Komatsu PC20MR-3 Hydraulic Excavator Operation and Maintenance Manual TEN00414-00

$20.00

Type Of Manual: Operation and Maintenance Manual
Manual ID: TEN00414-00
Format: PDF
Size: 7.7MB
Number of Pages: 253

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- PC20MR-3 Hydraulic Excavator

1. COVER
2. FOREWORD
2.1. FOREWORD
2.2. SAFETY INFORMATION
2.3. INTRODUCTION
2.3.1. DIRECTIONS OF MACHINE
2.4. PRODUCT INFORMATION
2.4.1. PRODUCT IDENTIFICATION NUMBER (PIN)/MACHINE SERIAL NO. PLATE
2.4.2. ENGINE SERIAL NUMBER PLATE AND ITS LOCATION
2.4.3. EMISSION CONTROL INFORMATION LABEL AND ITS LOCATION
2.4.4. SERVICE METER LOCATION
2.4.5. YOUR MACHINE SERIAL NUMBERS AND DISTRIBUTOR
2.5. CONTENTS
3. SAFETY
3.1. SAFETY
3.2. SAFETY LABELS
3.2.1. LOCATION OF SAFETY LABELS
3.2.2. SAFETY LABELS
3.3. GENERAL PRECAUTIONS
3.4. SAFETY MACHINE OPERATION
3.4.1. STARTING ENGINE
3.4.2. OPERATION
3.4.3. TRANSPORTATION
3.4.4. BATTERY
3.4.5. TOWING
3.4.6. LIFTING OBJECTS WITH BUCKET
3.5. SAFETY MAINTENANCE INFORMATION
4. OPERATION
4.1. MACHINE VIEW ILLUSTRATIONS
4.1.1. OVERALL MACHINE VIEW
4.1.2. CONTROLS AND GAUGES
4.2. DETAILED CONTROLS AND GAUGES
4.2.1. MONITORING SYSTEM
4.2.2. SWITCHES
4.2.3. CONTROL LEVERS AND PEDALS
4.2.4. WINDSHIELD
4.2.5. SLIDING DOOR
4.2.6. SLIDING WINDOW
4.2.7. EMERGENCY ESCAPE HAMMER
4.2.8. CAP WITH LOCK
4.2.9. ENGINE REAR COVER
4.2.10. COOLING COVER
4.2.11. FRONT RIGHT COVER
4.2.12. METHOD OF OPENING (TILTING) FLOOR
4.2.13. AUXILIARY ELECTRIC POWER
4.2.14. FUSE
4.2.15. BLOCK FUSE
4.2.16. OPERATION MANUAL STORAGE
4.2.17. TOOL BOX
4.2.18. GREASE GUN HOLDER
4.2.19. ASHTRAY
4.2.20. HANDLING MACHINES EQUIPPED WITH KOMTRAX
4.3. MACHINE OPERATIONS AND CONTROLS
4.3.1. BEFORE STARTING ENGINE
4.3.2. STARTING ENGINE
4.3.3. AFTER STARTING ENGINE
4.3.4. STOPPING THE ENGINE
4.3.5. MACHINE OPERATION
4.3.6. STEERING THE MACHINE
4.3.7. SWINGING
4.3.8. WORK EQUIPMENT CONTROLS AND OPERATIONS
4.3.9. PROHIBITED OPERATIONS
4.3.10. GENERAL OPERATION INFORMATION
4.3.11. TRAVELING ON SLOPES
4.3.12. ESCAPE FROM MUD
4.3.13. WORK POSSIBLE USING COMPACT HYDRAULIC EXCAVATOR
4.3.14. BUCKET REPLACEMENT
4.3.15. PARKING MACHINE
4.3.16. MACHINE INSPECTION AFTER DAILY WORK
4.3.17. LOCKING
4.3.18. RUBBER SHOES (MACHINE WITH RUBBER SHOES ONLY)
4.4. TRANSPORTATION
4.4.1. TRANSPORTATION PROCEDURE
4.4.2. LOADING AND UNLOADING WITH TRAILER
4.4.3. LIFTING MACHINE
4.5. COLD WEATHER OPERATION
4.5.1. COLD WEATHER OPERATION INFORMATION
4.5.2. CAB HEATER IN COLD WEATHER
4.5.3. AFTER DAILY WORK COMPLETION
4.5.4. AFTER COLD WEATHER SEASON
4.6. LONG TERM STORAGE
4.6.1. BEFORE STORAGE
4.6.2. DURING STORAGE
4.6.3. AFTER STORAGE
4.7. TROUBLES AND ACTIONS
4.7.1. RUNNING OUT OF FUEL
4.7.2. PHENOMENA THAT ARE NOT FAILURES
4.7.3. TOWING THE MACHINE
4.7.4. SEVERE JOB CONDITION
4.7.5. DISCHARGED BATTERY
4.7.6. OTHER TROUBLE
5. MAINTENANCE
5.1. MAINTENANCE INFORMATION
5.2. OUTLINE OF SERVICE
5.2.1. HANDLING OIL, FUEL, COOLANT, AND PERFORMING OIL CLINIC
5.2.2. ELECTRIC SYSTEM MAINTENANCE
5.2.3. HANDLING HYDRAULIC SYSTEM
5.3. WEAR PARTS
5.3.1. WEAR PARTS LIST
5.4. RECOMMENDED FUEL, COOLANT, AND LUBRICANT
5.5. TIGHTENING TORQUE SPECIFICATIONS
5.5.1. TIGHTENING TORQUE LIST
5.6. SAFETY CRITICAL PARTS
5.6.1. SAFETY CRITICAL PARTS LIST
5.7. MAINTENANCE SCHEDULE
5.7.1. MAINTENANCE SCHEDULE CHART
5.7.2. MAINTENANCE INTERVAL FOR HYDRAULIC BREAKER
5.8. MAINTENANCE PROCEDURE
5.8.1. WHEN REQUIRED
5.8.2. CHECK BEFORE STARTING
5.8.3. EXPLANATION OF SYMBOLS FOR LUBRICATION STANDARD TABLE
5.8.4. EVERY 500 HOURS MAINTENANCE
5.8.5. EVERY 1000 HOURS MAINTENANCE
5.8.6. EVERY 1500 HOURS MAINTENANCE
5.8.7. EVERY 2000 HOURS MAINTENANCE
6. SPECIFICATIONS
6.1. SPECIFICATIONS
7. ATTACHMENTS, OPTIONS
7.1. ATTACHMENTS AND OPTIONS GENERAL INFORMATION
7.1.1. SAFETY FIRST
7.1.2. ATTACHMENT INSTALLATION
7.2. BUCKET WITH HOOK
7.2.1. HOOK CONDITION
7.2.2. PROHIBITED OPERATIONS
7.3. WINDSHIELD WASHER
7.3.1. WINDSHIELD WASHER OPERATION
7.3.2. CHECK WINDOW WASHER FLUID LEVEL, ADD FLUID
7.4. MACHINE READY FOR ATTACHMENT
7.4.1. LOCATIONS
7.4.2. HYDRAULIC CIRCUIT
7.4.3. ATTACHMENT OPERATIONS
7.4.4. LONG TERM STORAGE
7.4.5. SPECIFICATIONS
7.5. ATTACHMENT GUIDE
7.5.1. ATTACHMENT COMBINATIONS
7.6. RECOMMENDED ATTACHMENT OPERATIONS
7.6.1. HYDRAULIC BREAKER
8. INDEX
