Komatsu 830E-5 Dump Truck Field Assembly Instruction CEAW013901

$20.00

Type Of Manual: Field Assembly Instruction
Manual ID: CEAW013901
Format: PDF
Size: 22.2MB
Number of Pages: 420

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- 830E-5 Dump Truck

1. FIELD ASSEMBLY MANUAL 830E5 DUMP TRUCK
2. Foreword
3. Table of Contents
4. SAFETY RULES
5. TRUCK COMPONENTS AND SPECIFICATIONS
6. MAJOR COMPONENT WEIGHTS
7. FIELD WELDING FOR ASSEMBLY OR REPAIR
8. RECEIVING ASSEMBLY PREPARATION
9. CHASSIS ASSEMBLY
9.1. ORDER OF ASSEMBLY
9.2. CHASSIS ASSEMBLY
9.3. GENERAL PRECAUTIONS AND INSTRUCTION
9.4. SN IDENTIFICATION
9.5. ASSEMBLY PROCEDURAL STEPS
10. DUMP BODY ASSEMBLY
11. FINAL ASSEMBLY
12. FINAL CHECKOUT
13. APPENDIX
13.1. STANDARD TORQUE CHARTS AND CONVERSION TABLES
13.2. SUSPENSION OILING AND CHARGING PROCEDURES
13.3. SUSPENSION OILING AND CHARGING BLOCK KIT
13.4. OIL AND NITROGEN SPECIFICATIONS CHART
13.5. FAN CLUTCH CHECKOUT PROCEDURE
13.6. ENGINE EMISSIONS AFTERTREATMENT SYSTEMS
13.7. TOEIN ADJUSTMENT
13.8. SEAT BELTS AND TETHERS
13.9. ELECTRIC CHECKOUT PROCEDURE
13.10. INTERFACE MODULE
13.11. ADDITIONAL ELECTRICAL CHECKOUT
13.12. HYDRAULIC SYSTEM CHECKOUT
13.13. Preshift Brake Test Checkout Procedure
13.14. BRAKE SYSTEM CHECKOUT
13.15. AUTOMATIC LUBRICATION SYSTEM
13.16. AUTO LUBE SYSTEM
13.17. AIR CONDITIONING SYSTEM
13.18. TIRE MONITORING SYSTEM
13.19. PAYLOAD METER IV
13.20. LOCK A, CHECKOUT PROCEDURE
13.21. KOMTRAX PLUS 2 SHOP SETUP
13.22. KOMTRAX PLUS 2 SITE SETUP
13.23. KPLUS2 SITE SETUP
13.24. KOMVISION CHECKOUT
13.25. KOMATSU WIRELESS BRIDGE
13.26. RETRACTABLE LADDER SYSTEM
13.27. FIELD ASSEMBLY INSPECTION REPORT
13.28. HOUR POSTCOMMISSIONING
