR FILTER WITH ASPIRATED PRE-CLEANER – TIER II ENGINE
37.18. WATER SEPARATOR PERKINS
37.19. THROTTLE LINKAGE PERKINS
37.20. THROTTLE LINKAGE CUMMINS
37.21. THROTTLE PEDAL LINKAGE FORWARD AND REVERSE LEVER
37.22. THROTTLE PEDAL LINKAGE MONOTROL PEDAL
37.23. MONOTROL PEDAL
38. ELECTRICAL SYSTEM
38.1. ELECTRICAL SYSTEM PERKINS – TIER I ENGINE ( S/N E019E01964A)
38.2. ELECTRICAL SYSTEM PERKINS – TIER II ENGINE (S/N E019E01965A )
38.3. ELECTRICAL SYSTEM CUMMINS
38.4. CONTROL PANEL HEATER
38.5. CONTROL PANEL AIR CONDITIONER
38.6. DC-DC CONVERTER AND ATTACHING PARTS
38.7. STARTER MOTOR TIER I ENGINE
38.8. ALTERNATOR
38.9. ALTERNATOR BRACKET AND ATTACHING PARTS PERKINS – TIER II ENGINE
38.10. ALTERNATOR AND PULLEY PERKINS – TIER II ENGINE
38.11. ALTERNATOR AND MOUNTING CUMMINS
38.12. STARTER MOTOR CUMMINS
38.13. WIRE HARNESS FUSES AND RELAY
38.14. WIRE HARNESS STEERING COLUMN
38.15. WIRE HARNESS REAR WIPER
38.16. WIRE HARNESS OPEN CAB
38.17. WIRE HARNESS CLOSED CAB
38.18. WIRE HARNESS ARMREST – WITH CLOSED CAB
38.19. WIRE HARNESS ARMREST – WITH OPEN CAB
38.20. WIRE HARNESS AUTOSHIFT BY-PASS
38.21. WIRE HARNESS CAB UNDERFLOOR
38.22. WIRE HARNESS CAB SIDE CONSOLE ( S/N E019E01690Z Perkins) ( S/N E019E01776Z Cummins)
38.23. WIRE HARNESS CAB SIDE CONSOLE (S/N E019E01777Z Cummins) (S/N E019E01691Z S/N E019E01964A Perkins)
38.24. WIRE HARNESS CAB TILT
38.25. WIRE HARNESS TWO STAGE LIMITED FREE-LIFT
38.26. JOYSTICK ASSEMBLY
38.27. WIRE HARNESS CAB SIDE CONSOLE – PAGE 1 OF 3 (S/N E019E01965A (Perkins Engine))
38.28. WIRE HARNESS CAB SIDE CONSOLE – PAGE 2 OF 3 (S/N E019E01965A (Perkins Engine))
38.29. WIRE HARNESS CAB SIDE CONSOLE – PAGE 3 OF 3 (S/N E019E01965A (Perkins Engine))
38.30. RELAYS AND FUSES
39. TRANSMISSION
39.1. TORQUE CONVERTER HOUSING PERKINS
39.2. TORQUE CONVERTER HOUSING CUMMINS
39.3. TRANSMISSION MOUNT AND ATTACHING PARTS
39.4. INCHING PEDAL LINKAGE
39.5. TRANSMISSION
39.6. PUMP DRIVE GEARS
39.7. CLUTCH FORWARD AND LOW
39.8. CLUTCH REVERSE AND SECOND
39.9. SHAFT ASSEMBLY REVERSE AND SECOND CLUTCH SHAFT
39.10. CLUTCH THIRD
39.11. IDLER SHAFT
39.12. OUTPUT GEAR
39.13. CHARGE PUMP
39.14. MODULATOR VALVE
39.15. CONTROL VALVE TRANSMISSION
40. Drive Axle
40.1. DIFFERENTIAL AND CARRIER WET BRAKE ( S/N E019E02009A)
40.2. DIFFERENTIAL AND CARRIER WET BRAKE (S/N E019E02010A )
40.3. DIFFERENTIAL AND CARRIER DRY BRAKE ( S/N E019E02009A)
40.4. DIFFERENTIAL AND CARRIER DRY BRAKE (S/N E019E02010A )
40.5. AXLE HOUSING AND ATTACHING PARTS
40.6. HUB AND SHAFT ASSEMBLY WET BRAKE ( S/N E019E02009A)
40.7. HUB AND SHAFT ASSEMBLY WET BRAKE (S/N E019E02010A )
40.8. HUB AND SHAFT ASSEMBLY DRY BRAKE ( S/N E019E02009A)
40.9. HUB AND SHAFT ASSEMBLY DRY BRAKE (S/N E019E02010A )
40.10. PARK BRAKE WET BRAKE
41. STEERING SYSTEM
41.1. STEERING SYSTEM
41.2. STEERING COLUMN
41.3. COLUMN ASSEMBLY STEERING
41.4. STEERING PUMP
41.5. STEERING AXLE
41.6. STEERING CYLINDER
42. BRAKE SYSTEM
