Linde 1173-01 – L-matic HD, L14, L14AP, L16, L16AP, L20, L20AP Spare Parts Manual SN up to W41173V04921

$30.00

Type Of Manual: Spare Parts Manual
Manual ID: SN up to W41173V04921
Format: PDF
Size: 42.4MB
Number of Pages: 397
Serial Number:
SN up to W41173V04921

Category: Linde Parts Manual PDF

Model List:
- L-matic HD
- L14
- L14AP
- L16
- L16AP
- L20
- L20AP

1. L14.L16.L20
1.1. POWER UNIT ENGINE
1.1.1. DRIVE MOTOR
1.1.2. TRACTION MOTOR OWD . 1,5kW . W41173H03717 19.07.2017 and up
1.1.3. TRACTION MOTOR OWD . 2,3KW . W41173H03751 19.07.2017 and up
1.2. DRIVE TRANSMISSION
1.2.1. DRIVE UNIT
1.2.2. DRIVE UNIT OWD . 1,5kW . W41173H03717 19.07.2017 and up
1.2.3. DRIVE UNIT OWD . 2,3KW . W41173H03751 19.07.2017 and up
1.2.4. GEARBOX
1.2.5. REDUCER OWD . 1,5kW . 2,3KW . W41173H03717 . W41173H03751 19.07.2017 and up
1.3. CHASSIS, BODYWORK AND FITTINGS
1.3.1. HOODING
1.3.2. HOODING PLATEFORM VERSION
1.3.3. BATTERY LOCK
1.3.4. PLATFORM
1.3.5. PLATFORM COLD STORE
1.4. STEERING, BRAKING AND WHEELS
1.4.1. TILLER
1.4.2. TILLER PLATFORM VERSION
1.4.3. TILLER ACC . MMI . W41173V01502 and up AP . MMI . W41173V01488 and up
1.4.4. TILLER ARTICULATION
1.4.5. TILLER PIVOT ACC . MMI . W41173V01502 and up
1.4.6. TILLER PIVOT AP . MMI . W41173V01488 and up
1.4.7. STEERING CENTRE
1.4.8. STEERING MOTOR and up W41173G00405
1.4.9. STEERING MOTOR ES3024 . W41173G00406 and up
1.4.10. BRAKE
1.4.11. BRAKES 1,5 kW
1.4.12. BRAKES 2,3 kW
1.4.13. DRIVE WHEEL
1.4.14. load castor assembly without initial lift
1.4.15. LOAD WHEEL SIMPLE with initial lift . L14 . L16
1.4.16. LOAD WHEEL SIMPLE with initial lift . L20
1.4.17. WHEEL LOAD SINGLE ROLLER LI
1.4.18. BOGGIE without initial lift
1.4.19. BOGGIE WITH LUB FITTING without initial lift
1.4.20. BOGGIE with initial lift . L14 . L16
1.4.21. BOGGIE with initial lift . L20
1.4.22. BOGGIE WITH LUB FITTING with initial lift . L14 . L16
1.4.23. BOGGIE WITH LUB FITTING with initial lift . L20
1.4.24. STABILIZER SIMPLE
1.4.25. STABILIZER DOUBLE
1.5. ELECTRICAL INSTALLATION
1.5.1. ELECTRIC AND CONTROLLER
1.5.2. ELECTRIC EQUIPMENT ES3024
1.5.3. MAIN HARNESS ACC W41173F00108
1.5.4. MAIN HARNESS PLATFORM VERSION AP W41173F00113
1.5.5. MAIN HARNESS ACC W41173F00109W41173G00405
1.5.6. MAIN HARNESS AP W41173F00114W41173G00405
1.5.7. MAIN HARNESS ACC W41173G00406
1.5.8. MAIN HARNESS AP W41173G00406
1.5.9. MAIN HARNESS ACC . MMI . W41173V01502 and up
