Komatsu D61EXi-24, D61PXi-24 Bull Dozer Operation and Maintenance Manual PEN02046-00

$20.00

Type Of Manual: Operation and Maintenance Manual
Manual ID: PEN02046-00
Format: PDF
Size: 25.8MB
Number of Pages: 313

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- D61EXi-24 Bull Dozer
- D61PXi-24 Bull Dozer

1. Cover
2. Foreword
2.1. Table of Contents
2.2. Read This Manual
2.3. Safety Information
2.4. Introduction
2.4.1. intelligent Machine Control
2.4.2. Machine Features
3. Safety
3.1. General Precautions Common to Operation and Maintenance
3.1.1. Precautions When Getting on or off Machine
3.1.2. Precautions for Blade Automatic Control
3.2. Precautions for Operation
3.2.1. Start Engine
3.3. Precautions for Maintenance
3.3.1. Precautions for Check and Maintenance
4. Operation
4.1. General View
4.1.1. Names of Machine Equipment
4.1.2. Control Levers and Pedals
4.2. Explanation of Components
4.2.1. intelligent Machine Control System
4.2.2. Other Equipment
4.3. Machine Operations and Controls
4.3.1. Checks and Adjustment Before You Start Engine
4.3.2. Operations and Checks After You Start Engine
4.3.3. How to Stop Engine
4.3.4. How to Use Automatic Blade Control
4.4. Transportation
4.4.1. Remove Radio Device Antenna Cable
4.5. Precautions for LongTerm Storage
4.5.1. Turn Battery Disconnect Switch to OFF Position Before LongTerm Storage
4.6. Troubles and Procedures
4.6.1. Troubles and Procedures During Automatic Blade Control When Simple Grading Mode is OFF
4.6.2. Phenomena and Procedures for Control Box
5. Handle Control Box
5.1. Table of Contents
5.2. Overview
5.2.1. Function of Switches
5.2.2. Brightness and Volume Control
5.2.3. LED Indicator
5.2.4. Keyboard Functions
5.2.5. How to Show Main Menu
5.3. File Menu
5.3.1. Project Files
5.3.2. Control Point Files
5.3.3. Layers
5.3.4. Point Data
5.3.5. Surface File
5.3.6. Surfaces Mode
5.3.7. Active File
5.3.8. Exit 3DMC
5.4. Control Menu
5.4.1. Machine Setting
5.4.2. How to Set ASBUILT Control Options
5.4.3. Blade Control
5.4.4. Steer Indication Options
5.4.5. Dozing Control
5.4.6. Adjust Blade Elevation
5.4.7. Pitch Rod Calibration
5.4.8. Adjust Wear Volume
5.4.9. Machine Calibration
5.5. Tools Menu
5.5.1. Radio Device Settings
5.5.2. Position Settings
5.5.3. Navigate Points
5.5.4. Topo Shot for Topographic Survey
5.5.5. Set Sitelink3D
5.5.6. Komatsu Options
5.5.7. Supervisor Mode
5.6. View Menu
5.6.1. Main Window Display
5.6.2. Left Window Display
5.6.3. Right Window Display
5.6.4. Lower Window Display
5.6.5. Display Options
5.7. Main Window Display
5.7.1. Elevation Control Key
5.7.2. Slope Control Key
5.7.3. Shortcut on the Main Window
5.7.4. Pan of Main Map View
5.8. Operation on Main Menu
5.8.1. How to Show GNSS Information
5.8.2. How to Adjust Cut/Fill Offsets
5.8.3. How to Change Grade Indicator Display
5.8.4. How to Change Display of Light Bar
5.8.5. Operation by Popup Menu
5.8.6. How to Set Lift Layer Control Function
5.8.7. How to Use Quick Surface Creation Function
5.8.8. Use Quick Surface Adjustment Function
6. Specifications
6.1. Specifications
6.1.1. Specifications D61EXI24
6.1.2. Specifications D61PXI24
7. Laser Machine Control
7.1. Handle 2D Laser Machine Control
7.1.1. Laser Machine Control
7.1.2. Operations and Controls of 2D Laser Machine Control
7.1.3. Laser Machine Control Application
7.2. Troubles and Procedures
7.2.1. Other Trouble
7.2.2. Procedures When PopUp Message is Shown on Control Box
8. Index