42.1. BRAKE SYSTEM WET
42.2. BRAKE SYSTEM DRY
42.3. OIL COOLER
42.4. ACCUMULATOR
42.5. BRAKE ASSEMBLY WET BRAKE
42.6. BRAKE ASSEMBLY DRY BRAKE
42.7. BRAKE VALVE WET BRAKE
42.8. BRAKE VALVE DRY BRAKE
43. HYDRAULIC SYSTEM
43.1. HYDRAULIC SUPPLY AND RETURN
43.2. LIFT ACCUMULATOR AND ATTACHING PARTS
43.3. ACCUMULATOR PISTON TYPE
43.4. HYDRAULIC TANK AND ATTACHING PARTS
43.5. HYDRAULIC TANK AND ATTACHING PARTS
43.6. HYDRAULIC VALVE AND ATTACHING PARTS
43.7. HYDRAULIC PUMP
43.8. HYDRAULIC PUMP
43.9. CONTROL VALVE
43.10. CONTROL VALVE
43.11. END CAP PARTS
43.12. PILOT VALVE
43.13. JOYSTICK CONTROL
43.14. CONTROL LEVER HYDRAULIC ( S/N E019E01578Y)
43.15. CONTROL LEVER HYDRAULIC (S/N E019E01579Y S/N E019E01914A)
43.16. CONTROL LEVER ELECTRONIC (S/N E019E01915A )
43.17. ELECTRONIC LEVER ASSEMBLY
43.18. TILT CYLINDER AND ATTACHING PARTS
43.19. TILT CYLINDER
43.20. MAST INSTALLATION
44. Mast-Two Stage Limited Free-Lift
44.1. OUTER MAST
44.2. INNER MAST
44.3. LIFT CYLINDER NON-EMPTY CONTAINER HANDLER
44.4. LIFT CYLINDER EMPTY CONTAINER HANDLER
44.5. CARRIAGE THREE FUNCTION
44.6. CARRIAGE FOUR, FIVE, AND SIX FUNCTION
44.7. CARRIAGE FOUR AND FIVE FUNCTION
44.8. CARRIAGE INDIVIDUAL FORK POSITIONER
44.9. CARRIAGE INDIVIDUAL FORK POSITIONER – FOUR FUNCTION (S/N E019E01951A )
44.10. CARRIAGE SIMULTANEOUS FORK POSITIONER
44.11. FORK POSITIONING CYLINDER
44.12. HEADER HOSE TWO STAGE LIMITED FREE-LIFT ( S/N E019E01950A)
44.13. HEADER HOSE TWO STAGE LIMITED FREE-LIFT (S/N E019E01951A )
45. OPTIONS
45.1. SIDE-SHIFT CARRIAGE THREE FUNCTION
45.2. SIDE-SHIFT CARRIAGE FOUR AND FIVE FUNCTION ( S/N E019E01950A)
45.3. SIDE-SHIFT CARRIAGE FOUR, FIVE, AND SIX FUNCTION (S/N E019E01951A )
45.4. SIDE-SHIFT CARRIAGE INDIVIDUAL FORK POSITIONER ( S/N E019E01950A)
45.5. SIDE-SHIFT CARRIAGE INDIVIDUAL FORK POSITIONER – FIVE FUNCTION (S/N E019E01951A )
45.6. SIDE-SHIFT CARRIAGE SIMULTANEOUS FORK POSITIONER ( S/N E109E01950A)
45.7. SIDE-SHIFT CARRIAGE SIMULTANEOUS FORK POSITIONER – FOUR FUNCTION (S/N E019E01951A )
45.8. SIDE-SHIFT CARRIAGE DUAL FUNCTION WITH FORK POSITIONER
45.9. SIDE-SHIFT CYLINDER
45.10. DIRECTIONAL CONTROL VALVE
45.11. SIDE-SHIFT CYLINDER DUAL FUNCTION WITH FORK POSITIONER
45.12. MAST AND REAR WORK LIGHTS
45.13. FRONT, BRAKE AND BACK-UP LIGHTS
45.14. STROBE LIGHT
45.15. CAB MOUNTED DRIVE LIGHTS
45.16. LIFTING EYES
45.17. TIRE AND WHEEL 11.00 X 20 – 14 PLY
45.18. TIRE AND WHEEL 12.00 X 20
45.19. TIRE AND WHEEL 12.00 X 20 – SOLID
45.20. HEADER HOSE EMPTY CONTAINER HANDLER ( S/N E019E01950A)
45.21. HEADER HOSE EMPTY CONTAINER HANDLER (S/N E019E01951A )
45.22. INSTALLATION EMPTY CONTAINER HANDLER
45.23. MAIN FRAME SERIES 553, 555, 558 – 250 MM (10 IN.) SIDE-SHIFT
45.24. SELECTOR VALVE
46. FIELD CONVERSION KITS
46.1. MAST HOSE SHEAVE KIT
46.2. DIRECTIONAL CONTROL CONVERSION KIT
46.3. AIR CONDITIONING KITS
46.4. SPEED SENSOR KIT
47. NUMERICAL INDEX

Rate this product
