Komatsu WA115-3 Wheel Loader Operation and Maintenance Manual VEAM120100

$20.00

Type Of Manual: Operation and Maintenance Manual
Manual ID: VEAM120100
Format: PDF
Size: 8.5MB
Number of Pages: 251

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- WA115-3 Wheel Loader

1. WA115gb_VEAM120100_Inhalt.pdf
1.1. Introduction
1.1.1. Foreword
1.1.1.1. EU Directives
1.1.2. Safety information
1.1.3. Introduction
1.1.3.1. Intended use
1.1.3.2. Breakingin the machine
1.1.4. Location of plates
1.1.4.1. Machine identification plate
1.1.4.2. Vehicle identification number
1.1.4.3. Engine nameplate with serial no.
1.1.4.4. Table to enter serial no. and distributor
1.1.5. Table of contents
1.1.6. Dimensions, weights and operating data
1.1.7. CEconforming equipment
1.1.7.1. CEconforming equipment part 1
1.1.7.2. CEconforming equipment part 2
1.1.7.3. CEconforming equipment part 3
1.1.7.4. Manufacturersupplied CEconforming equipment, according to document42R9319080
1.1.8. Loading and securing
1.2. Safety
1.2.1. General safety measures
1.2.1.1. Safety instructions
1.2.1.2. Safety devices
1.2.1.3. Emergency exit
1.2.1.4. Clothing and personal protection
1.2.1.5. Machine modifications
1.2.1.6. Before you leave the drivers seat
1.2.1.7. Mounting and dismounting
1.2.1.8. Fire prevention and fire fighting
1.2.1.9. Protection against asbestos dust
1.2.1.10. Protection against injuries
1.2.1.11. Working at high temperatures
1.2.1.12. Rollover protection system (ROPS)
1.2.1.13. Attachment for protection against falling objects (FOPS)
1.2.1.14. Attachments with auxiliary function
1.2.1.15. Battery
1.2.2. Safety precautions during operation
1.2.2.1. Prior to daily starting up
1.2.2.2. Machine operation
1.2.3. Safety measures during transport
1.2.3.1. Loading and unloading the machine
1.2.3.2. Transport
1.2.4. Precautions for maintenance
1.2.4.1. Personnel
1.2.4.2. Before carrying out maintenance
1.2.4.3. During maintenance
1.2.4.4. Tyres
1.2.5. Labels on the machine
1.2.5.1. Positions and order numbers of safety labels
1.2.5.2. Positions and order numbers of information labels
1.3. Operation
1.3.1. General view
1.3.1.1. General view of the machine
1.3.1.2. Controls and Indicators
1.3.2. Controls
1.3.2.1. Switches
1.3.2.2. Operating and control levers
1.3.2.3. Pedals
1.3.2.4. Miscellaneous controls
1.3.3. Control lamps, measuring indicators und warning lights
1.3.3.1. Overview
1.3.3.2. Control lamps
1.3.3.3. Measuring indicators
1.3.3.4. Warning lights
1.3.4. Description of individual elements
1.3.4.1. Safety bar
1.3.4.2. Towing pin
1.3.4.3. Alarm horn for reverse driving option
1.3.4.4. Fuses
1.3.4.5. SlowBlowing Fuses
1.3.4.6. Heater and ventilation system
1.3.5. Checks and adjustments prior to starting work
1.3.5.1. Visual inspection
1.3.5.2. Control checks
1.3.5.3. Adjustments
1.3.6. Operation
1.3.6.1. Starting the engine
1.3.6.2. Switching off the engine
1.3.6.3. Driving with the machine
1.3.6.4. Actuating working attachment
1.3.6.5. Raise/lower working attachment
1.3.6.6. Working with the wheeled loader
1.3.6.7. Precautions For Special Operations
1.3.6.8. If wheel brake fails to work
1.3.6.9. Check after stopping the engine
1.3.6.10. Locking
1.3.6.11. Tyre handling
1.3.7. Transport
1.3.7.1. Securing the articulated steering
1.3.7.2. Loading and securing the machine
1.3.7.3. Driving machine onto loading area of transport vehicle
1.3.7.4. Securing machine for transport
1.3.7.5. Transporting the machine
1.3.7.6. After Transport
1.3.8. Cold weather operation
1.3.8.1. Precautions for low temperatures
1.3.8.2. Precautions after completion of work
1.3.8.3. After the cold weather period
1.3.9. Longterm storage
1.3.9.1. Before storage
1.3.9.2. During storage
1.3.9.3. After storage
1.4. Troubleshooting
1.4.1. When the machine runs out of fuel
1.4.2. Towing the machine
1.4.3. If battery is discharged
1.4.3.1. Precautions for charging the battery
1.4.3.2. Starting the engine with a booster cable
1.4.4. For insufficient braking effect
1.4.4.1. Checking the brake function
1.4.4.2. Checking the parking brake function
1.4.5. Emergency steering properties
1.4.6. Emergency lowering
1.4.7. Other troubles
1.4.7.1. Electrical system
1.4.7.2. Engine
1.4.7.3. Hydraulic system
1.4.7.4. Brakes
1.4.7.5. Steering
1.4.7.6. Axles
1.4.7.7. Drivers Cab
1.5. Maintenance
1.5.1. Maintenance guide
1.5.2. Maintenance basics
1.5.2.1. Oil, fuel and coolant specifications
1.5.2.2. Specifications of the electrical system
1.5.3. Wearing parts list
1.5.4. Lubricants, fuels and filling capacities
1.5.5. Tools and standard tightening torques (bolts,nuts)
1.5.5.1. Introduction of recommended tools
1.5.5.2. Torque list
1.5.6. Periodical replacement of safetycritical parts
1.5.7. Maintenance schedule chart
1.5.8. Service procedure
1.5.8.1. Prestart checklist
1.5.8.2. Maintenance upon demand
1.5.8.3. Maintenance after first 50 service hours
1.5.8.4. Maintenance every 50 operating hours
1.5.8.5. Maintenance every 100 operating hours
1.5.8.6. Maintenance after the first 250 operating hours
1.5.8.7. Maintenance every 500 operating hours
1.5.8.8. Maintenance every 1000 operating hours
1.5.8.9. Maintenance every 2000 operating hours
1.6. Technical data
1.6.1. Technical data
1.6.2. Noise emission levels
1.6.3. Vibration level
1.6.4. Limit values for slopes
1.7. Special equipment and attachments
1.7.1. ALSelectronics
1.7.1.1. Structure and functioning principle of the ALSelectronics
1.7.1.2. Precautionary measures for switching on the ALSelectronics
1.7.1.3. Operating the ALSelectronics
1.7.1.4. Precautions when handling the accumulator
1.7.2. Air condition
1.8. Index
