Komatsu PC490LC-11 Hydraulic Excavator Field Assembly Instruction GEN00126-03

$20.00

Type Of Manual: Field Assembly Instruction
Manual ID: GEN00126-03
Format: PDF
Size: 13.7MB
Number of Pages: 150

Category: Komatsu Operation and Maintenance Manual PDF

Model List:
- PC490LC-11 Hydraulic Excavator

1. COVER
2. FOREWORD
3. CONTENTS
4. Specifications
5. Precautions for Field Assembly
6. Disposal of removed parts
7. Assembling procedures,applicable equipment and schedule
8. Flow of field assembly
9. Kit layout diagram
10. Transportation
11. Tool list for field assembly
12. Tightening torque
13. Coating materials
14. Selection of wire ropes used for assembly
15. Selection of nylon slings used for assembly
16. Assembly of Chassis
16.1. A1. Installation of climbing step
16.2. A2. Installation of handrail
16.3. A3. Installation of mirror
16.4. A4. Installation of tail pipe, tail pipe cover
17. Assembling of Work Equipment
17.1. B1. Installation of boom cylinder
17.2. B2. Releasing remaining pressure in hydraulic circuit
17.3. B3. Installation of boom cylinder hoses
17.4. B4. Installation of boom cylinder top pin
17.5. B5. Installation of boom assembly
17.6. B6. Installation of hoses from chassis along top of boom
17.7. B7. Connection of boom cylinder head
17.8. B8. Installation of arm assembly
17.9. B9. Installation of bucket cylinder hoses between boom and bucket cylinder
17.10. B10. Installation of bucket
17.11. B11. Connection of work equipment grease piping
17.12. B12. Connection of work equipment wiring
17.13. B13. Greasing after completion of work equipment
17.14. B14. Bleeding air from work equipment circuit
18. Increasing and decreasing oF track frame gauge, assembling of counterweight
18.1. C1. Increasing and decreasing of track frame gauge
18.2. C2. Installation of steps
18.3. C3. Installation of travel piping covers
18.4. C4. Adjustment of track tension
18.5. C5. Sticking sheet to counterweight
18.6. C6. Installation of camera
18.7. C7. Installation of counterweight
19. Procedure for Inspection and Maintenance after Completion of Assembly
19.1. M1. Replacement of return filter (Standard filter to flushing filter)
19.2. M2. Flushing of hydraulic circuit
19.3. M3. Replacement of return filter (Flushing filter to standard filter)
19.4. M4. Check of oil/coolant level at each part
19.5. M5. Inspection of oil level in hydraulic tank and refill
19.6. M6. Parts to be touched up after field assembly
19.7. M7. ADJUST KomVision Camera angle (KomVision Spec.)(Camera calibration and 12 m visibility check)
19.8. M8. Error code
20. Mounting bolt torque check sheet
21. FIELD ASSEMBLY INSPECTION REPORT

Rate this product