1.5.10. MAIN HARNESS AP . MMI . W41173V01488 and up
1.5.11. MAIN HARNESS AP
1.5.12. MAIN HARNESS ACC
1.5.13. MAIN HARNESS LiIon ACC
1.5.14. MAIN HARNESS LiIon AP
1.5.15. MAIN HARNESS LiIon ACC
1.5.16. MAIN HARNESS LiIon AP
1.5.17. INBUILT CHARGER
1.5.18. SOCKET STANDARD
1.5.19. SOCKET FLEX
1.5.20. SOCKET PERFECT
1.5.21. LFM CONNECT
1.5.22. CONNECT
1.5.23. CONNECT GPRS Desk Online WIFI 19.03.2019
1.5.24. SOCKET BATTERY LiIon
1.5.25. BATTERY LiIon B1
1.5.26. BATTERY LiIon B2
1.5.27. BATTERY LOCK LiIon
1.5.28. BATTERY SUPPORT LiIon
1.6. HYDRAULIC EQUIPMENT
1.6.1. PUMP WITH MOTOR without initial lift
1.6.2. PUMP WITH MOTOR initial lift
1.6.3. PUMP WITH MOTOR initial lift Booster
1.6.4. PUMP WITH MOTOR without initial lift Booster W41173F02353
1.6.5. MOTOR PUMP UNIT without initial lift Booster W41173F02354
1.6.6. PUMP WITH MOTOR initial lift LiIon 08.11.2016 and up
1.6.7. PUMP WITH MOTOR initial lift Booster LiIon 08.11.2016 and up
1.6.8. HYDRAULIC EQUIPMENT initial lift
1.6.9. HYDRAULIC EQUIPMENT without initial lift
1.7. MAST AND AUXILIARY HYDRAULIC SERVICES
1.7.1. HOIST MAST TYPE S
1.7.2. HOIST MAST TYPE D
1.7.3. HOIST MAST TYPE T
1.7.4. MAST STANDARD 2t W41173F00107
1.7.5. MAST DUPLEX 2t W41173F00107
1.7.6. MAST TRIPLEX 2t W41173F00107
1.7.7. HOIST ASSEMBLY BATTERY UP SIDE
1.7.8. HOIST ASSEMBLY BATTERY SIDE EXIT W41173J01089
1.7.9. HOIST ASSEMBLY BATTERY UP SIDE 2T W41173F00107
1.7.10. HOIST ASSEMBLY BATTERY SIDE EXIT 2T
1.7.11. fork carriage W41173J02133
1.7.12. fork carriage W41173J02134
1.7.13. FORK CARRIAGE TYPE S.D 2T W41173F00107
1.7.14. FORK CARRIAGE TYPE T 2T W41173F00107
1.7.15. SIDE CYLINDER TYPE S
1.7.16. LEFT CYLINDER TYPE D
1.7.17. MIDDLE CYLINDER TYPE D
1.7.18. RIGHT CYLINDER TYP D
1.7.19. SIDE CYLINDER TYPE T
1.7.20. MIDDLE CYLINDER TYPE T
1.7.21. SIDE CYLINDER TYPE T
1.7.22. LIFT CYLINDER 2T Tige pleine Ø28 W41173F00107
1.7.23. LIFT CYLINDER 2T Tige creuse Ø28 W41173F00107
1.7.24. LIFT CYLINDER 2T Tige pleine Ø40 W41173F00107
1.7.25. LIFT CYLINDER 2T Tige creuse Ø40 W41173F00107
1.7.26. LIFT CYLINDER 2T Tige pleine Ø60 W41173F00107
1.8. OPTIONS AND ACCERRORIES
1.8.1. MOBILE BATTERY TROLLEY
1.8.2. BATTERY HOLDER
1.8.3. LOAD BACKREST
1.8.4. HEIGHT SENSOR
1.8.5. HEIGHT SENSOR 2T W41173F00107
1.8.6. LOAD MANAGEMENT W41173H01401 4m
1.8.7. LOAD MANAGEMENT W41173H01401 4m
1.8.8. KIT LOAD MANAGEMENT
1.9. Miscellaneous
1.9.1. MANUFACTURERS PLATE
1.9.2. MANUFACTURERS PLATE
