Komatsu 830E-1AC Dump Truck Operation and Maintenance Manual CEAM031900

$20.00

Type Of Manual: Operation and Maintenance Manual
Manual ID: CEAM031900
Format: PDF
Size: 1.1MB
Number of Pages: 74

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- 830E-1AC Dump Truck

1. FOREWORD
2. ALERTS PAGE
3. TABLE OF CONTENTS
4. TRUCK MODEL ILLUSTRATION
5. KOMATSU MODEL 830EAC DUMP TRUCK
6. ABOUT THIS MANUAL
7. TORQUE TABLES AND CONVERSION CHARTS
7.1. INDEX OF TABLES
7.2. EFFECT OF SPECIAL LUBRICANTS On Fasteners and Standard Torque Values
7.3. STANDARD TIGHTENING TORQUES For Class 10.9 Cap screws Class 10 Nuts
7.4. STANDARD TIGHTENING TORQUES For SAE Grade 5 and Grade 8 Cap screws
7.5. STANDARD TIGHTENING TORQUES For SAE Hex Head and 12Point, Grade 9 Capscrews
8. GENERAL SAFETY
8.1. Safety Rules
8.2. Truck Safety Features
8.3. Clothing And Personal Items
8.4. Unauthorized Modification
8.5. Leaving The Operators Seat
8.6. Mounting And Dismounting
8.7. Fire Extinguishers And First Aid Kits
8.8. Precautions For High Temperature Fluids
8.9. Asbestos Dust Hazard Prevention
8.10. Fire Prevention For Fuel And Oil
8.11. ROPS Precautions
8.12. Preventing Injury From Work Equipment
8.13. Precautions For Optional Attachments
8.14. Precautions When Starting The Machine
8.15. WORKING NEAR BATTERIES
9. PRECAUTIONS FOR MAINTENANCE
9.1. BEFORE PERFORMING MAINTENANCE
9.1.1. Stopping The Engine Before Service
9.1.2. Electrical Systems Isolation
9.1.3. Warning Tag
9.1.4. Proper Tools
9.1.5. Use of TieOff Anchor During Maintenance
9.1.6. Securing The Dump Body
9.2. DURING MAINTENANCE
9.2.1. Personnel
9.2.2. Attachments
9.2.3. Working Under The Machine
9.2.4. Keeping The Machine Clean
9.2.5. Use Of Lighting
9.2.6. Precautions With The Battery
9.2.7. Handling High Pressure Hoses
9.2.8. Precautions With High Pressure Oil
9.2.9. Maintenance Near High Temperatures And High Pressures
9.2.10. Rotating Fan And Belts
9.2.11. Waste Materials
10. WHEN REPAIRS ARE NECESSARY
11. SPECIAL PRECAUTIONS FOR WORKING ON AN 830E/930E TRUCK
11.1. Preliminary Procedures before Welding or Performing Maintenance
11.2. Engine Shutdown Procedure before Welding or Performing Maintenance
12. CAPACITOR DISCHARGE SYSTEM
12.1. Necessary Tools
12.2. Warnings And Cautions
12.3. MANUAL DC LINK CAPACITOR DISCHARGE PROCEDURE
12.3.1. Preparation
12.3.2. CAPACITOR CHARGE LIGHTS
12.4. FAILURE OF DISCHARGE SYSTEM
12.4.1. Measuring Dc Voltage On Capacitors
12.5. MANUAL DISCHARGE OF CAPACITORS
12.6. SHORT ISOLATED CAPACITOR TERMINALS
13. CHASSIS SOUND ATTENUATION SYSTEM
13.1. OVERVIEW
13.1.1. Preparing For Operation
13.1.1.1. Safety Is Thinking Ahead
13.1.1.2. Approximate weights
13.1.2. Attenuators
13.1.2.1. General
13.1.3. Engine Side Panels
13.1.3.1. General
13.1.3.2. Maintenance
13.1.4. Engine Belly Pan Assembly
13.1.4.1. General
13.1.4.2. Maintenance
13.1.4.3. Approximate weights
13.1.5. Radiator Silencer
13.1.5.1. General
13.1.5.2. Maintenance
13.1.5.3. Approximate weights
13.1.6. Rear Engine Compartment Enclosure
13.1.6.1. General
13.1.6.2. Maintenance
13.1.6.3. Approximate weights
13.1.7. Center Deck Lining
13.1.7.1. General
13.1.8. Front Panel Assembly Below Radiator
13.1.8.1. General
13.2. Hood Seals
13.2.1. Upper Horse Collar Panels
13.2.1.1. Maintenance
13.2.2. Blower Duct Cover Hoses
13.2.2.1. General
13.2.2.2. Maintenance
14. DRIVE SYSTEM SOUND ATTENUATION SYSTEM
14.1. RETARDING GRID ATTENUATION PACKAGE
14.1.1. General
14.1.1.1. Maintenance
14.2. Alternator Air Intake Silencer
14.2.1. Maintenance
15. SOUND ATTENUATION SYSTEM SERVICE INTERVALS
15.1. EVERY 10 HOUR (DAILY) MAINTENANCE
15.2. EVERY 500 HOUR MAINTENANCE
15.3. EVERY 6000 HOUR MAINTENANCE
15.4. EVERY 10,000 HOUR MAINTENANCE
16. MAJOR COMPONENT DESCRIPTION
16.1. SPECIFICATIONS
16.2. WEIGHT DISTRIBUTION
16.2.1. OVERALL TRUCK DIMENSIONS (Empty with Standard Body)
