Komatsu 860E-1K, 860E-1KT Electric Dump Truck Field Assembly Instruction CEAW007204

$20.00

Type Of Manual: Field Assembly Instruction
Manual ID: CEAW007204
Format: PDF
Size: 8.0MB
Number of Pages: 304

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- 860E-1K Electric Dump Truck
- 860E-1KT Electric Dump Truck

1. FIELD ASSEMBLY MANUAL 860E1K/860E1KT DUMP TRUCK
2. Contents
3. FOREWORD
3.1. Foreword
3.2. WARNINGS
3.3. Safety Alert Symbol and Signal Words
4. SAFETY RULES, TOOLS AND EQUIPMENT
4.1. Safety rules
4.2. Tools and equipment for assembly
4.3. Assembly schedule
5. TRUCK COMPONENTS AND SPECIFICATIONS
5.1. Truck components
5.2. Specifications
6. MAJOR COMPONENT WEIGHTS
6.1. Major component weights
7. FIELD WELDING FOR ASSEMBLY OR REPAIR
7.1. Introduction
7.2. General repair procedures
8. RECEIVING AND ASSEMBLY PREPARATION
8.1. Parts preparation
9. CHASSIS ASSEMBLY
9.1. Assembly introduction
9.2. Chassis Assembly
10. DUMP BODY ASSEMBLY
10.1. Dump body general information
11. FINAL ASSEMBLY
11.1. Final assembly general information
12. FINAL CHECKOUT
12.1. Perform final checkout
13. APPENDIX
13.1. Appendix
13.2. Torque Specifications
13.3. Suspension Oiling and Charging Procedures (58E6002200_04)
13.4. Suspension Oiling and Charging Block Kit Installation Procedure (FAM1211)
13.5. Oil and Nitrogen Specifications Chart (FAM1204)
13.6. ToeIn Adjustment (FAM1305)
13.7. Seat Belts And Tethers Checkout Procedure (SM2700_03)
13.8. Electric Checkout Procedure (58B6050501)
13.9. Interface Module Checkout Procedure (58C0620700_01)
13.10. Hydraulic System Checkout Procedure (58C6010600_02)
13.11. Brake System Checkout Procedure (58C6010190_02)
13.12. Payload Meter IV Checkout Procedure (58B0602400_06)
13.13. Komtrax Plus Setup Procedure (EM21281)
13.14. Komtrax Plus Checkout Procedure (EM21293)
13.15. Reserve Oil System Checkout Procedure (58F9000400_01)
13.16. Auto Lube System (58F9000300_02)
13.17. Automatic Lubrication System Priming (FAM1406)
13.18. Air Conditioning System Checkout Procedure (EM4003_02)
13.19. KDrive Checkout Procedure (58C4300020)
13.20. FIELD ASSEMBLY INSPECTION REPORT
13.21. HOUR POSTCOMMISSIONING CHECKSHEET
